SCORPIO35, SCORPIO40, SCORPIO45,

SCORPIOCD35, SCORPIOCD40, SCORPIOCD45

Owner's Manual

FOR QUESTIONS AND CONCERNS, CONTACT US AT

www.allpartsinc.com

Call Us: 1-269-685-4123

Text Us: 1-269-447-0412

Need help?

Do you have a question about the SCORPIO35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Astria Fireplaces SCORPIO35

Page 1 SCORPIO35, SCORPIO40, SCORPIO45, SCORPIOCD35, SCORPIOCD40, SCORPIOCD45 Owner's Manual FOR QUESTIONS AND CONCERNS, CONTACT US AT FOR QUESTIONS AND CONCERNS, CONTACT US AT www.allpartsinc.com Call Us: 1-269-685-4123 Text Us: 1-269-447-0412...
Page 2 Installation and Operation Instructions Scorpio™ Series Direct-Vent Gas Fireplaces P/N 900298-01 REV. D 04/2016 Models Ce manuel est disponible en francais, simplement Scorpio35DEN Scorpio45DEN Scorpio40DEN en faire la demande. Numéro de la pièce 900298-03.. Scorpio35DEP Scorpio45DEP Scorpio40DEP ScorpioCD45DEN ScorpioCD35DEN ScorpioCD40DEN Report No.
Page 3 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 SAFETY AND YOUR FIREPLACE See attached color flyer for proper color representation DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is pro- vided with this appliance and shall be installed for the protection of children and other at-risk individuals.
Page 4 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 La sécurité et Safety and Your Seguridad y su votre foyer Fireplace chimenea All parts of your ¡Todas las partes de la Toutes les parties de votre IHP fireplace get chimenea IHP se ponen foyer IHP deviennent EXTRÊMEMENT CHAUDES !
Page 5 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 THANK YOU FOR YOUR PURCHASE. WE APPRECIATE YOUR BUSINESS! Please carefully read and follow all instructions in this manual. Pay special attention to all warnings and safety information. Following these safety, care, and operation instructions will help ensure many years of dependable and enjoyable service from your fireplace.
Page 6 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 IMPORTANT SAFETY INFORMATION Important Safety Informa- L’information de sûreté Información importante de tion importante seguridad 1. WARNING: Do not operate appliance 1. AVERTISSEMENT. Ne pas utiliser l’appareil 1. ADVERTENCIA: No opere el artefacto con el with the glass front removed, cracked si le panneau frontal en verre n’est pas en frente de vidrio quitado, agrietado o roto.
Page 7 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 APPLIANCE INSTALLATION, SERVICE, AND MAINTENANCE NOTICES WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult a qualified installer, service agency or the gas supplier.
Page 8 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 APPLIANCE OPERATION NOTICES These fireplaces are vented gas appliances. Do not burn wood or other material in these appliances. These appliances are designed to operate on natural gas or propane gas only. The use of other fuels or combinations of fuels will degrade the performance of this system and may be dangerous.
Page 9 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 INSTALLATION PACKAGING All models include The assembled vented gas fireplace heater is packaged with: • Literature Kit (envelope in bottom compartment containing Installation and Operation Instructions (this manual), Hot Glass Safety Flyer, and Safety-In-Operation Warning Labels) •...
Page 10 Innovative Hearth Products General Information Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 BTU Input Table 1 - Input Rate (BTU/HR), Gas Valves Natural Gas Propane Gas Models High Rate Low Rate High Rate Low Rate 35” Models 20,000 14,000 19,000 13,000 40”...
Page 11 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
Page 12 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 COLD CLIMATE INSULATION For cold climate installations, seal all cracks around your fireplace with noncombustible material and wherever cold air could enter the room. It is especially important to insulate outside chase cavity between studs and under floor on which fireplace rests, if floor is above ground level.
Page 13 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 MANUFACTURED HOME REQUIREMENTS This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. Cet appareil peut être installé dans une maison préfabriquée (mobile) déjà installée à demeure si les règlements locaux le permettent.
Page 14 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 VENT TERMINATION CLEARANCES These instructions should be used as a guideline and do not supersede local codes in any way. Install venting according to local codes, these instructions, the current National Fuel Gas Code (ANSI Z223.1/NFPA 54) in the USA or the current standards of CAN/CGA-B149.1 in Canada.
