Lumens VC-TR60A User Manual

Auto tracking camera (ptz video camera)
Hide thumbs Also See for VC-TR60A:

Advertisement

Quick Links

Download this manual
VC-TR60A
Auto Tracking Camera
(PTZ Video Camera)
User Manual - English
Version VRK100a
To download the latest version of Quick Start Guide,
multilingual user manual, software, or driver, etc.,
please visit Lumens
https://www.MyLumens.com/support

Advertisement

loading
Need help?

Need help?

Do you have a question about the VC-TR60A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens VC-TR60A

Summary of Contents for Lumens VC-TR60A

  • Page 1 VC-TR60A Auto Tracking Camera (PTZ Video Camera) User Manual - English Version VRK100a To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...
  • Page 2 Contents Chapter 1 Package Contents ..............2 Chapter 2 Product Appearance ..............3 2.1 I/O interface ........................... 3 2.2 LED Indicator ......................... 3 Chapter 3 Installation Instructions............4 3.1 Scenario ........................... 4 3.2 Preparation before installation ..................4 3.3 I would like to install the camera on the ceiling/wall/TV stand ......5 3.4 Camera Size ...........................
  • Page 3 Chapter 1 Package Contents 3-PIN to 2-PIN Camera Power Adapter Power Cord connector (Appearance may vary (For Japan only) depending on country/ region) USB cable - 2M Remote Control (Type B to Type A) English...
  • Page 4 Chapter 2 Product Appearance 2.1 I/O interface Front Back Item Function Descriptions Main camera lens UltraHD camera lens Panoramic lens Panoramic camera lens LED indicators Display the camera status, please refer to 2.2 LED Indicator HDMI Out HDMI output (Audio output supported) Connecting to the USB port of the computer and providing USB USB3.0 Out signal images...
  • Page 5 Chapter 3 Installation Instructions 3.1 Scenario 3.1.1 VC-TR60A supported distance range: ▪ Auto Tracking, Auto Framing: 6-12m ▪ Voice Tracking: 2-8m 3.1.2 Cautions for installation 3.1.2.1 Recommended to install the camera on top of the display. Avoid placing on the desktop to prevent obstructing the lens view and audio quality.
  • Page 6 3.3 I would like to install the camera on the ceiling/wall/TV stand Lumens offer following optional accessories. ▪ VC-WM14 3 in 1 Folding Bracket ▪ VC-WM15 Ceiling Mounted Bracket For installation of brackets, please download Quick Installation Guide from Lumens website ▪...
  • Page 7 3.4 Camera Size ▪ Length x Width x Height: 190 x 144x 179mm ▪ Weight: 1.5Kg 3.4.1 Dimensions of the bottom The camera can be mounted on a 1/4”-20 UNC PTZ tripod deck by using the lock holes on the bottom.
  • Page 8 3.5 Connecting Devices 3.5.1 Connecting devices Ethernet port supporting PoE+ (IEEE802.3at) 3.5.2 RS-232/ RS-422 Pin Definition RJ45 Series RJ45 Series RX_IN- RS422 RS232 RX_IN+ RS422 Detection TX_IN- RS422 RS232 TX_IN+ RS422 English...
  • Page 9 Chapter 4 Remote Control and Setting Menu Remote Control Item Description ➊ ⓫ Power on/ off Power  0-9: Click to call the preset ➋  Preset: Appoint an ID(0~9) to save the current position data Preset  Reset: Appoint an ID(0~9) to clear the current position data ➌...
  • Page 10 Setting Menu Press [MENU] on the remote control to enter the setting menu. Default is showed with bold. Layer 1 Layer 2 Layer 3 Description Full Auto/ Shutter Pri/ Iris Mode Exposure mode setting Pri/ Manual/ White Board Spot Light On/ Off Turn on/ off Spot Light Spot Light...
  • Page 11 Layer 1 Layer 2 Layer 3 Description Users can customize the desired image Image Mode Default/ Custom mode Adjustable when Image Mode set to Brightness 0~C~14 Custom Adjustable when Image Mode set to 0~C~14 Custom Adjustable when Image Mode set to Saturation 0~C~14 Custom...
