COVANA EVO Replacement Procedure

PRODUCT MODELS
● Evolution Cover
● Oasis Cover
PURPOSE OF THE REPAIR PROCEDURE
This repair procedure should be performed if the replacement of a non-
motor post assembly is required on the Evolution or Oasis spa cover.
PREPARATION
● The cover must be closed
● Gather the required tools, as seen in the table at right
● Make sure the parts kit is complete and that parts have not
been damaged during transport. Call your local dealer if parts
need to be replaced.
Do not use power tools, some parts are fragile and may break under too much torque.
This procedure must be performed by a certified Covana installer.
Keep the key out of the key switch socket at all times. The certified Covana installer must keep control of the key during the
repair procedure. Derogation from this directive could cause serious injury or damage the cover.
Motor and non-motor sides identification
Motor
side
STEP BY STEP PROCEDURE
A- REMOVING DEFECTIVE JACK ASSEMBLY
1) Remove the
rubber cap from
the defective non-
motor jack.
EVO - OASIS ― NON-MOTOR JACK REPLACEMENT PROCEDURE
TOOLS REQUIRED
1/2" socket wrench and spanner
7/16" socket wrench and spanner
7/32" Allen key
Measuring tape
PARTS KIT NO. 234830
Oasis G3 Non-motor post assembly 600N
M6-1.0 Panel nut
M8-1.25 x 50 mm button head screw
Version française à la page 5.
CAUTION
WARNING
2) Remove the four
M6 x 20 mm bolts
and 5/16" painted
metal washers to
Non-Motor
separate the spa
side
cover from the post.
Do not discard !
Leave the bracket
attached to the
sleeve.
3) Remove the 3/8-24
x 1" Allen bolt with
a 7/32" Allen key.
Do not discard !
Rubber
cap
4) Loosen the Phillips
M6 x 20 mm screw
at the bottom of
the post. Do not
remove the screw.
image 1
COVANA.COM
Adjustable wrench
Phillips screwdriver
Rubber mallet
48" long level
QTY
1
1
2
M6
screw
1/4" nylon
washer
CODE
230050
202159
233731
image 2
image 3
image 4
1
