- Page 1 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro Difficulty Moderate Time Required 50 min PRODUCT PAGE Required Tools 1.5mm hex key 2mm hex key 2.5mm hex key 3mm hex key Parallel pliers Multimeter BONDTECH...
- Page 2 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH h t t p s : / / y o u t u . b e / 1 y 7 MY R E 1 0...
- Page 3 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Unscrew the screw on the side, holding the plastic Unscrew the screw on the other side. Remove the silicon sock. cowling to the Sprite, using a 2.5mm hex key.
- Page 4 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Using the 1.5mm hex key, remove the hotend fan. Using the 1.5mm hex key, unscrew the fan shroud Using the 2.5mm hex key, remove the bed leveling for the part cooling fan.
- Page 5 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Using the 2mm hex key, unscrew the two M2.5x10 Unscrew the LGX™ interface plug. Insert the two M2.5x10 hex screws into the hex screws (to be used later) from the SK heatsink.
- Page 6 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Before moving on, make sure there are no debris Clean any dust thoroughly. Install the fan in the LGX SK mount with the cable going through the SLS part.
- Page 7 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Install the bed leveling sensor in the fan shroud. Note the opening in the mount where the cables Using the 2mm hex key, install the two M3x10 low should be placed.
- Page 8 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Using the 2mm hex key, tighten the screws. Install the part cooling fan in the back of the NOTE: Make sure that it’s clean.
- Page 9 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Install the stepper motor cable that comes with Guide the cable down and insert it in the cable If needed, use a hex key to help.
- Page 10 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Insert all the connectors in place paying close Connect F1 to FAN1. Connect F2 to FAN2. attention to the labels. Connect the leveling sensor.
- Page 11 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Readjust the cables if necessary. Protect the build surface. Slide the printhead back in it’s position. Insert and tighten the two M3x8 low head screws, Reinstall the toolhead bus cable.
- Page 12 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Remove the panel gently and be careful with the Before removing completely, wiggle out the fan Remove the panel completely. cable from the board.
- Page 13 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH Insert back the two M6 screws and tighten them Reinstall the four M3 screws and tighten. Fully tighten the M6 screws. but not fully.
- Page 14 HOW TO Install an LGX SK Copperhead Upgrade Kit on Ender-3 S1 & S1 Pro BONDTECH IT’S DONE! TAKE GOOD CARE OF IT Every 6 months, or sooner if you have a higher than 15h per week average usage, perform the following maintenance operations: 1.
- Page 15 BONDTECH...
