DESCRIPT ID
Modulating 3800
Boiler E
Modulating 3900
Boiler F
Modulating 4000
Boiler G
Modulating 4100
Boiler H
Modulating 4200
Boiler I
Modulating 4300
Boiler H
Modulating 4400
Boiler K
Modulating 4500
Boiler L
Modulating 4600
Boiler M
Modulating 4700
Boiler N
Modulating 4800
Boiler O
Modulating 4900
Boiler P
059102-00 REV. C
OBJECT
VALUE NAME
TYPE
Analog Read MODE
Only
Analog Read MODF
Only
Analog Read MODG
Only
Analog Read MODH
Only
Analog Read MODI
Only
Analog Read MODJ
Only
Analog Read MODK
Only
Analog Read MODL
Only
Analog Read MODM
Only
Analog Read MODN
Only
Analog Read MODO
Only
Analog Read MODP
Only
VALUE VALUE
UNITS
MIN MAX
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
Percent 0 100
22 BACNET
DEFINITION
Modulation = 0%, 100%,
Staging: On/Off = 0%, 100%,
2-Stage = 0%, 10%, 55%,
3-Stage = 0%, 10%, 30% , 55%,
4-Stage = 0%, 10%, 30%,
55%, 80%
|
