SPC741D8HM3
User Manual
Version 1.0
Published April 2023
Copyright©2023 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPC741D8HM3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK SPC741D8HM3

Summary of Contents for ASROCK SPC741D8HM3

  • Page 1 SPC741D8HM3 User Manual Version 1.0 Published April 2023 Copyright©2023 ASRock Rack INC. All rights reserved.
  • Page 2 (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 INTEL END USER SOFTWARE LICENSE AGREEMENT IMPORTANT - READ BEFORE COPYING, INSTALLING OR USING. LICENSE. Licensee has a license under Intel’s copyrights to reproduce Intel’s Software only in its unmodified and binary form, (with the accompanying documentation, the “Software”) for Licensee’s personal use only, and not commercial use, in connection with Intel-based products for which the Software has been provided, subject to the following conditions: (a) Licensee may not disclose, distribute or transfer any part of the Software, and You agree...
  • Page 4 If you require assistance please call ASRock Rack Tel : +886-2-55599600 ext.123 (Standard International call charges apply)
  • Page 5 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.

  • Page 6: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU and Heatsink Installing Memory Modules (DIMM) 2.4.1 Memory Support 2.4.2 Memory Configurations Expansion Slots (PCI Express Slots) Jumper Setup Onboard Headers and Connectors...
  • Page 7 3.1.2 Navigation Keys Main Screen 3.2.1 Motherboard Information 3.2.2 Processor Information 3.2.3 Memory Information Advanced Screen 3.3.1 CPU Configuration 3.3.2 Platform Power Configuration 3.3.3 DRAM Configuration 3.3.4 Chipset Configuration 3.3.5 Storage Configuration 3.3.6 NVMe Configuration 3.3.7 ACPI Configuration 3.3.8 USB Configuration 3.3.9 Super IO Configuration 3.3.10 Serial Port Console Redirection 3.3.11 H/W Monitor...
  • Page 8 3.4.1 BMC Network Configuration 3.4.2 System Event Log 3.4.3 BMC Tools Security 3.5.1 Key Management Event Logs Boot Screen Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 9: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 10: Specifications

    1.2 Specifications SPC741D8HM3 Physical Status Form Factor Half-Width Dimension 6.6” x 17” (167.64 x 431.80 mm) Processor System Supports 5 and 4 Gen Intel® Xeon® Scalable processors Socket Single Socket E (LGA 4677) Thermal Design 350W Power (TDP) Chipset Intel® C741...
  • Page 11 AMI UEFI BIOS; 512Mb SPI Flash ROM Features Plug and Play (PnP), ACPI 4.0 and above compliance wake up events, SMBIOS 3.4 and above , ASRock Rack Instant Flash Internal Connectors/Headers PSU Connector 3 Micro-Hi (8-pin, 12V), 1 (19-pin, CM Board Standby Power...
  • Page 12 LED Indicators Standby Power 1 (5VSB) Fan Fail LED BMC Heartbeat Supported OS Microsoft® Windows® - Server 2022 (64bit) Linux® - Red Hat Enterprise Linux Server 8.4 (64bit)/8.5 (64bit)/9.2 (64bit) - SUSE Enterprise Linux Server 15 SP3 (64bit) - Ubuntu 21.10 (64bit)/22.04.2 (64bit) Hypervisor: - VMWare®...

  • Page 13: Unique Features

    . With this utility, you can press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 14: Motherboard Layout

    1.4 Motherboard Layout 16.8cm (6.6in) 8.1cm (3.2in) IPMI_LAN1 USB 3.2 Gen1 B: USB1 ASPEED AST2600 OCP1 CPU0...
  • Page 15 SPC741D8HM3 Description Password Reset Jumper (PASSWORD_CLEAR1) Non Maskable Interrupt Button (NMI_BTN1) Flash Security Jumper (FLASH_SEC_OVERRIDE1) BIOS Swap Override Jumper (BIOS_SWAP_OVERRIDE1) Front VGA Header (FRNT_VGA) PCI Express 5.0 x16 Slot (PCIE1) Thermal Sensor Header (TR1) OCuLink Connector (2 SATA 6Gb/s) (OCU2)
  • Page 16 Description Backplane PCI Express Hot-Plug Connector (CPU0_HSBP1) System Fan Connector (FAN3) System Fan Connector (FAN4) Micro-Hi Power Connector (12VCON2) CM Board Standby Power Header (CM_SB_R) PSU SMBus Header (PSU_SMB1) Clear CMOS Pad (CLRMOS1) System Panel Header (PANEL1) Auxiliary Panel Header (AUX_PANEL1) USB 3.2 Gen1 Header (USB3_3_4) 2 x 288-pin DDR5 DIMM Slots (DDR5_F1, DDR5_H1)* Thumbscrew...

