Page 1 of 4

ECC0416R

FITTING INSTRUCTIONS FOR ECC0416R

HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE

OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY

O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT

LEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING

IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS

OR HAVE FITTED BY A QUALIFIED TECHNICIAN.

LEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF

MOUNTING TO THE BIKE

N THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS

THESE RUBBER WASHERS CAN BE THROWN AWAY

DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:

WWW.RG-RACING.COM

R&G Racing

Unit 1, Shelley's Lane, East Worldham, Alton, Hampshire, GU34 3AQ

Tel: +44 (0)1420 89007 Fax: +44 (0)1420 87301

www.rg-racing.com

Email:

info@rg-racing.com

Need help?

Do you have a question about the ECC0416R and is the answer not in the manual?

Page 1 Page 1 of 4 ECC0416R FITTING INSTRUCTIONS FOR ECC0416R HIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE OME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY O NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
Page 2 0 BOLT = 40Nm M12 BOLT = 40Nm LEGEND ITEM NO. DESCRIPTION ITEM 1 ECC0416R ENGINE CASE COVER INCLUDING FITTED SPACERS ITEM 2 M6 x 1.00 x 40mm CAP HEAD BOLTS ITEM 3 M6 x 1.00 x 45mm CAP HEAD BOLT FITTING DIAGRAM R&G Racing...
Page 3 • Ensure the pre-fitted threaded spacers in the casing are hand tight against the inside of the ECC0416R Engine Case Cover (Item 1). • Offer up the R&G cover to the engine and carefully fit it over the casing. Ensure that the bolt holes are lined up with the holes in the engine casing, and then push on until it bottoms out.
Page 4 Page 4 of 4 ECC0416R defect arises from accident or neglect. Other than identified above and subject to R&G not limiting its liability for causing death and personal injury, it shall not be liable for indirect or consequential loss and otherwise its liability shall be limited to the amounts paid by the Buyer for the Products or the fitting or service concerned.
