- Page 1 USER MANUAL Individual wireless controller KID-07 S IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
- Page 3 Table of Contents Remote Controller Specifications ............03 Handling the Remote Controller ............05 Buttons and Functions ..............04 Remote Screen Indicators ..............06 How to Use Basic Functions ............07 How to Use Advanced Functions ..........10...
- Page 4 Remote Controller Specifications KID-07 S Model 3.0V( Dry batteries R03/LR03×2) Rated Voltage Signal Receiving Range -5°C~60°C Environment Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH SELECT FAN SPEED PRESS POWER BUTTON POINT REMOTE TOWARD UNIT...
- Page 5 Handling the Remote Controller Inserting and Replacing Batteries NOTES FOR USING REMOTE CONTROL Your air conditioning unit may come with two The device could comply with the local national batteries(some units). Put the batteries in the regulations. remote control before use. In Canada, it should comply wit •...
- Page 6 Silence feature. Turbo SWING Enables unit to reach preset Starts and stops the horizontal temperature in shortest louver movement. Hold down possible time for 2 seconds to initiate vertical louver auto swing feature. KID-07 S (Fresh feature is not available) Model:...
- Page 7 Remote Screen Indicators Information are displayed when the remote controller is power up. Fresh feature display(some units) (No displays when Fresh feature is activated) Sleep mode display Follow me feature display Wireless control feature display Transmission Indicator Low battery detection display(If flashes) Lights up when remote sends signal to indoor MODE display...
- Page 8 How to Use Basic Functions Basic operation ATTENTION! Before operation, please ensure the unit is plugged in and power is available. SETTING TEMPERATURE The operating temperature range for units is 17-30°C /20-28 C. You can increase or decrease the set temperature in 1°C (1°F) increments.
- Page 9 DRY Mode (dehumidifying) 1. Press the MODE button to select DRY. 2. Set your desired temperature using the TEMP or TEMP button. 3. Press the ON/OFF button to start the unit. NOTE: FAN SPEED cannot be changed in DRY mode. Turbo FAN Mode Press the MODE button to select FAN mode.
- Page 10 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER button to initiate Press Temp. up or down button for Point remote to unit and wait 1sec, the ON time sequence.
- Page 11 How to Use Advanced Functions Swing function Press Swing button Swing Swing The horizontal louver will swing up and down Keep pressing this button more than 2 seconds, automatically when pressing Swing button. the vertical louver swing function is activated. Press again to make it stop.
- Page 12 LED DISPLAY Press this button more Press LED button than 5 seconds(some units) Keep pressing this button more than 5 seconds, Press this button to turn on and turn off the indoor unit will display the actual room the display on the indoor unit. temperature.
- Page 13 SLEEP Function Press SLEEP button The SLEEP function is used to decrease energy while you sleep(and don’t need the same temperature settings to stay comfortable). This function can only by activated via remote control. For the details, please see “sleep operation ” in “ USER’S MANUAL ”. Note: The SLEEP function is not available in FAN or DRY mode.
- Page 14 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CR266-RG10B(B)