  • Page 17: Onboard Led Indicators

    SPC741D8HM3 1.5 Onboard LED Indicators...
  • Page 18 Item Status Description BMC_HB1 Green BMC heartbeat LED LED_FAN5 FAN5 failed LED_FAN1 FAN1 failed LED_FAN6 FAN6 failed LED_FAN2 FAN2 failed LED_FAN7 FAN7 failed LED_FAN8 FAN8 failed LED_FAN3 FAN3 failed LED_FAN4 FAN4 failed SB_PWR1 Green STB PWR ready CPU_CATERR1 CPU CATERR error...

  • Page 19: I/O Panel

    SPC741D8HM3 1.6 I/O Panel No. Description No. Description UID Switch (UID1) LAN RJ-45 Port (IPMI_LAN1)* USB 3.2 Gen1 Ports (USB3_1_2) Mini Display Port (VGA1) LAN Port LED Indications *There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

  • Page 20: Block Diagram

    1.7 Block Diagram...

  • Page 21: Chapter 2 Installation

    SPC741D8HM3 Chapter 2 Installation This is a Half-Width form factor (6.6” x 17”) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries to you and damages to motherboard components.

  • Page 22: Installing The Cpu And Heatsink

    2.3 Installing the CPU and Heatsink 1. Unplug all power cables before installing the CPU. 2. Illustration in this documentation are examples only. Carrier Used Carrier Type Xeon® SP XCC Xeon® SP MCC/LCC Carrier Code Shim Carrier Height 16.70mm 17.55mm XCC Carrier No Shim MCC Carrier...
  • Page 23 SPC741D8HM3 Follow the steps below to finish the CPU installation and please save the Socket Dust Cover when returning for service. Socket Dust Cover CPU Carrier...
  • Page 25 SPC741D8HM3...
  • Page 26 CPU Carrier...
  • Page 27 SPC741D8HM3 Heatsink CPU Carrier Socket...

  • Page 29: Installing Memory Modules (Dimm)

    SPC741D8HM3 2.4 Installing Memory Modules (DIMM) This motherboard provides eight 288-pin DDR5 (Double Data Rate 5) DIMM slots in two groups, and supports Single Channel Memory Technology. CPU0 DDR5_A1, B1, C1, D1 DDR5_E1, F1, G1, H1 1. Before installing a memory module, make sure to turn off the computer and unplug the powercord from the power outlet to prevent damage to the memory module.

  • Page 30: Memory Configurations

    Gen Intel® Xeon® Scalable Processors - SP Speed (MT/s); Voltage (V); DRAM Density & DIMM Per Channel (DPC) Ranks Per DIMM DIMM Capacity Type and Data Width 1DPC 2DPC 16GB 24GB 32GB 1.1V SRx8 (RC D) 16GB 24GB SRx4 (RC C) 32GB 48GB SRx4 (RC F) 9x4...
  • Page 31 SPC741D8HM3...

  • Page 32: Expansion Slots (Pci Express Slots)

    2.5 Expansion Slots (PCI Express Slots) There are 2 PCI Express slots on this motherboard. PCIE slots: PCIE1 (PCIE 5.0 x16 slot, from CPU0) is used for PCI Express x16 lane width cards. PCIE2 (PCIE 5.0 x16 slot, from CPU0) is used for PCI Express x16 lane width cards. Slot Generation Mechanical...

