Lumens VC-TR30 User Manual

Auto tracking camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VC-TR30
Auto Tracking Camera
(PTZ Video Camera)
User Manual - English
Version VYO100
[Important]
To download the latest version of Quick Start
Guide, multilingual user manual, software, or
driver, etc., please visit Lumens
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC-TR30 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens VC-TR30

Summary of Contents for Lumens VC-TR30

  • Page 1 VC-TR30 Auto Tracking Camera (PTZ Video Camera) User Manual - English Version VYO100 [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Package Contents ...................2 Chapter 2 Product appearance ..................3 2.1 I/O functions Introduction ..................3 2.2 Description of LED indicator .................. 3 Chapter 3 Instruction for installation ................4 3.2 Preparation before installation................4 3.3 Instruction for installation ..................4 3.4 Connecting devices ....................

  • Page 3: Chapter 1 Package Contents

    Chapter 1 Package Contents RS-232/RS-422 Camera Remote Control Connection Instruction 3-PIN to 2-PIN Power Cord Power Adapter connector Appearance may vary (For Japan only) depending on country/ region USB 3.0 cable - 2 M (Type B to Type A) English...

  • Page 4: Chapter 2 Product Appearance

    Chapter 2 Product appearance I/O functions Introduction Front View Back View ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Item Function Descriptions Main camera lens HD camera lens Panoramic lens Panoramic camera lens USB3.0 Port The USB port is for connecting to the USB port of the computer and providing USB signal images HDMI output HDMI output (Audio output supported)

  • Page 5: Chapter 3 Instruction For Installation

    Scenario 3.1.1 3.1.2 Applicable distance range of VC-TR30: 2 - 12 m, best tracking target distance recommended: 8 3.1.3 Mounting height: 2 - 3 m, best height recommended: 2.4 m <Note> For maintaining the best tracking results, please avoid images of people on posters, screens,...
  • Page 6 3.3.2 I would like to install the camera on the ceiling/wall/TV stand Lumens can provide the following optional accessories. Please contact your Lumens distributer if needed for purchase  VC-WM14 3 in 1 Folding Bracket  VC-WM15 Ceiling Mounted Bracket...
  • Page 7 3.3.3 Camera Size  Length x Width x Height: 190 x 137.4x 185 mm  Weight: 1.3 Kg 3.3.4 Dimensions of the bottom of the machine The camera can be mounted on a 1/4”-20 UNC PTZ tripod deck by using the lock holes on the bottom for the tripod English...

  • Page 8: Connecting Devices

    Connecting devices <Remark> Network cable port, supporting PoE (IEEE802.3af) power supply 3.4.1 RS-232 connection (up to 7 Lumens cameras) English...
  • Page 9  RS-232 pins definition instructions English...

  • Page 10: Chapter 4 Remote Control And Setting Menu

    Chapter 4 Remote Control and Setting Menu Remote Control 編號 項目 說明 ➊ Power Switch Power ⓫  Numeric Keys 0 - 9: Click to call the preset ➋  Preset: Appoint an ID (0 ~ 9) to save the current position data Preset ...

  • Page 11: Setting Menu

    Setting Menu <Remark> Press [MENU] on the remote control to enter the setting menu; the bold underlined values in the following table are defaults. 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Full Auto/ Shutter Pri/ Iris Exposure mode setting Mode Pri/ Manual/ White Board...
  • Page 12 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Limit the right angle Pan Right Limit 0~170 Zoom Limit the left angle Pan Left Limit -170~0 Limit the upward angle Tilt UP Limit 0~90 Limit the downward angle Tilt Down Limit -30~0 After it is activated, the Pan command...
  • Page 13 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Camera IR Select setting must be the same setting as the Camera Select of IR Select 1/ 2/ 3 the remote control to control the camera When enabled, LED on the front panel Tracking Led will flash green in a slow blinking while...

  • Page 14: Chapter 5 Network Function Settings Description

     Open the browser, and enter the IP address of the camera in the address bar E.g.: http://192.168.100.100 (default IP address)  Enter administrator’s account and password <Remark> For the first-time login, please refer to5.2.10System Settings - User to change the default password Lumens Network Camera  Account: admin  Password: 9999 (Default) English...
  • Page 15 5.1.3 Using RTSP Player to View the Images Free software can be used for RTSP connection, such as VLC, Quick Time and PotPlayer RTSP connection address formats are as follows:  RTSP Stream 1 => rtsp://camera IP:8557/h264  RTSP Stream 2 => rtsp://camera IP:8556/h264 If password authentication is enabled, the RTSP connection address is as follows: ...

