INSTALLATION & OWNER' S
MANUAL
WiFi Controller
K03 WIFI LCAC
IMPORTANT NOTE:
Thank you very much for purchasing our product.
Before using your unit, please read this manual carefully and keep it for future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K03 WIFI LCAC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kaysun K03 WIFI LCAC

Summary of Contents for Kaysun K03 WIFI LCAC

  • Page 1 INSTALLATION & OWNER’ S MANUAL WiFi Controller K03 WIFI LCAC IMPORTANT NOTE: Thank you very much for purchasing our product. Before using your unit, please read this manual carefully and keep it for future reference.
  • Page 3 ● This manual gives detailed description of the precautions that should be brought to your attention during operation. ● In order to ensure correct service of the smart port, please read this manual carefully before using the unit. ● For convenience of future reference, keep this manual after reading it.

  • Page 5: Table Of Contents

    CONTENTS 1. SAFETY PRECAUTION ................. 1 2. DOWNLOAD AND INSTALL APP ..............2 3. INSTALLATION ACCESSORY ............... 2 4. INSTALLATION METHOD ................3 5. SPECIFICATION .................... 6 6. USER REGISTRATION ................. 7 7. SET THE UNIT TO AP MODE ................ 7 8.

  • Page 7: Safety Precaution

    1. SAFETY PRECAUTION • Read the safety precautions carefully before installing the unit. • Stated below are important safety issues that must be obeyed. Applicable system: IOS, Android. (Suggest:IOS 10.3, Android 6.0) NOTE: APP cannot support the latest software version ofAndroid and IOS system. Due to special situation may be occurred, we explicitly claim below: Not all of the Android and IOS system are compatible with APP.

  • Page 8: Download And Install App

    2. DOWNLOAD AND INSTALL APP Caution: QR Code A and QR Code B is only available for downloading APP. QR Code A QR Code B • Android Phone users: scan QR Code A or go to google play, search ‘Nethome Plus’ app and download it •...

  • Page 9: Installation Method

    4. INSTALLATION METHOD 1.Wifi controller structure size figure Fig 4-1 2. Wiring Principle Sketch: Insert of the Applicable to K03 WIFI LCAC mainboard CN40 only black black yellow yellow brown brown 4-Core Shield Cable, the length Wifi control Indoor unit mainboard...

  • Page 10: Remove The Upper Part Of The Smart Port. (Fig

    4. Remove the upper part of the smart port • Insert a slot screwdriver into the slots in the lower part of the smart port (2 places), and remove the upper part of the smart port. (Fig.4-4) Fig 4-4 Slots 5.
  • Page 11 7. Wiring A. For exposed mounting, two outletting positions. Top side wire outlet Bottom side Fig 4-7 wire outlet B. Shielded wiring. Wiring through the wall Wiring hole and wall hole Fig 4-8 Diameter of wall hole: Φ20mm Putty Putty Trap Fig 4-9 CAUTION...

  • Page 12: Specification

    Fig 4-11 Fig 4-12 All the pictures in this manual are for explanation purpose only. Your Wi-Fi controller may be slightly different. The actual shape shall prevail. Model K03 WIFI LCAC Estandard IEEE802.11 b/g/n Antenna Type Wxternal omnidirectional Antenna Frequency WIFI:2.4G...

  • Page 13: User Registration

    6. USER REGISTRATION • Please ensure your mobile device is connected to Wifi router. Also, the Wifi router has already connected to Internet before doing user registration and network configuration. • It is better to log in your email box and active your registration account by clicking link in case you forget the password.

  • Page 14: Network Configuration

    8. NETWORK CONFIGURATION 1. Log in with your account . 2. Press “+ ” on the app’s appliance list screen and select the device category you need. 3. Choose network configuration method Scan QR Code Method: • It is suitable for user who likes simple steps. •...
  • Page 15 4. For Android (ScanQR code Method) 1 Scan QR Code which is packed with smart kit 2 Select your own WiFi network, for example My Home (the picture is only for reference) 3 Enter your own WiFi router password and click OK; 4 Configuration Success, you can see the device on the list.
  • Page 16 5. For Android (No need to Scan QR code Method) 1 Select net_xx_xxxx hotspot, type password 12345678 and click “next “. 2 Select your own WiFi network, for example My Home (the picture is only for reference) 3 Enter your own WiFi router password and click OK; NOTE: When finishisng...
  • Page 17 6. For IOS (Scan QR code Method) 1 Scan QR Code which is packed with smart kit 2 Read the instruction above and press the “Home ” button to return to the device interface. 3 Go to your wireless devices settings 4 Choose net_ac_ xxxx...
  • Page 18 5 Type defult password: 12345678 and click “Join “. 6 Go back to your APP’s Connecting Device Screen and tap next on the top-hand corner. 7 Select your own WiFi network, for example My Home (the picture is only for reference) 8 Enter your own WiFi router password and click OK;...
  • Page 19 7. For IOS (No need to Scan QR code Method) 1 Read the instruction above and press the “Home” button to return to the device interface. 2 Go to your wireless devices settings. 3 Choose net_ac_xxxx 4 Type default password: 12345678 and click “Join”.
  • Page 20 8. NETWORK CONFIGURATION 5 Go back to your APP’s Connecting Device Screen and tap next on the top-hand corner. 6 Select your own WiFi network, for example My Home (the picture is only for reference). 7 Enter your own WiFi router password and click OK; NOTE: •...

  • Page 21: How To Use App

    9. HOW TO USE APP Log in and select your unit to enjoy controlling it wherever you are from your smart device. NOTE: • Not all the functions of the APP are available on air-conditioner. For example: ECO, Turbo, Left and Right Swing, Up and Down Swing function, please check the user manual to find more information.

  • Page 22: Special Functions

    10. SPECIAL FUNCTIONS Including: Timer on, Timer off, Sleep curve, Check, Energy Monitor, Bill Control Check. NOTE: Not all the unit can use these special functions on the APP. Thus, if the air conditioner do not support the above functions, the functions will be hided from the function list.
  • Page 23 • Sleep User can customize their own comfortable sleep by setting target temperature. • Check User can simply check the AC running status with this function. When finishing this procedure, it can display the normal items, abnormal items, and detail information.
  • Page 24 • Energy monitor User can simply monitor the electricity consumption of AC unit by checking the chart and history record. • Bill Control Check User can set parameters to limit the electricity consumption over a period of time.

  • Page 25: App Declaration

    11. APP DECLARATION • Applicable system: IOS, Android Note: (Suggest IOS7.0, Android 4.0) • APP can not support the latest software version of Android and IOS system. • Due to special situation may be occurred, we explicitly claims below: Not all of the Android and IOS system are compatible with APP.
  • Page 26 CAUTION • Due to different network situation, control process may return time-out sometimes. If this situation occurs, the display between board and App may not be the same, please do not feel confused. • Smart Phone camera needs to be 5 million pixels or above to make sure scan QR code well.
  • Page 27 QSWFUI-002AEN 16110800A01696 20170729 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details.
