P/N 126891-01 Rev.A 02/2014
P126891-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
f i r e - p a r t s . c o m
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in
a solid-fuel burning masonry or UL127 factory-built
fireplace, constructed of noncombustible material
and connected to a working flue. (See page 6 for
minimum flue opening.)
WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Installation and Operation Instructions
Astria
TM
PFS
Models
®
US
BlueRidge18MN
BlueRidge18MP
BlueRidge24MN
BlueRidge24MP
WARNING: This is a gas-fired heater. It uses air (oxy-
gen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be
provided. Refer to the National Fual Gas Codes, ANSI
Z233.1/NFPA 54, Section 5.3 for Combustion and
Ventilation.
Vented Gas Log Appliance
Acadia18MN
Acadia18MP
Acadia24MN
Acadia24MP
Sequoia18MN
Sequoia18MP
Sequoia24MN
Sequoia24MP
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Astria Fireplaces BlueRidge18MN
Summary of Contents for Astria Fireplaces BlueRidge18MN
- Page 1 Installation and Operation Instructions Astria Vented Gas Log Appliance P/N 126891-01 Rev.A 02/2014 Models ® BlueRidge18MN Acadia18MN Sequoia18MN BlueRidge18MP Acadia18MP Sequoia18MP BlueRidge24MN Acadia24MN Sequoia24MN BlueRidge24MP Acadia24MP Sequoia24MP P126891-01 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety ..............2 Troubleshooting ..........13 Local Codes............4 Specifications ............ 15 Product Identification ........... 4 Wiring Diagram ..........15 Unpacking............5 Technical Service..........15 General Information ..........5 Parts ..............16 Installation ............5 Replacement Parts ..........18 Operation ............ - Page 3 SAFETY Continued WARNING: Installed decora- DANGER: Carbon monoxide tive glass door enclosures must poisoning may lead to death! be fully opened when operating Carbon Monoxide Poisoning: Early signs this gas appliance. of carbon monoxide poisoning resemble the flu, with headaches, dizziness or nausea. If Due to high temperatures, the you have these signs, the log set may not be appliance should be located out...
-
Page 4: Local Codes
SAFETY bottom, you must open the vents before operating appliance. Continued 7. To reduce the creation of soot, follow the 1. This appliance, as supplied, is only for use instructions in Cleaning and Maintenance, with the type of gas indicated on the rating page 12. -
Page 5: Unpacking
UNPACKING CAUTION: Do not remove data plates from grate assembly. Data Carton Tray with Handles plates contain important warranty and safety information. 1. Remove log set by lifting tray handles. Set tray on floor. 2. Remove contents from side compart- ments (see Figure 2). - Page 6 INSTALLATION Continued CHECK GAS TYPE INSTALLING DAMPER CLAMP Use the correct gas type (natural or propane/ Secure the damper stop clam to the edge of LP) for your unit. If your gas supply is not the damper as shown in Figure 2. If for any correct, do not instal in fireplace.
- Page 7 INSTALLATION Continued For propane/LP units, the installer must IMPORTANT: Install equipment shutoff valve in supply an external regulator. The external an accessible location. The equipment shutoff regulator will reduce incoming gas pressure. valve is for turning on or shutting off the gas to You must reduce incoming gas pressure to the appliance.
- Page 8 INSTALLATION Continued CHECKING GAS CONNECTIONS 3. Check all joints from gas meter to equip- ment shutoff valve for natural gas or WARNING: Test all gas piping propane/LP supply to equipment shutoff valve for propane/LP (see Figure 6 or 7). and connections for leaks after Apply noncorrosive leak detection fluid to installing or servicing.
- Page 9 INSTALLATION Continued The pressure should be checked with the 3. Place fiber log pieces randomly on lava unit burning and set to High. Replace test rock and ember material around unit (see point plug or tighten test screw after pressure Figure 10).