  • Page 33: Jumper Setup

    SPC741D8HM3 2.6 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.
  • Page 34 The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. Password Reset Jumper Open: Password Clear (2-pin PASSWORD_ Short: Normal Mode (Default) 2-pin Jumper CLEAR1)

  • Page 35: Onboard Headers And Connectors

    SPC741D8HM3 2.7 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 36 Auxiliary Panel Header This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.6, No. 42) including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows you to connect SMBus (System Management Bus) equipment. It can be used for communication between peripheral equipment in the system, which has slower transmission rates, and power management equipment.
  • Page 37 SPC741D8HM3 CM Board Standby Power Connect this 19-pin header +12VSB Headers to the PSU for +12VSB and +12VSB +12VSB (19-pin CM_SB_R) PSON PWROK. RSVD (see p.6, No. 38) RSVD PSU_FAN_FAIL_N BMC_THROTTLE NODE_ID_1 PSON# NODE_ID_2 SMB_DATA PSU_PG SMB_CLK SMB_ALT SRST# Thermal Sensor Header...
  • Page 38 OCuLink Connector Please connect PCIE SSDs to (OCU1) the connector. (see p.6, No. 47) (OCU2) (see p.6, No. 8) BMC SMB Header The header is used for the SM DATA (5-pin BMC_SMB1) BUS devices. (see p.6, No. 17) +3VSB +3VSB PH Clear CMOS Pad This allows you to clear (CLRMOS1)
  • Page 39 SPC741D8HM3 System Fan Connectors Please connect fan cables to (6-pin FAN1) the fan connectors and match TACH2 (see p.6, No. 14) the black wire to the ground (6-pin FAN2) pin. All fans support Fan TACH1 (see p.6, No. 13) Control.
  • Page 40 Front Panel Board Header Connect this header to the PWRBTN# +5VSB_FPB (9-pin J1) Front Panel Board on the PLED- USB+0 RESETCON# USB-0 (see p.6, No. 30) system. LOCATORLED- +5V_FPB Intelligent Platform This 4-pin connector is IPMB_SDA Management Bus Header used to provide a cabled IPMB_SCL No connect (4-pin IPMB1)
  • Page 41 SPC741D8HM3 Virtual RAID On CPU This connector supports Intel® Header Virtual RAID on CPU and RAID_KEY (4-pin RAID_1) NVME/AHCI RAID on CPU +3VSB PH (see p.6, No. 31) PCIE. With the introduction of the Intel VROC product, there are three modes of operation:...
  • Page 42 MCIO1 Pin Definition Defeinition Pin Defeinition RX_DP0 TX_DP0 RX_DN0 TX_DN0 RX_DP1 TX_DP1 RX_DN1 TX_DN1 TP_SPARE_A1 SMB_SCL1 IRQ_LVC3_WAKE_N SMB_SDA1 CLK_100M_DIF8_DP PERST0 CLK_100M_DIF8_DN PRSNT0 RX_DP2 TX_DP2 RX_DN2 TX_DN2 RX_DP3 TX_DP3 RX_DN3 TX_DN3 RX_DP4 TX_DP4 RX_DN4 TX_DN4 RX_DP5 TX_DP5 RX_DN5 TX_DN5 TP_SPARE_A2 SMB_SCL2 IRQ_LVC3_WAKE_N SMB_SDA2 CLK_100M_DIF9_DP...
  • Page 43 SPC741D8HM3 MCIO2 Pin Definition Defeinition Pin Defeinition RX_DP8 TX_DP8 RX_DN8 TX_DN8 RX_DP9 TX_DP9 RX_DN9 TX_DN9 TP_SPARE_A1 SMB_SCL1 IRQ_LVC3_WAKE_N SMB_SDA1 CLK_100M_DIF10_DP PERST0 CLK_100M_DIF10_DN PRSNT0 RX_DP10 TX_DP10 RX_DN10 TX_DN10 RX_DP11 TX_DP11 RX_DN11 TX_DN11 RX_DP12 TX_DP12 RX_DN12 TX_DN12 RX_DP13 TX_DP13 RX_DN13 TX_DN13 TP_SPARE_A2...
  • Page 44 MCIO3 Pin Definition Defeinition Pin Defeinition RX_DN0 TX_DN0 RX_DP0 TX_DP0 RX_DN1 TX_DN1 RX_DP1 TX_DP1 TP_SPARE_A3 SMB_SCL1 IRQ_LVC3_WAKE_N SMB_SDA1 CLK_100M_DIF4_DP PERST0 CLK_100M_DIF4_DN PRSNT0 RX_DN2 TX_DN2 RX_DP2 TX_DP2 RX_DN3 TX_DN3 RX_DP3 TX_DP3 RX_DN4 TX_DN4 RX_DP4 TX_DP4 RX_DN5 TX_DN5 RX_DP5 TX_DP5 TP_SPARE_A4 SMB_SCL2 IRQ_LVC3_WAKE_N SMB_SDA2 CLK_100M_DIF5_DP...
  • Page 45 SPC741D8HM3 MCIO4 Pin Definition Defeinition Pin Defeinition RX_DN8 TX_DN8 RX_DP8 TX_DP8 RX_DN9 TX_DN9 RX_DP9 TX_DP9 TP_SPARE_A3 SMB_SCL1 IRQ_LVC3_WAKE_N SMB_SDA1 CLK_100M_DIF6_DP PERST0 CLK_100M_DIF6_DN PRSNT0 RX_DN10 TX_DN10 RX_DP10 TX_DP10 RX_DN11 TX_DN11 RX_DP11 TX_DP11 RX_DN12 TX_DN12 RX_DP12 TX_DP12 RX_DN13 TX_DN13 RX_DP13 TX_DP13 TP_SPARE_A4...