Page 15 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 7 - Horizontal vent termination clearances for buildings with combustible and noncumbustible exteriors Inside Corner Outside Corner Recessed Location See Table 6 Fixed Balcony with No Side Wall Balcony with Perpendicular Side Wall Openable Fixed Closed...
Page 16 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 MINIMUM CLEARANCES TO COMBUSTIBLES Fireplace And Vent Clearances The fireplace is approved with zero clearance to combustible materials on all sides (Table 8), with the following exception: The unit may not be recessed (allowance made for mantel legs / side trim in Figure 5). When the unit is installed with one side flush with a wall, the wall on the other side of the unit must not extend beyond the front edge of the unit (Figure 5).
Page 17 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 5 - Combustible Side Clearances Figure 6 - Mantel Height At 6” minimum side wall Mantel depth clearance, a At 6 in. minimum 20 (508) side wall clearance, combustible Top View of Top View of...
Page 18 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 INSTALLATION SEQUENCE The typical sequence of installation is outlined below; however, each installation is unique and may result in variations to the steps described. See the pages referenced in the following steps for detailed instructions. Framing 1.
Page 19 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 10 - Fireplace Framing Specifications Model Framing NOTE: Dimension “D” is the construction to be 10-1/2 required framing depth when 35-3/8 36-1/4 38-3/4 23-3/8 2 x 4, or larger. 35”...
Page 20 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Prepare the Fireplace Top Spacers 1. The two (2) 4” standoff spacers on top of the fireplace cabinet are shipped flat. Remove the screw adjacent to the detached end (Figure 7). 2.
Page 21 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Determining Vent Setup in the Combination Venting Unit Combination venting units are shipped with rear venting setup nearly ready for install. If this is the type of vent you require, remove all insulation packing and flue plug block off from rear venting and proceed with fireplace installation.
Page 22 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Rough in the Electrical Supply, if Needed As necessary, rough in the fireplace electrical supply per NEC and local codes. Place the Fireplace in the Framing and Secure NOTE: Nailing flanges, combustible members, and screw heads in areas directly adjacent to the nailing flanges are EXEMPT from the 1/2”...
Page 23 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Install the Vent Restrictor (if necessary) U-Shaped Vent Restrictor 1. Use the vent run descriptions in Figure 11 to determine if a vent restrictor is necessary. U-Shaped Vent 2. If necessary, assemble the vent restrictor and wing as detailed in Figures 11 and 14. Restrictor 3.
Page 24 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Connecting the Vent Pipe Secure Vent SV4.5 direct-vent system components are unitized concentric pipe components featuring positive twist ® lock connections (Figures 15–16, Page 23). All of the fireplaces covered in this document are fitted with collars having locking inclined channels.
Page 25 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Vent section length table Table 14 will assist calculating how many vent sections are needed for the planned vent configuration. When a vent section is engaged with another section, its effective length will be 1-1/2” shorter. Table 14 - Vent Section Length Nominal Section Nominal Section Length...
Page 26 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Clearance to combustibles Maintain the minimum clearance to combustibles (e.g., framing, attic, ceiling insulation, etc.). For all vertical runs: • 1” (26 mm) from all sides NOTE: Attic insulation shield (H3907, see Page 47) must be installed when blown or loose-fill insulation is used, and is required for all attic installations.
Page 27 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Vertical (Offset) Installation 1. Analyze the vent route and determine the number of vent sections and elbows required—See Effective Vent Length on Pages 23-24 for more information. Plan the venting so that a joint does not occur in the ceiling or roof joists.
Page 28 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 7. Change vent direction of horizontal/inclined run—Install the SV4.5E45 and SV4.5E90 elbows in the same manner as the straight vent sections. See Vent elbows on Page 23 for more information. 8.
