1.2 Specifications
SPC741D8QM3-NL
Physical Status
Form Factor
Dimension
Processor System
CPU
Socket
Thermal Design
Power (TDP)
Chipset
System Memory
Supported DIMM
Quantity
Supported Type
Max. Capacity per
DIMM
Max. Frequency
Voltage
Note
PCIe Expansion Slots (SLOT7 close to CPU)
SLOT6
SLOT1
Other PCIe Expansion Connectors
M.2 slot
OCuLink
MCIO
SATA/SAS Storage
PCH Built-in
Storage
Ethernet
OCP slot
USB
Controller/Hub
Connectors/
headers
2
CEB
12" x 10.5" (304.8 x 266.7 mm)
th
Supports 4 Gen Intel® Xeon® Scalable Processors
Single Socket E (LGA 4677)
~350W
Intel® C741
8 DIMM slots (1DPC)
288-pin DDR5 RDIMM/RDIMM-3DS
RDIMM:64GB
RDIMM-3DS: 256GB
4800 MT/s
1.1V
Memory support is to be validated
PCIe5.0 / CXL1.1 x16 [CPU]
PCIe4.0 x16 [CPU]
1 M-key M2_1 (PCIe3.0 x4 or SATA 6Gb/s), supports 2280/2260
form factor [PCH]
1 M-key M2_2 (PCIe3.0 x4 or SATA 6Gb/s), supports
22110/2280 form factor [PCH]
1 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s) [PCH]
4 MCIO (PCIE5.0 x8) [CPU]
Intel® C741 (Up to 8 SATA 6Gb/s, support RAID 0/1/5/10):
1 OCuLink, 2 SATA 7-pin, 2 M.2
1 OCP NIC 3.0 (PCIe5.0 / CXL1.1 x16) [CPU]
ASMedia ASM1074
External:
2 Type A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
1 header (9-pin, 2 USB2.0)
