Texas Instruments LMK03806 User Manual

Texas Instruments LMK03806 User Manual

Ultra-low jitter clock generator with 14 outputs evaluation board

Advertisement

Quick Links

LMK03806 Evaluation Board
User's Guide
November 2013
SNAU075A

Advertisement

loading
Need help?

Need help?

Do you have a question about the LMK03806 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments LMK03806

  • Page 1 LMK03806 Evaluation Board User's Guide November 2013 SNAU075A...
  • Page 2 LMK03806 Ultra-low Jitter Clock Generator with 14 Outputs Evaluation Board Operating Instructions SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 3   SCHEMATICS ......................27     PCB LAYERS STACKUP ..................35     PCB LAYOUT ......................36   APPENDIX A: EVM SOFTWARE AND COMMUNICATION: INTERFACING UWIRE ... 41 November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 4 Figure 18 - LMK03806 Device Schematic ........................28   Figure 19 - Outputs, (OSCout, CLKout0/1/2/3) Schematics ..................29   Figure 20 - LMK03806 Clock Outputs 4 through 7 Schematics ................. 30   Figure 21 - LMK03806 Clock Outputs 8 through 11 Schematics ................31  ...
  • Page 5 LMK03806B Texas Instruments CodeLoader software can be used to program the internal registers of the LMK03806B device through the USB2ANY-uWire interface. The CodeLoader software will run on a Windows 7 or Windows XP PC and can be downloaded from http://www.ti.com/tool/codeloader...
  • Page 6 5.0 V Program with CodeLoader (LDO) Be sure to press ‘Ctrl - L’ For interfacing the board please see Appendix A Laptop or PC Figure 1: Quick Start Diagram SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 7 CodeLoader saves the state of the selected LMK03806B device when exiting the software. To ensure a common starting point, the following modes listed in Table 2: Default CodeLoader Modes for LMK03806 may be restored by clicking “Mode” and selecting the appropriate device configuration, as shown in Figure 2 in the case of the LMK03806B device.
  • Page 8 For this example, the LMK03806B is chosen. Selecting the device does cause the device to be programmed. SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 9 5. Program/Load Device Assuming the Port Setup settings are correct, press the “Ctrl+L” shortcut or click “Keyboard Controls”  “Load Device” from the menu to program the device to the current state of the newly loaded LMK03806 file. Figure 3: Loading the Device Once the device has been initially loaded, CodeLoader will automatically program changed registers so it is not necessary to re-load the device upon subsequent changes in the device configuration.
  • Page 10 A balun may also be used. Ensure CLKoutX and CLKoutX* states are complementary, i.e.: Norm/Inv or Inv/Norm. 5. The phase noise may be measured with a spectrum analyzer or signal source analyzer. SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 11 Margin Loop Bandwidth Note: PLL Loop Bandwidth is a function of K, Kvco, N as well as loop components. Changing K and N will change the loop bandwidth. November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 12 RF test equipment. All LVPECL clock outputs are source-terminated using 240-ohm resistors. If an output pair is programmed to LVCMOS, each output can be independently configured (normal, inverted, or off/tri-state). SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 13 On-board LDO regulators and 0  resistor options provide flexibility to supply and route power to various devices. See schematics for more details. November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 14 A SYNC event can also be programmed by toggling the SYNC_POL_INV bit in the Bits/Pins tab in CodeLoader. Refer to the LMK03806 Datasheet section “Clock Output Synchronization” for more information. SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 15 50-ohm cables to minimize external sources of skew or other errors/distortion that may be introduced if using oscilloscope probes. November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 16 The Pin Configuration field is hardware dependent and normally does not need to be changed by the user. Figure 7: Port Setup Tab shows the default settings. SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 17 Clicking on the cyan-colored PLL block that contains R, PDF and N values will bring the PLL tab into focus where these values may be modified, if needed. November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 18 VCO Frequency (MHz) Internal VCO Frequency should be within the allowable range of the LMK03806B device. This value is calculated as: VCO Frequency = PLL PDF * (PLL_N * PLL_P). SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 19 Changes made on this tab will be reflected in the Clock Outputs tab. The VCO Frequency should conform to the specified internal VCO frequency range for the LMK03806B. November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 20 Table 6: Datasheet to PCB Silkscreen Updates Datasheet Name PCB Silkscreen Identifier Readback (pin 27) Status0 Ftest/LD (pin 33) Status1 GPout0 (pin 62) Status2 GPout1 (pin 63) Status3 SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 21 Clock Outputs tab. PLL_C4_LF SYNC Sets these pins on the uWire header to logic high Program Pins (checked) or logic low (unchecked). TRIGGER November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 22 By clicking in the “bit field” it is possible to manually change the value of registers by typing ‘1’ and ‘0.’ SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 23 100 kHz -114.2 1 MHz -136.6 10 MHz -150.6 20 MHz -151.3 RMS Jitter (fs) 12 kHz to 20 MHz RMS Jitter (fs) 100 Hz to 20 MHz November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 24 Clock Outputs (CLKout The LMK03806 Family features programmable LVDS, LVPECL, and LVCMOS buffer modes for the CLKoutX and OSCout0 output pairs. The OSCout1 output pair has a LVPECL buffer. Included below are various phase noise measurements for each output format.
  • Page 25 Figure 13: LMK03806B div8 CLKout LVPECL Phase Noise Figure 14: LMK03806B div8 CLKout LVDS Phase Noise November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 26 Figure 15: LMK03806B div8 CLKout LVCMOS Phase Noise SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 27 Designed for: Evaluation Customer Mod. Date: 11/28/2011 Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this Project: LMK038xx Evaluation Board specification or any information contained therein. Texas Instruments and/or its licensors do not Sheet Title:...
  • Page 28 Designed for: Evaluation Customer Mod. Date: 11/30/2011 Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this Project: LMK038xx Evaluation Board specification or any information contained therein. Texas Instruments and/or its licensors do not Sheet Title:...
  • Page 29 Designed for: Evaluation Customer Mod. Date: 11/28/2011 Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this Project: LMK038xx Evaluation Board specification or any information contained therein. Texas Instruments and/or its licensors do not Sheet Title:...
  • Page 30 Designed for: Evaluation Customer Mod. Date: 11/28/2011 Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this Project: LMK038xx Evaluation Board specification or any information contained therein. Texas Instruments and/or its licensors do not Sheet Title:...
  • Page 31 Designed for: Evaluation Customer Mod. Date: 11/28/2011 Texas Instruments and/or its licensors do not warrant the accuracy or completeness of this Project: LMK038xx Evaluation Board specification or any information contained therein. Texas Instruments and/or its licensors do not Sheet Title:...
  • Page 32 LED 2.8X3.2MM 565NM Lumex SML-LX2832GC GRN CLR SMD Opto/Compon ents Inc. CONN TERM BLK PCB Weidmuller 1594540000 5.08MM 2POS OR RES, 620 ohm, 5%, 0.1W, R2_LF Vishay-Dale CRCW0603620RJNEA 0603 SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 33 Kemet C0603C471K5RACTU +/-10%, X7R, 0603 CAP, CERM, 0.1uF, 25V, C50, C52, C59 Kemet C0603C104K3RACTU +/-10%, X7R, 0603 CAP, CERM, 1uF, 25V, +/- C63, C65 08053D105KAT2A 10%, X5R, 0805 November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 34 R67, R68, R69, R70 RES, 1.00k ohm, 1%, 0.1W, R102 Vishay-Dale CRCW06031K00FKEA 0603 FB, 1000 ohm, 600 mA, R82, R83 Murata BLM18HE102SN1D 0603 Y1, Y2 DNP_XTAL, ECS-200- 20-30B-DU SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 35 FR4 (Er = 4.8) 19 mil RF Ground plane [LMK03806ENG.G1] FR4 (Er = 4.8) 14.5 mil Power plane #1 [LMK03806ENG.G2] 19 mil Bottom Layer [LMK03806ENG.GBL] Figure 21: PCB Stackup November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 36 16. PCB Layout Figure 22: Layer 1 - Top SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 37 Figure 23: Layer 2 – RF Ground Plane November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 38 Figure 24: Layer 3 – Vcc Planes SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 39 Figure 25: Layer 4 - Bottom November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 40 Figure 26: Top and Bottom (Composite) SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
  • Page 41 OPTION 1 Open Codeloader.exe  Click “Select Device”  Click “Port Setup” tab  Click “LPT” (in Communication Mode) OPTION 2 November 2013 LMK3806 Evaluation Board SNAU075A Copyright © 2013, Texas Instruments Incorporated...
  • Page 42 Open Codeloader.exe  Click “Select Device”  Click “Port Setup” Tab  Click “USB” (in Communication Mode) *Remember to also make modifications in “Pin Configuration” Section according to Table above. SNAU075A LMK3806 Evaluation Board November 2013 Copyright © 2013, Texas Instruments Incorporated...
