ROW UNIT MOUNTED DOUBLE DISC FERTILIZER OPENER
YETTER MANUFACTURING CO.
FOUNDED 1930
Colchester, IL 62326-0358
Toll free: 800/447-5777
309/776-3222 (Fax)
Website:
www.yetterco.com
E-mail:
info@yetterco.com
2962 R.U.M.D.D.F.O.
OPERATOR'S MANUAL
PARTS IDENTIFICATION
2565-731_REV_M • 08/2024
1
Advertisement
Related Manuals for Yetter 2962 R.U.M.D.D.F.O.
Summary of Contents for Yetter 2962 R.U.M.D.D.F.O.
- Page 1 2962 R.U.M.D.D.F.O. ROW UNIT MOUNTED DOUBLE DISC FERTILIZER OPENER OPERATOR’S MANUAL PARTS IDENTIFICATION 2565-731_REV_M • 08/2024 YETTER MANUFACTURING CO. FOUNDED 1930 Colchester, IL 62326-0358 Toll free: 800/447-5777 309/776-3222 (Fax) Website: www.yetterco.com E-mail: info@yetterco.com...
- Page 4 BOLT TORQUE Mounting bolts and hardware Before operating the 2962 R.U.M.D.D.F.O. for the first time, check to be sure that all hardware is tight. Check all hardware again after approximately 50 hours of operation and at the beginning of each planting season. All hardware used on the 2962 R.U.M.D.D.F.O.
- Page 5 NOTICE: failure to properly set the planter frame height and levelness can result in less than successful operation of the planter and the Yetter product and may result in damaged equipment. All operators should read and thoroughly understand the instructions given prior to using the Yetter product.
- Page 6 PLANTER ADJUSTMENT...
- Page 7 PLANTER ADJUSTMENT...
- Page 8 ADJUSTING DEPTH Row Unit Mounted Double-Disk Fertilizer openers will perform in conventional, reduced and light no-till conditions but are not recommended for double-crop or tough no-till conditions. The double-disk design limits penetration in no-till or double-crop conditions. Single disk openers are better suited for no-till conditions.
- Page 9 ADJUSTING FERTILIZER TO SEED FURROW...
- Page 10 MAINTENANCE...
- Page 14 MAINTENANCE...
- Page 15 MAINTENANCE Lubrication Symbols Lubricate with grease at hourly interval indicated on symbol. Lubrication Intervals NOTICE: The recommended service intervals are based on normal conditions; severe or unusual conditions may require more frequent lubrication. Perform each lubrication and service procedure at the beginning and end of each season. Clean grease fittings before using grease gun, to avoid injecting dirt and grit into the bearing.
- Page 17 Notes:...
- Page 18 PARTS IDENTIFICATION 2962-122 RH LIQUID ASSEMBLY MFG 11-2015 TO 6-2016...
- Page 19 PARTS IDENTIFICATION 2962-126 LH LIQUID ASSEMBLY MFG 11-2015 TO 6-2016...
- Page 20 PARTS IDENTIFICATION...
- Page 21 PARTS IDENTIFICATION...
- Page 22 PARTS IDENTIFICATION 2962-123 NOTCHED BLADE ASSEMBLY ITEM PART # DESCRIPTION 2520-159 ¼-20 HEX FLANGE NYLON INSERT NUT, GR F 2550-328 PLANTER COULTER BEARING 2570-204 ¼-20 X 1.37 BHSCS, GR 5 ZP 2571-283 .138 X 12.5 NOTCHED BLADE 2962-342 DOUBLE DISC HUB (2016-OLDER) MANUFACTURED 11/15 –...
- Page 23 PARTS IDENTIFICATION 2962-125 OPENER BLADE ASSEMBLY ITEM PART # DESCRIPTION 2520-159 ¼-20 HEX FLANGE NYLON INSERT NUT, GR F 2550-328 PLANTER COULTER BEARING 2570-204 ¼-20 X 1.37 BHSCS, GR 5 ZP 2571-284 .138 X 12.5 OPENER BLADE 2962-342 DOUBLE DISC HUB (2016-OLDER) MANUFACTURED 11/15 –...
- Page 24 PARTS IDENTIFICATION 2962-124 DOUBLE DISC HUB ASSEMBLY...
- Page 25 PARTS IDENTIFICATION...
- Page 26 PARTS IDENTIFICATION 2962-005 UMDDFO RM ASSEMBLY...
- Page 28 PARTS IDENTIFICATION MFG 04-2004 TO 10-2007...
- Page 29 PARTS IDENTIFICATION MFG 10-31-07 TO 07-2009...
- Page 30 PARTS IDENTIFICATION MFG 04-2004 TO 10-2007...
- Page 31 PARTS IDENTIFICATION MFG 10-31-07 TO 07-2009...
- Page 32 PARTS IDENTIFICATION 2962-104 UMDDFO ASS’Y RH (SMOOTH) SHOWN 2962-105 UMDDFO ASS’Y LH (SMOOTH) (Ref. Only – Sub 2962-334 Tube & (2) 2962-335 Clamps) MANUFACTURED 01-2010 TO 12-2010...
- Page 33 PARTS IDENTIFICATION 2962-106 UMDDFO ASS’Y RH (NOTCHED) SHOWN 2962-107 UMDDFO ASS’Y LH (NOTCHED) (Ref. Only – Sub 2962-334 Tube & (2) 2962-335 Clamps) MANUFACTURED 01-2010 TO 12-2010...
- Page 34 PARTS IDENTIFICATION...
- Page 35 PARTS IDENTIFICATION MANUFACTURED 01-2011 TO 06-2015...
- Page 36 2565-731_REV_M 08/2024...