Page 29 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Vertical Vent Figures/Tables NOTE: Secure Vent rigid vent pipe is shown in the figures; Secure Flex flexible vent pipe may also be used. ® ® NOTE: Rise per foot run ratios are acceptable all the way to level. For best results, maintain the horizontal/inclined run in a straight (no dips), slightly elevated plane of approximately 1/4”...
Page 30 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 17 - Top Vent—Two 90° Elbows Table 18 - Rear Vent—Three Elbows Table 19 - Top Vent—Three Elbows When using Secure Flex , use ® ceiling firestop/ Ceiling firestop/ spacer SF4.5VF.
Page 31 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Install the Horizontal Termination Vent System These instructions should be used as a guideline and do not supersede local codes in any way. Install venting according to local codes, these instructions, the current National Fuel Gas Code (ANSI-Z223.1) in the USA or the current standards of CAN/CGA-B149.1 in Canada.
Page 32 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 8. Change vent direction—At transition from or to a horizontal/inclined run, install SV4.5E45 or SV4.5E90 elbows in the same manner as the straight vent sections. The elbows feature a twist section to allow them to be routed about the center axis of their initial collar section to align with the required direction of the next vent run element.
Page 33 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 26 - Installing the Horizontal Termination To help minimize water infiltration Firestop/Spacer (SV4.5HF) shown Typical it is recommended that the Fire- Termination on the exterior side of the wall. It Shown stop/ Spacer (SV4.5HF) be installed may also be installed on the...
Page 34 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 20 - Venting Components Required for Various Exterior Wall Thicknesses, when using Typical Termination Kits Vent Components Required Exterior Wall Thickness Termination Kit Only 6 to 9-1/4” (152 to 235 mm) Termination Kit and 6”...
Page 35 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 23 - Top Vent—One 90° Elbow, Elbow Connection NOT at Fireplace H Maximum V Minimum feet meters feet meters 1.524 0.305 When using Secure Flex, 3.048 0.610 use Firestop/Spacer SF4.5VF.
Page 36 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Table 26 - Rear Vent—Three 90° Elbows H + H Maximum H Maximum V Minimum feet meters feet meters feet meters Wall firestop/spacer Wall Firestop/Spacer SV4.5HF ** 1.524 0.610 0.305 SV4.5HF** 3.048...
Page 37 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Vertical or Horizontal Venting Using Secure Flex Kits and Components ® When Secure Flex kits are used in a rear flue, horizontal termination installation, at least 1 ft of vertical rise is required. ®...
Page 38 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 f. Install three (3) screws 120° apart through the flexible vent and into the adaptor collar just below the gear clamp to provide additional security to the connection. 3. Route the flexible vent. NOTE: Ensure that the flexible vent is properly routed to provide the required clearance.
Page 39 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 30 - Wiring Diagrams—Electronic Gas Valves Ecoflow Pilot Burner 2 Main Burner Thermocouple Ground - Connector to Chassis Ground or Valve Body Thermocouple - To “S” Valve Terminal on Main Module Step Motor Dry -...
Page 40 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 31 - Wiring Diagram—Junction Box 4. Connect the black power supply wire to the lower outlet’s black and red pigtail lead (Figures 30 and 31). Connect the white power supply wire to the Green Ground - Green White...
Page 41 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 NOTE: A sediment trap is recommended in the gas piping within the home to prevent moisture and debris in the line from damaging the valve. NOTE: Secure all joints tightly using appropriate tools and sealing compounds (ensure propane resistant compounds are used in propane applications).
Page 42 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 33 - Electronic Pilot Igniter Pilot Hood Flame Rod Initialize the Remote Control System for the First Time 1. Install the four (4) AAA batteries. NOTE: Check the polarity (+/-) of the batteries and insert them into the battery bay as indicated on the battery cover.
Page 43 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Remote Control Display THERMOSTAT OFF LCD Displays: • MODE Zone: THERMO and OFF is displayed • ROOM TEMP Zone: Measured temperature is displayed • SET TEMP Zone: SET TEMP is displayed •...
Page 44 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Optional: Install the Firebox Liners 1. See Page 53 for instructions on Traditional Only: Installing the Firebox Liners. Traditional Fireplaces: Install the Logs, Volcanic Stone, and Glowing Embers 1. See Pages 54–56 for instructions on Installing the logs, volcanic stone, and glowing embers. Contemporary Fireplaces: Install Glass Media 1.