  • Page 12 Layer 1 Layer 2 Layer 3 Description IP Address 192.168.100.100 Subnet mask 255.255.255.0 Configurable when DHCP is set to Off Gateway 192.168.100.254 Audio Enable On/ Off Turn on/off audio output Audio In Line In Audio Volume 0~C~10 Volume Setting When the audio is not synchronized with Audio Delay On/ Off the video, enable this function to set the...
  • Page 13 Layer 1 Layer 2 Layer 3 Description Set whether the tally lamp is linked with RS232 command  Normal (Not linked): The tally lamp and mode shall be set separately. When the tally lamp is on but the ➢ default mode is off, additional command is required to set the indicator light mode Tally CMMD...
  • Page 14 Layer 1 Layer 2 Layer 3 Description The image will freeze when Preset is Motionless Preset executed. Freeze will be released after On/ Off Preset is completed When the camera is turned off via the remote control or software, the lens will Privacy Mode On/ Off automatically turn to the bottom right to...
  • Page 15 Chapter 5 Network setting and Web interface Connecting Camera to Network 5.1.1 Connection Two common connection methods are shown below 1. Connect via switch or router Cat5e cable Cat5e cable Camera Ethernet Switch 2. Connect directly via an Ethernet cable, and the computer's IP address must be modified to match the network segment used by the camera.
  • Page 16 Lumens IP Camera Account: admin ⚫ Password: 9999 ⚫ (Default) 5.1.3 Using RTSP Player to View the Images Free software can be used for RTSP connection, such as VLC, Quick Time and PotPlayer. RTSP connection address formats are as follows: RTSP Stream 1 =>...
  • Page 17 Web interface functions 5.2.1 Login Item Function Descriptions User name Enter user login account (default: admin) Enter user password (default: 9999) For the first-time login, please refer to 5.2.10 System-User Password change the default password Save user name and password. When you log in next time, there is Remember Me no need to re-enter them.
  • Page 18 5.2.2 Live View Item Function Descriptions Display camera ID/ Location Camera ID/ Location Please refer to 5.2.7 System-Output Preview screen Display the current view of the camera Preset setting Select the number first and then select Store or Load Pan/Tilt Adjust the Pan/Tilt of the camera Zoom Zoom In/Zoom Out the image...
  • Page 19 5.2.3 Live View - Camera Setting Item Function Descriptions Mode: Exposure mode (Full Auto/ Shutter Pri/ Iris Pri/ Manual/ ◼ White Board) Gain Limit: Adjust gain limit (adjustable under “Manual”mode.) ◼ Exposure Comp. Level: Select exposure compensation level ◼ WDR: Set the level to obtain better image ◼...
  • Page 20 Mirror: Set image mirroring ◼ Flip: Set image flip ◼ Pan/Tilt limit: Enable to set the pan/tilt limit ◼ Preset Speed: Set the rotation speed when Preset executed ◼ Pan Tilt Zoom Initial Position: Set the camera go to the Last MEM or 1st Preset ◼...
  • Page 21 5.2.4 Tracking Item Function Descriptions Camera ID/Location Display camera ID/ location. Please refer to 5.2.7 System-Output PTZ preview screen Display the current view of the main lens. Panoramic preview Display the current view of the panoramic lens screen People Count Display the calculated number of people in the screen.
  • Page 22 Everywhere Tracking/ Stage Tracking/ Partition ▪ Auto Tracking: Tracking Center Stage ▪ Auto Framing: Auto Framing/ Partition Framing ▪ Sensitivity Set tracking sensitivity Tracking Speed Set tracking speed Target Lost Time Set a delay to take action after a tracking target is lost Target Lost Action Set the action after a tracking target is lost After a person enters the area for 3 seconds, tracking/ framing will...
  • Page 23 Body Size: Set Full/ Half Body ◼ 19.2 Stage Tracking Head Position: Set the head position of the person in the screen ◼ Block Area: Click the left mouse button to draw a frame on the ◼ panoramic view to set a block area. Tracking Zone: Click the left mouse button to draw a frame on the ◼...
