No.
Description
35
Auxiliary Panel Header (AUX_PANEL1)
36
Speaker Header (SPEAKER1)
37
USB 2.0 Header (USB_1_2)
38
Non Maskable Interrupt Button (NMI_BTN1)
39
OCP3 +12VSB Power Jumper (+12VSB_SEL1)
40
Thermal Sensor Header (TR1)
41
SPI TPM Header (TPM_BIOS_PH1)
42
BIOS Swap Override Jumper (BIOS_SWAP_OVERRIDE1)
43
ME Recovery Jumper (ME_RECOVERY1)
44
Switch SATA and PCIE Jumper (OCUSW_1)
45
BMC SMBus Header (BMC_SMB1)
46
Intelligent Platform Management Bus Header (IPMB1)
47
Password Reset Jumper (PASSWORD_CLEAR1)
48
PCI Express 4.0 x16 Slot (PCIE1)
49
OCP 3.0 Gen5 x16 NIC Slot (OCP1)
50
M-key M.2 Socket (M2_1) (Type 2280/2260)
51
PCI Express 5.0 x16 Slot (PCIE6)
52
CPU PECI Mode Jumper (PECI1)
53
LGA 4677 CPU Socket (CPU0)
*For DIMM installation and configuration instructions, please see p.20 (Installation of Memory Modules
(DIMM)) for more details.