  • Page 46: Unit Identification Purpose Led/Switch

    2.8 Unit Identification purpose LED/Switch With the UID button, user can locate the server working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be turned on.

  • Page 47: Ssd Module Installation Guide

    SPC741D8HM3 2.9 M.2 SSD Module Installation Guide The M.2 Socket (M2_1/M2_2, Key M) supports either a M.2 SATA3.6.0 Gb/s module or a M.2 PCI Express moduel up to Gen3x4 (8Gb/s x4). Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the screw.
  • Page 48 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 49: Chapter 3 Uefi Setup Utility

    SPC741D8HM3 Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 50: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 51: Main Screen

    SPC741D8HM3 3.2 Main Screen Entering the UEFI SETUP UTILITY, the Main screen displays the system overview. The Main screen provides system overview information and allows user to set the system time and date.

  • Page 52: Motherboard Information

    3.2.1 Motherboard Information Press [Enter] to view the information of the motheboard. 3.2.2 Processor Information Press [Enter] to view the information of the processor.

  • Page 53: Memory Information

    SPC741D8HM3 3.2.3 Memory Information Press [Enter] to view the information of the memory.

  • Page 54: Advanced Screen

    3.3 Advanced Screen In this section, it allows user to configure and view the following items: CPU Configura- tion, Platform Power Configuration, DRAM Configuration, Chipset Configuration, Stor- age Configuration, NVMe Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Runtime Error Log- ging, Intel SPS Information, Network Stack Configuration, Intel VMD Technology, Driver Health, Tls Auth Configuration and Instant Flash.

  • Page 55: Cpu Configuration

    SPC741D8HM3 3.3.1 CPU Configuration Active Processor 1 Cores Select the number of cores to enable in each processor package. Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved.
  • Page 56 SW Guard Extensions (SGX) Use this item to enable or disable Software Guard Extensions (SGX). DCU Streamer Prefetcher DCU streamer prefetcher is an L1 data cache prefetcher (MSR 1A4h [2]). Hardware Prefetcher Automatically prefetch data and code for the processor. Enable for better performance. Adjacent Cache Line Prefetch Automatically prefetch the subsequent cache line while retrieving the currently requested cache line.

  • Page 57: Platform Power Configuration

    SPC741D8HM3 3.3.2 Platform Power Configuration Intel SpeedStep Technology Intel SpeedStep technology allows processors to switch between multiple frequencies and voltage points for better power saving and heat dissipation. CPU turbo ratio can be fixed when Intel SpeedStep Technology set Disabled and Intel Turbo Boost Technology set En- abled.
  • Page 58 HWP Native Mode is a pre-requisite for enabling Dynamic SST-PP. Activate SST-BF Select this item to enable or disable the SST-BF. HWP Native Mode is a pre-requisite for enabling SST-BF; HWP Native Mode with No Legacy is a pre-requisite for configuring SST-BF. Configure SST-BF Select this item to enable or disable the BIOS to configure SST-BF High Priority Cores so that SW does not have to configure.
  • Page 59 SPC741D8HM3 CPU Thermal Throttling Select this item to enable or disable Thermal Monitor. Power Performance Tuning This allows user to decides which controls EFB. OS Controls EPB: Specifies IA32_ENERGY_PERF_BIAS is used. BIOS Controls EPB: Specifies ENERGY_PERF_BIAS_CONFIG is used. PECI Controls EPB: Specifies PCS53 is used.