-
Page 10: Operation
OPERATION The RF Millivolt valve control used on these A. This appliance has a pilot which must appliances allows you to turn the gas log set be lighted with a piezo ignitor. When on or off; use a timer to automatically operate lightning the pilot, follow these instruc- the log set;... -
Page 11: Inspecting Burners
OPERATION Continued 4. Wait five (5) minutes to clear out any gas. 5. Press MODE button until mode If you then smell gas STOP! Follow the shows in display window of transmitter/ safety information, page 10. If you don't remote. Press up or down key to change smell gas, go on to the next step. -
Page 12: Cleaning And Maintenance
INSPECTING BURNERS Continued Beech Mountain Log Set Little Leaf Oak Log Set Black Tupelo Log Set f i r e - p a r t s . c o m Figure 14 - Log Sets with Flame Patterns CLEANING AND MAINTENANCE If, after a period of use, the flames start to WARNING: Turn off the ap- exhibit unusual shapes and behavior or the... -
Page 13: Troubleshooting
TROUBLESHOOTING LED Failure Code Note: In normal operation, LED blinks once (No. of Blinks) Service Action every two seconds; also, LED will be on Replace valve. for one second after every valid command received by the receiver/valve' these are not Confirm stepper motor connection exists. - Page 14 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Pilot will not stay lit after 1. Defective pilot generator 1. Check pilot flame, it must carefully following the lighting (thermocouple) impinge on thermocouple instructions (see Figure 13, page 11). Clean and/or adjust pilot for maximum flame impinge- ment on thermocouple.
-
Page 15: Specifications
SPECIFICATIONS BlueRidge24MN BlueRidge24MP BlueRidge18MN BlueRidge18MP Acadia24MN Acadia24MP Acadia18MN Acadia18MP Sequoia24MN Sequoia24MP Sequoia18MN Sequoia18MP Btu (Variable) 45,000/67,000 43,000/65,000 41,000/56,000 42,000/51,000 Type Gas Natural Gas Only Propane/LP Only Natural Gas Only Propane/LP Only Ignition Piezo Piezo Piezo Piezo Manifold Pressure 3.5" - 1.6"W.C. -
Page 16: Parts
PARTS BlueRidge18MN Acadia18MN Sequoia18MN BlueRidge18MP Acadia18MP Sequoia18MP BlueRidge24MN Acadia24MN Sequoia24MN BlueRidge24MP Acadia24MP Sequoia24MP f i r e - p a r t s . c o m www.Astria.US.com 126891-01A... - Page 17 112799-01 Ember Flakes Kit • • • • GA6060 Lava Rock • • • • 26839 Rock Wool • • • • LOG SET ASSEMBLIES MODELS PART NO. BlueRidge24MN/P 115474-01 Sequoia24MN/P 115471-01 Acadia24MN/P 115473-01 BlueRidge18MN/P 115469-01 Sequoia18MN/P 115470-01 Acadia18MN/P 115472-01 www.Astria.US.com 126891-01A...
-
Page 18: Replacement Parts
REPLACEMENT PARTS When calling, have ready: Note: Use only original replacement parts. This will protect your warranty coverage for • your name parts replaced under warranty. • your address Contact authorized dealers of this product. • model and serial numbers of your heater If they can’t supply original replacement •... -
Page 19: Warranty
Innovative Hearth Products Superior™ Brand Gas Log Set Limited Three Year Warranty THE WARRANTY Innovative Hearth Products Limited Three Year Warranty ("IHP") warrants your Superior™ brand Gas Log Set ("Product") to be free from defects in materials and workmanship at the time of manufacture. The logs and grate carry the Limited Three Year Warranty. After installation, if covered components manufactured by IHP are found to be defec- tive in materials or workmanship during the Limited Three Year Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components. - Page 20 WARRANTY KEEP THIS WARRANTY Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. f i r e - p a r t s . c o m www.Astria.US.com 126891-01A...
- Page 21 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ f i r e - p a r t s . c o m ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________...
- Page 22 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ f i r e - p a r t s . c o m ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________...
- Page 23 NOTES _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ f i r e - p a r t s . c o m ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________...
- Page 24 f i r e - p a r t s . c o m 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 126891-01 1-800-655-2008 Rev. A www.IHP.US.com 02/14 P126891-01...