  • Page 24 Block Area: Click into the Edit mode, frame by holding the left ◼ mouse button and set the block area Block Area: Click the left mouse button to draw a frame on the ◼ panoramic view to set a block area. Framing Size: Set the framing size.
  • Page 25 5.2.5 Audio Item Function Descriptions Select to enable Audio function Audio In: Set Line In ◼ Audio Enable Encode sample rate: Encode type and sample rate (48KHz(AAC) ◼ Volume: Adjust Audio Volume ◼ Audio Delay Check to set the audio delay time (10 ~ -500 ms) Apply/Cancel Apply/ Cancel Audio Settings English...
  • Page 26 5.2.6 Stream Item Function Descriptions Streaming 1/ 2 Supporting 2 streaming outputs Streaming Please refer to 5.2.6.1 Streaming Parameter Setting. parameter settings Select to enable RTSP Enable/ Disable Multicast ◼ Multicast is recommended when the online watching numbers is more than 4. Enable/Disable Password Authentication ◼...
  • Page 27 Latency can be set between 20-8000 microseconds. (Default is 120 ◼ microseconds 5.2.6.1 Streaming parameter setting Function Streaming 1 Streaming 2 Encode Format H.264 H.264 Resolution 4K/ 1080p / 720p 720p Bit rate 2,000~20,000 2,000~20,000 Bit rate Default 7,000 3,000 Rate Control CBR / VBR Frame Rate/ Group of Pictures...
  • Page 28 5.2.7 System - Output Item Function Descriptions Name camera ID/ Location ◼ Supporting 1 - 32 characters for the camera ID/ location ◼ Supporting English, Chinese and numbers. Special symbols such as Camera ID/ “/” and “space” cannot be used Location Modifying this field will also update the ONVIF device name/location.
  • Page 29 simultaneously. ◼ Once PIP is enabled, [Motionless Switch] will be automatically disabled. Apply/ Cancel Apply/ Cancel Setting 5.2.7 System - Network Item Function Descriptions Camera network settings. Modifications can be made when the DHCP DHCP is disabled. HTTP Port Set HTTP port. The default Port value is 80 HTTPS Port Set HTTPS port.
  • Page 30 5.2.8 System - Date & Time Description Display the current camera/PC date/time, and set the display format and synchronization way. When Manually Set is selected for [Time Settings], Date & Time can be customized. 5.2.9 System - User Description Add/Modify/Delete user account ◼...
  • Page 31 5.2.10 System - Control Item Function Descriptions Protocol Supporting VISCA protocol Baud Rate Select the transmission speed of the control signal The camera ID address 1 ~ 7 can be assigned. VISCA address When enabled, LED on the front panel will flash green in a Tracking LED status slow blinking while the camera is tracking.
  • Page 32 Save setup parameters as a Profile, and users can download and Configuration upload camera setup parameters. If the camera operates abnormally, please export event log and Event Log provide it to Lumens for confirmation. 5.2.12 About Description Display the firmware version, serial number, and other related information of the camera For technical support, please scan the QR code at the bottom right.
  • Page 33 Chapter 6 Troubleshooting This chapter describes problems you may encounter while using VC-TR60A. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your local distributors or Lumens.
  • Page 34 Chapter 7 Safety Instructions Always follow these safety instructions when setting up and using PTZ Video Camera: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.
  • Page 35 ◼ IC Warning This digital apparatus does not exceed the Class A limits for radio noise emissions from digital apparatus as set out in the interference-causing equipment standard entitled “Digital Apparatus,” ICES-003 of Industry Canada. Cet appareil numerique respecte les limites de bruits radioelectriques applicables aux appareils numeriques de Classe A prescrites dans la norme sur le material brouilleur: “Appareils Numeriques,”...
  • Page 36 Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
