STARTUP SETTINGS
PROGRAM CHANGE SETTINGS
To be able to change the Mini-MOD-CNC settings the PROGRAM/RUN Switch must be
set to Program. The switch is located under the Enclosure Wiring Cover for security. The
Enclosure Wiring Cover can be secured using a lock.
STARTUP SEQUENCE
Button: MENU/<System Startup>
• When powered, the Mini-MOD-CNC performs a self diagnostics-test on its components.
• On the first power up, the System Startup screen will appear after the initialization is
complete. If it doesn't, the Mini-MOD-CNC has already been configured.
• The System Startup menu sets the main parameters that relate to the heating application.
These settings must be set by the installer.
SENSOR TYPE
Reset °F, Reset °C, EMS °F, EMS °C
Button: MENU/<System Startup>/.../Sensor type
• The same Heat-Timer temperature sensor can display in either °F or °C.
• If any of the Reset options is selected, the control will use outdoor reset to calculate the
Target Temperature.
• If any of the EMS options is selected, the control will require the use EMS 4–20mA
Interface (P/N 926741-00).
• Selecting any of the °F options will display all temperatures in degrees Fahrenheit.
• Selecting any of the °C options will display all temperatures in degrees Celsius.