Page 45 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 If the air shutter opening is closed too far, sooting may develop. Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting results in black deposits forming on the logs, fireplace inside surfaces, and on exterior surfaces adjacent to the vent termination.
Page 46 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Install the Hood NOTE: All models must have a hood installed prior to operation. 1. Install the hood by sliding it into the slots on the lower edge of the cabinet top. NOTE: To install the non-combustible finish material flush with the top of the hood, the hood must be installed before installing the finish material.
Page 47 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 INSTALLER INSTRUCTIONS - ATTACHING SAFETY IN OPERATION WARNINGS It is the installer’s responsibility to ensure these warnings are properly affixed during installation. These warning labels are a critical step in informing consumers of safe operation of this appliance. ATTACHING SAFETY IN OPERATION APPOSITION DES MISES EN GARDE RELATIVES COLOCACIÓN DE ADVERTENCIAS DE SEGURIDAD...
Page 48 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 INSTALLATION ACCESSORIES Table 30 - Listed Secure Vent Components ® Cat. No. Model Description Cat. No. Model Description Horizontal Square Termination H1968 SV4.5HT-2 with Firestop/Spacer (H2246), H6183 SV4.5HF5 Firestop Spacer, 5”, rigid and Adaptor (74L61) H6184 SF4.5HF5...
Page 49 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 INSTALLATION ACCESSORIES (continued) Table 31 - Listed Secure Flex Components ® Cat. No. Model Description Cat. No. Model Description Vertical Termination for flex (flat 18 ft (5.49 m)* compressed flex 60L10 SF-18 to 6/12) with flex adaptor, section...
Page 50 Innovative Hearth Products Installation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 GAS CONVERSION KITS WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion, or the production of carbon monoxide may result;...
Page 51 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 OPERATION WARNING Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at risk individuals in the house.
Page 52 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 HOMEOWNER’S INSTRUCTIONS - ATTACHING SAFETY IN OPERATION WARNINGS ATTACHING SAFETY IN OPERATION WARN- APPOSITION DES MISES EN GARDE RELATIVES À COLOCACIÓN DE ADVERTENCIAS DE SEGURIDAD INGS LA SÉCURITÉ D’UTILISATION EN OPERACIÓN Votre foyer a été...
Page 53 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Burn-in Period The first few times this fireplace is operated, there will be an odor from the curing of paint and the burning off of the lubricants used in the manufacturing process. Depending on usage, the burn-in period may take a few hours or a few days.
Page 54 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Installing the Backup Batteries With a battery backup, electronic fireplaces can automatically switch to battery power. In the event of a power outage, this allows ON/OFF operation (without blower functionality). Install new batteries before every burn season. 1.
Page 55 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Install the Logs, Volcanic Stone, and Glowing Embers WARNING • Turn OFF all gas and electricity to the appliance before installing the volcanic stone, embers, and logs. • Do NOT install the logs until the appliance has been completely installed, the gas line connected and tested for leaks, and the initial burner operation has been confirmed.
Page 56 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Installing the Scorpio™ 35” logs The logs have notches/tabs to assist proper positioning. Upper logs rest on lower logs via notches/tabs. Proper log placement is critical to prevent sooting. Place the logs in the gaps between flame peaks, so they do not impinge the flames.
Page 57 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Installing the Scorpio™ Series 40” and 45” logs The logs have notches/tabs to assist proper positioning. Upper logs rest on lower logs via notches/tabs. Proper log placement is critical to prevent sooting. Place the logs in the gaps between flame peaks, so they do not impinge the flames.
Page 58 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Installing and removing the glass door WARNING • Do not attempt to substitute the materials used on these doors, or replace cracked or broken glass. • Handle this glass with extreme care! Glass is susceptible to damage—Do not scratch or handle roughly while reinstalling the glass door frame.