  • Page 60: Dram Configuration

    3.3.3 DRAM Configuration Enforce DDR Memory Frequency POR Enable to enforce POR restrictions for DDR frequency and voltage programming. DRAM Frequency If [Auto] is selected, the motherboard will detect the memory module(s) inserted and assign the appropriate frequency automatically. Volatile Memory Mode Select 1LM or 2LM mode for Volatile memory.
  • Page 61 SPC741D8HM3 Mirror Mode Mirror Mode will set entire 1LM/2LM memory in system to be mirrored, consequently reducing the memory capacity by half. Mirror Enable will disable XPT Prefetch. ADDDC Sparing Enable or disable Memory Rank Sparing. Patrol Scrub Patrol Scrub is a background activity initiated by the processor to seek out and fix memory errors.

  • Page 62: Chipset Configuration

    3.3.4 Chipset Configuration MMCFG Base Use this item to select MMCFG Base. MMCFG Size Use this item to select MMCFG Size. MMIO High Base Use this item to select MMIO High Base. MMIO High Granularity Size Use this item to select MMIO Granularity Size. SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.
  • Page 63 SPC741D8HM3 VT-d Intel Virtualization Technology for Directed I/O helps the virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing ad- ditional levels of manageability, security, isolation, and I/O performance. OCU Mode Selection Select SATA or PCIe work in OCU port.
  • Page 64 MCIO4-1/MCIO4-2 Surprise Hot Plug Enable or disable PCIE and MCIO Surprise Hot Plug. PCIE ASPM Selec this item to configure the PCIE ASPM. PCI-E ASPM Support (Global) Select this item to disable ASPM Support in all PCIe root ports. OCU1/2 ASPM Support Select this item to configure PCIE Active State Power Management settings.

  • Page 65: Storage Configuration

    SPC741D8HM3 3.3.5 Storage Configuration Hard Disk S.M.A.R.T. S.M.A.R.T stands for Self-Monitoring, Analysis, and Reporting Technology. It is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability. SATA Controller 0/1 Use this item to enable or disable SATA Controllers.

  • Page 66: Nvme Configuration

    3.3.6 NVMe Configuration NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information. Launch NVMe driver Select this item to enable or disable launch NVMe driver.

  • Page 67: Acpi Configuration

    SPC741D8HM3 3.3.7 ACPI Configuration PCIE Devices Power On Allow the system to be waked up by a PCIE device and enable wake on LAN. Ring-In Power On Use this item to enable or disable Ring-In signals to turn on the system from the power- soft-off mode.

  • Page 68: Usb Configuration

    3.3.8 USB Configuration USB Configuration The USB Configuration displays the USB Controllers and USB Devices informations.

  • Page 69: Super Io Configuration

    SPC741D8HM3 3.3.9 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Change Settings Use this item to select an optimal setting for Super IO device.

  • Page 70: Serial Port Console Redirection

    3.3.10 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, it allows user to select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how the computer and the host computer to which are connected exchange information.
  • Page 71 SPC741D8HM3 Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200].
  • Page 72 Out-of-Band Mgmt Port Microsof t Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this item to select the preferred terminal emulation type for out-of-band management. It is recommended to select [VT-UTF8]. Option Description VT100...

  • Page 73: H/W Monitor

    SPC741D8HM3 3.3.11 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 74: Runtime Error Logging

    3.3.12 Runtime Error Logging System Error Use this item to enable or disable System Error feature. When it is set to [Enabled], it allows user to configure Memory Error and PCIE Error log features. WHEA Support Use this item to enable or disable Windows Hardware Error Architecture. EMCA Logging Support Use this item to enable or disable EMCA Logging.
  • Page 75 SPC741D8HM3 PCIE Corrected Error Threshold PCIE Correctable Error Threshold (0x01-0xFF) used for sparing, tagging, and leaky bucket. PCIE Uncorrected Error Enable Use this item to enable or disable PCIe Uncorrectable errors. PCIE Fatal Error Enable Use this item to enable or disable PCIe Ftal errors.