  • Page 16: Web Page Menu Function Description

    Web Page Menu Function Description 5.2.1 Login Screen ○ ○ ○ ○ ○ Item Function Descriptions User Login Account Enter user login account (default: admin) Enter user password (default: 9999) User Password <Remark> For the first-time login, please refer to 5.2.10 System Settings - User to change the default password...
  • Page 17 Preset setting Select the number first and then select SAVE or LOAD Pan/Tilt setting Adjust the Pan/Tilt position of the camera screen Zoom Zoom In/Zoom Out ratio AF/MF Switch AF/MF Pan/ Tilt Speed Adjust the horizontal/vertical moving speed of the lens Zoom speed Adjust the zoom speed Auto Tracking...
  • Page 18 Focus  AF Sensitivity: Set automatic focus sensitivity  AF Frame: Set automatic focus range Mirror  Mirror: Set image mirroring  Flip: Set image flip  Pan/Tilt limit: Enable, and set the pan/tilt limit  Preset Speed: Set the rotation speed of the cradle head when Preset is executed ...
  • Page 19  Brightness: Brightness adjustment of the image; Adjustable when the image mode is set to Custom  Gamma: Gamma Level adjustment; Adjustable when the image mode is set to Custom  Sharpness: Sharpness adjustment of the image; Adjustable when the image mode is set to Custom PTZ Control Go back to PTZ Control page...
  • Page 20 5.2.4 Tracking ○ ○ ○ ○ ⑲ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Item Function Descriptions Camera Please refer to 5.2.7 System Settings - Output Setting to display camera ID/location ID/location Preview main Display the screen currently captured by the main camera lens window <Remark>...
  • Page 21 Target Lost Set the action after a tracking object is lost Action Partition Edit Check to edit and save the Partition settings. People Count VC-TR30 supports 6 kinds of tracking mode 19.1 Settings - Everywhere tracking  Body Size: Set Full/Half Body ...
  • Page 22  Body Size: Set Full/Half Body  Head Position: Set the head position of the person in the screen  Block Area: Click into the Edit mode, frame by holding the left mouse button and set the block area  Partition Edit: Edit, save partition positions and preview the partition image.
  • Page 23 5.2.4.1 Stage Tracking 1. Select [Stage] for Tracking Mode, and click to access the settings Select Stage Zone to enter Edit mode, and click the lef mouse button to frame it (blue frame) in the panoramic preview window, determine the area and moving range. After framing, use the mouse to click the frame line to move or delete it.
  • Page 24 4. After setting completed, click to save the settings. 5. Click to enable the Stage feature 5.2.4.2 Partition Tracking 1. Select [Partition] for Tracking Mode, and click to access the settings 2. Click to enable the Partition edit, click the left mouse button to frame it (orange frame) in the panoramic preview window, determine the area and click to save.
  • Page 25 5.2.5 Audio ○ ○ ○ Item Function Descriptions Select to enable Audio function  Audio In: Set Line In / Mic In Audio Enable  Encode sample rate: Encode type and sample rate (48KHz(AAC)  Volume: Adjust Audio Volume Audio Delay After checking the box, set the audio delay time (10 ~ -500 ms) Apply/Cancel Apply/Cancel Audio Setting...
  • Page 26 5.2.6 Streaming ○ ○ ○ ○ ○ ○ Item Function Descriptions Streaming 1/ Supporting 2-way streaming output Streaming 2 Streaming Please refer to 5.2.6.1 Streaming Parameter Setting for relevant settings parameter setting Select to enable RTSP  Enable/Disable Multicast It is suggested to enable Multicast when the number of users online watching the live image simultaneously is more than 4 ...
  • Page 27 5.2.6.1 Streaming parameter setting Function Streaming 1 Streaming 2 Encode Format H.264 Resolution 1080p / 720p 720p Range 2,000~20,000 2,000~20,000 Bit rate Factory 7,000 3,000 Default Rate Control CBR / VBR Frame Rate Setting according to the supported resolution Group of Pictures Setting according to the supported resolution System –...
  • Page 28 After switching the resolution, the camera will restart. Please refresh the browser HDMI format Select YUV444/RGB Enable/Cancel Privacy Mode Privacy Mode After the function is enabled, when the camera is turned off via the (UVC) remote control or software, the lens will automatically turn to the bottom right to ensure the user’s privacy Apply/Cancel Apply/Cancel Setting...
  • Page 29 5.2.9 System – Date & Time Function Descriptions Display the current camera/PC date and time, and set the display format and synchronization way When Manually Set is selected for [Time Settings], Date & Time can be customized 5.2.10 System – User Function Descriptions Add/Modify/Delete user account ...
  • Page 30 5.2.11 System Settings – Control ○ ○ ○ ○ 4 ○ Item Function Descriptions Protocol Supporting VISCA protocol Baud Rate Choose the transmission speed of the control signal as 9600/38400 VISCA address The camera ID address 1 ~ 7 can be assigned. Select 0 for automation Tracking LED status Enable/Disable the LED in front panel flick when tracking is triggered.
  • Page 31 System Settings camera setup parameters If the camera operates abnormally, please export error log and provide it Error Log to Lumens for confirmation 5.2.13 About Function Descriptions Display the firmware version, serial number, and other related information of the camera For technical support, please scan the QRcode at the bottom right.

  • Page 32: Chapter 6 Troubleshooting

    Chapter 6 Troubleshooting This chapter describes problems you may encounter while using VC-TR30. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributors or the service center.

  • Page 33: Chapter 7 Safety Instructions

    Safety Instructions Chapter 7 Always follow these safety instructions when setting up and using VC-TR30 PTZ Video Camera: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table.
  • Page 34  “Extron IP Link Compatible Extron has developed and tested an IP Link driver for this product. Using IP Link technology, this device can be monitored, controlled and supported over a standard Ethernet network. In order to enable IP Link network connectivity and control, you must install and configure an IP Link-enabled device such as a MediaLink controller or IP Link Ethernet control interface.

  • Page 35: Supplier's Declaration Of Conformity 47 Cfr § 2.1077 Compliance Information

    Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：VC-TR30 Model Number：PTZ Video Camera Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules.

  • Page 36: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.

This manual is also suitable for:

Vc-tr30pb
