ELITE SERIES BACNET PICS STATEMENT
PRODUCT
ELITE Series BACnet Option
VENDOR
Heat-Timer
PRODUCT DESCRIPTION
Various controls for heating applications for multiple boilers. Includes Mini MOD, Mini MOD-CNC, SQ-8T ELITE, SQ-8S ELITE and
SQ-MOV ELITE. (see https://www.heat-timer.com for more information)
BACNET STANDARDIZED DEVICE PRO ILE (ANNEX L)
PRODUCT
ELITE Series BACnet Upgrade
SUPPORTED BIBBS (ANNEX K)
SUPPORTED BIBBS
DS-RP-B
DS-WP-B
DM-DDB-B
DM-DOB-B
DM-DCC-B
STANDARD OBJECT TYPES SUPPORTED
OBJECT TYPE
Analog Value
Binary Value
Multi-State Value
Device
DATA LINK LAYER OPTIONS (ANNEX J)
PRODUCT
ELITE Series BACnet Upgrade
SEGMENTATION CAPABILITY
SEGMENTATION TYPE
Able to transmit segmented messages
Able to receive segmented messages
DEVICE ADDRESS BINDING
PRODUCT
ELITE Series BACnet Upgrade
|
50 HEAT-TIMER CORP.
MODEL NUMBER PROTOCOL REVISION
Varies 1.5
VENDOR ID ADDRESS AND PHONE
248 20 New Dutch Lane, Fairfield, NJ 07004 • (973)575-4004
DEVICE PRO ILE
BACnet Application Specific Controller (B-ASC)
BIBB NAME
Data Sharing-ReadProperty-B
Data Sharing-WriteProperty-B
Device Management-Dynamic Device Binding-B
Device Management-Dynamic Object Binding-B
Device Management-Device Communication Control-B
CREATABLE
No
No
No
No
DATA LINK
BACnet MS/TP
SUPPORTED
No
No
STATIC BINDING SUPPORTED
No
SOFTWARE VERSION
2.0
DELETABLE
No
No
No
No
OPTIONS
Baud Rates: 9600, 19200, 38400
WINDOW SIZE (MS/TP PRODUCT LIMITED TO 1)
CHARACTER SETS
PRODUCT
ELITE series BACnet Controls
22 BACNET
FIRMWARE VERSION
2.0
CHARACTER SETS
Supported ANSI X3 4
059102-00 REV. C