  • Page 76: Intel Sps Configuration

    3.3.13 Intel SPS Configuration SPS screen displays the Intel SPS Configuration information, such as Operational Firmware Version and Firmware State.

  • Page 77: Network Stack Configuration

    SPC741D8HM3 3.3.14 Network Stack Configuration Network Stack Enable UEFI network stack can prevents to perform from the single-user network boots and network installation. If disabled, the host does not use the network interface. IPv4 PXE Support Enable IPv4 PXE Boot support. If disabled, IPv4 PXE Boot Option is not supported.

  • Page 78: Intel® Vmd Technology

    3.3.15 Intel® VMD technology Press <Enter> to bring up the Intel(R) VMD for Volume Management Device Configuration menu. VMD Config for PCH ports Use this item to enter VMD for PCH ports configuration menu . Enable/Disable VMD Use this item to enable or disable VMD in this Stack. PCH Root Port 0/2 (OCU1/2) Use this item to configure PCH root port.

  • Page 79: Tls Auth Configuration

    SPC741D8HM3 3.3.16 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Press <Enter> to configure Client Cert. Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert.

  • Page 80: Instant Flash

    3.3.17 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows user to update system UEFI without entering operating systems first like MS- ® DOS or Windows . Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then update the UEFI only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 81: Server Mgmt

    SPC741D8HM3 3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces. FRB-2 Timer...
  • Page 82 OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. If the OS Boot Watchdog Timer is disabled, this item is not available. BMC Network Configuration Select this item to configure BMC network parameters. System Event Log Press <Enter>...

  • Page 83: Bmc Network Configuration

    SPC741D8HM3 3.4.1 BMC Network Configuration Bonding Setting Select this item to enabled or disabled bonding. Please enable all lan channel first when want to enable bonding. Lan Channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. Using a static IP address, toggle to [Yes], and the changes take effect after the system reboots.
  • Page 84 When [DHCP] or [Static] is selected, do NOT modify the BMC network settings on the IPMI web page. The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/ipmi.asp VLAN...

  • Page 85: System Event Log

    SPC741D8HM3 3.4.2 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL.

  • Page 86: Bmc Tools

    3.4.3 BMC Tools KCS control Select the KSC interface state after POST end. If [Enabled] is selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage. Restore AC Power Loss This allows user to set the power state after an unexpected AC/power loss.

  • Page 87: Security

    SPC741D8HM3 3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 88: Key Management

    3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time using the secure boot.
  • Page 89 SPC741D8HM3 Platform Key(PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed...
  • Page 90 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Forbidden Signatures(dbx) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3.
  • Page 91 SPC741D8HM3 b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed...

  • Page 92: Event Logs

    3.6 Event Logs Change Smbios Event Log Settings Select this item to configure the Smbios Event Log Settings. When entering the item, the screen displays following sub-items: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.

  • Page 93: Boot Screen

    SPC741D8HM3 3.7 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1/#2/#3/#4/#5/#6 Use this item to set the system boot order. UEFI USB Drive BBS Priorities Specifies the Boot Device Priority sequence from available UEFI USB Drives.
  • Page 94 Full Screen Logo Use this item to enable or disable OEM Logo. The default value is [Enabled].

  • Page 95: Exit Screen

    SPC741D8HM3 3.8 Exit Screen Save Changes and Exit When selecting this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When selecting this option, the following message “Discard changes and exit setup?”...

  • Page 96: Chapter 4 Software Support

    Please download the operating system from the OS manufacturer. Please refer to the OS documentation for more instructions. * Please download the Intel® SATA Floppy Image driver from the ASRock Rack’s website (www.asrockrack.com) to the USB drive while installing OS in SATA RAID mode.

  • Page 97: Chapter 5 Troubleshooting

    SPC741D8HM3 Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries and damages to motherboard components.
  • Page 98 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the related problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 99: Technical Support Procedures

    SPC741D8HM3 5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description. Contact ASRock Rack’s technical support at: http://www.asrockrack.com/support/tsd.asp...
