DC40 LED Driver
1.6 Components
Front Panel
Callout Feature
1 LED Switch
2 Mode Select Switch
3 Status LED
4 Mode LEDs
Rev. B, November 28, 2024
Figure 3 Front Panel of the DC40 LED Driver
Push to Select One of the Three
a
Blinking Yellow: "Standby" State During
Blinking Green: "Active" State During
LEDs for Indication of Active Mode: CW, TTL or MOD
Table 3 Front Panel of the DC40 LED Driver
Front Panel
Description
Push to Switch The LED On/Off
Modes
"Standby"
LED for Indication of Device Status:
Red: "Error" State
Yellow: "Standby" State
Green: "Active" State
Chapter 1 Introduction
when the DC40 LED Driver is in
Remote Control
Remote Control
