Regency Fireplace Products Classic i2450-2 Manual

Wood insert

Hide thumbs Also See for Classic i2450-2:

Download this manual

Model

Maximum Cordwood BTU's

EPA g/hr

Efficiency (EPA HHV)*

Efficiency (EPA LHV)

Flue Size

US Biomass Tax Rebate Eligible

Maximum Log Size

Firebox Size

*US Biomass Tax Rebate eligibility is based on the HHV value being

greater than or equal to 75%.

UNIT DIMENSIONS

Classic

i2450-2 Wood Insert

™

i2450-2

75,000 BTU's

1.6 g/hr

70.3%

76%

6" (152mm)

18" (457 mm)

2.3 cu.ft.

6" (152 mm)

From back of faceplate (not shown) to fuel door opening 7"

(178mm)

i2450-2 Classic

Wood Insert |

™

Need help?

Do you have a question about the Classic i2450-2 and is the answer not in the manual?

Page 1 Classic i2450-2 Wood Insert ™ Model i2450-2 Maximum Cordwood BTU’s 75,000 BTU’s EPA g/hr 1.6 g/hr Efficiency (EPA HHV)* 70.3% Efficiency (EPA LHV) Flue Size 6" (152mm) US Biomass Tax Rebate Eligible Maximum Log Size 18” (457 mm) Firebox Size 2.3 cu.ft.
Page 2 CLEARANCES MASONRY FIREPLACE CLEARANCES The minimum required clearances to combustible materials when installed into a masonry fireplace are listed below. Unit Adjacent Mantle ** Side Minimum Minimum To Top of Unit From Side of Faceplate Width Side Wall (to Top of Facing Facing Hearth...
Page 3 INSTALLATION INTO A CHIMNEY SPECIFICATIONS DRAFT MASONRY FIREPLACE Before installing, check and clean your chimney Draft is the force which moves air from the system thoroughly. If in doubt about its condition, appliance up through the chimney. The amount Regency Inserts are constructed with the highest seek professional advice.