Page 59 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Installing the glass door 1. Visually inspect the gasket on the backside of the glass door. NOTE: The gasket surface must be clean, free of irregularities, and seated firmly. Ensure it is properly located. Make sure the bead is not rolled into the channel at the top of the door, but remains flat against the top of the glass.
Page 60 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 MAINTENANCE Refer to the Maintenance Schedule on Page 61 for maintenance tasks, procedures, frequency, and a listing of by whom the tasks should be performed. Always verify proper fireplace operation after servicing. WARNING Turn OFF gas and electrical power to the fireplace and allow it to cool before cleaning or servicing the appliance.
Page 61 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Inspecting the glass gasket Visually inspect the gasket on the backside of the glass door. The gasket surface must be clean, free of irregularities, and seated firmly. Cleaning the control compartment Keep the control compartment clean by vacuuming or brushing it out at least twice a year.
Page 62 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 MAINTENANCE SCHEDULE See the tables below for detailed information about required maintenance, both regular and annual. Table 36 - Maintenance Performed Annually—Before the Burning Season Maintenance Task Performed By Procedure Inspecting/Cleaning Burner, Logs, and Qualified Service Technician...
Page 63 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 ACCESSORY COMPONENTS Termination Shroud (fits H1968) Clear (standard) Blue Black Reflective Porcelain Firebox Liner Kits - Traditional Models Deluxe Termination Table 40 - Black Reflective Porcelain Guard Liner Kit (fits 94L10 and H1968) Cat.
Page 64 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 LIGHTING INSTRUCTIONS, ELECTRONIC ECOFLOW - ENGLISH FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
Page 65 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 LIGHTING INSTRUCTIONS, ELECTRONIC ECOFLOW - FRENCH POUR PLUS DE SÉCURITÉ LIRE AVANT DE METTRE EN MARCHE AVERTISSEMENT. Quiconque ne respecte pas à la lettre les instructions dans la présente notice risque de déclencher un incendie ou une explosion entraînant des dommages, des blessures ou la mort.
Page 66 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 LIGHTING INSTRUCTIONS, ELECTRONIC SIT - ENGLISH FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
Page 67 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 LIGHTING INSTRUCTIONS, ELECTRONIC SIT - FRENCH POUR PLUS DE SÉCURITÉ LIRE AVANT DE METTRE EN MARCHE AVERTISSEMENT. Quiconque ne respecte pas à la lettre les instructions dans la présente notice risque de déclencher un incendie ou une explosion entraînant des dommages, des blessures ou la mort.
Page 68 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 TROUBLESHOOTING Before troubleshooting, ensure that the fireplace main line gas shutoff valve and the wall switch are in the ON position. The following troubleshoots the fireplace only to an elementary level. For detailed remote and ignition system troubleshooting, refer to the instructions provided with the remote.
Page 69 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 REPLACEMENT PARTS Table 44 - Installer Replacement Parts 35” Models 40” Models 45” Models Description Catalog Number Catalog Number Catalog Number Black touch-up paint, powder coat exterior F1882 F1882 F1882 Blower Assembly 80L84...
Page 70 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 REPLACEMENT PARTS 33” Models 35” Models 40” Models 45” Models Catalog Catalog Catalog Catalog Number Number Number Number ECOFLOW PARTS Pilot Assembly, Ecoflow, Natural Gas J7935 J7935 J7935 J7935 Pilot Assembly, Ecoflow, Liquid Propane J7962 J7962...
Page 71 Innovative Hearth Products Operation Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Figure 54 - Replacement Parts WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. AVERTISSEMENT Risque de dommages ou de blessures si les pièces ne sont pas installées conformément à...
Page 72 Innovative Hearth Products Astria Brand Gas Fireplace ® Limited Lifetime Warranty THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria brand gas ﬁ replace ("Product") to be free from defects in materials and workmanship at ® the time of manufacture. The Product body and ﬁ rebox carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only.
Page 73 Innovative Hearth Products Installation and Operation Instructions Scorpio™ Series Direct-Vent Gas Fireplaces 900298-01, 04/2016 Astria.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed Type of gas fireplace uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
