BEINAT SG800/duct Manual

The SG800/duct is born from the elegance and prestige that has always distinguished BEINAT S.r.l. and from the
home fitness concept. The device has the capacity of controlling, the presence of various types of explosive gas,
such as Methane, LPG, Hydrogen
Through innovative technology advances, the probe is suitable to civil use, industrial use and car parks.
The probe has two danger levels:
1 st LEVEL, pre-alarm. This was set at 13% of L.E.L. (200ppm)
2 nd LEVEL, main alarm. This was set at 20 % of L.E.L. (300ppm)
The probe is managed by a microprocessor which not only supplies an alarm signal to the control unit connected
to it, but also allows execution of a self-diagnosis and therefore an AUTOMATIC CALIBRATION, in order to always
have the maximum detection accuracy.
The self-calibration means the probe adapts in harsh and variable temperature environments, avoiding false alarms
due to anomalous events.
The probe has a 0 ÷ 20 % L.E.L. linear output conforming to the 4 ÷ 20mA standard, for which can be connected
with one of BEINAT's industrial control units.
Instrument of testing TS1008
To facilitate the reading of the functional parameters of the probe as well as the
control of annual operating, the BEINAT S.r.l.
The tester allows to read all the data in the memory of the probes eand by serial
transmission, it prints the ticket that confirms the testing data, certifying your own work.
Important:
Assembly / maintenance of the appliance must be carried out by qualified personnel and in accordance with
applicable laws and regulations.
The manufacturer assumes no responsibility for the use of products that have to comply with particular
environmental and / or installation standards.
Important note
Before connecting the equipment, it is recommended that you read the instruction manual carefully and keep
it for future reference. It is also recommended to perform the electrical connections correctly as per enclosed
drawings, observing the instructions and the Standards.
N.B. Refer to the documentation in all cases where the symbol is on the side

Installation and
user guide
Air Duct Gas Sensor SG800/duct
has built a new portable tester TS1008.
Install in a safe area
No ATEX
CONFORMITY
Compliant EN 60079-29-1
Installation EN 60079-29-2
Reports issued by TUV Italia
Electric connections also available on
Channel: Beinat gas solutions
Belonging to
V. R4
EN 50270
EN 61010-1
