VC-TR40
Auto Tracking Camera
(PTZ Video Camera)
User Manual - English
[Important]
To download the latest version of Quick Start
Guide, multilingual user manual, software, or
driver, etc., please visit Lumens
https://www.MyLumens.com/support

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VC-TR40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens VC-TR40

Summary of Contents for Lumens VC-TR40

  • Page 1 VC-TR40 Auto Tracking Camera (PTZ Video Camera) User Manual - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Package Contents ...................2 Chapter 2 Product appearance ..................3 2.1 I/O functions Introduction ..................3 2.2 Description of LED indicator .................. 3 Chapter 3 Instruction for installation ................4 3.2 Preparation before installation................4 3.3 Instruction for installation ..................4 3.4 Connecting devices ....................

  • Page 3: Chapter 1 Package Contents

    Chapter 1 Package Contents RS-232/RS-422 Quick Installation Camera Connection Guide Instruction 3-PIN to 2-PIN Power Cord Power Adapter connector Appearance may vary (For Japan only) depending on country/ region USB 3.0 cable - 2 M HDMI cable - 1.5 M Remote Control (Type B to Type A) English...

  • Page 4: Chapter 2 Product Appearance

    Chapter 2 Product appearance I/O functions Introduction Front View Back View ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Item Function Descriptions Main camera lens 18X HD camera lens Panoramic lens Panoramic camera lens USB3.0 Port The USB port is for connecting to the USB port of the computer and providing USB signal images HDMI output HDMI output (Audio output supported)

  • Page 5: Chapter 3 Instruction For Installation

    Scenario 3.1.1 3.1.2 Applicable distance range of VC-TR40: 4 - 15 m, best tracking target distance recommended: 8 3.1.3 Mounting height: 2 - 3 m, best height recommended: 2.4 m <Note> For maintaining the best tracking results, please avoid images of people on posters, screens,...
  • Page 6 3.3.2 I would like to install the camera on the ceiling/wall/TV stand Lumens can provide the following optional accessories. Please contact your Lumens distributer if needed for purchase  VC-WM14 3 in 1 Folding Bracket  VC-WM15 Ceiling Mounted Bracket...
  • Page 7 3.3.3 Camera Size  Length x Width x Height: 190 x 138 x 185 mm  Weight: 1.3 Kg 3.3.4 Dimensions of the bottom of the machine The camera can be mounted on a 1/4”-20 UNC PTZ tripod deck by using the lock holes on the bottom for the tripod English...

  • Page 8: Connecting Devices

    Connecting devices <Remark> Network cable port, supporting PoE (IEEE802.3af) power supply 3.4.1 RS-232 connection (up to 7 Lumens cameras) English...
  • Page 9  RS-232 pins definition instructions English...

  • Page 10: Chapter 4 Remote Control And Setting Menu

    Chapter 4 Remote Control and Setting Menu Remote Control 編號 項目 說明 ➊ Power Switch Power ⓫  Numeric Keys 0 - 9: Click to call the preset ➋  Preset: Appoint an ID (0 ~ 9) to save the current position data Preset ...

  • Page 11: Setting Menu

    Setting Menu <Remark> Press [MENU] on the remote control to enter the setting menu; the bold underlined values in the following table are defaults. 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Full Auto/ Shutter Pri/ Iris Exposure mode setting Mode Pri/ Manual/ White Board...
  • Page 12 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Limit the left angle Pan Left Limit -170~0 Zoom Limit the upward angle Tilt UP Limit 0~90 Limit the downward angle Tilt Down Limit -30~0 After it is activated, the Pan command Pan Flip On/Off will be reverse...
  • Page 13 1st Level 2nd Level 3rd Level Function Descriptions Major Items Minor Items Adjustment Values Turn on/off the infrared reception When it is Off, the remote control will not be able to control the camera. At IR Receive On/Off this moment, turn off and then turn on the power to restore control of the remote control.

  • Page 14: Chapter 5 Network Function Settings Description

    Chapter 5 Network Function Settings Description Connecting Camera to Network 5.1.1 Connecting to Internet Two common connection methods are shown below 1. Connecting via switch or router Network cable Network cable Camera Computer Switch or router 2. To connect directly through network cable, the IP address of the computer should be changed so that it is on the same network segment as the camera E.g.: The factory-preset default IP address of the camera is 192.168.100.100.
  • Page 15 Lumens Network Camera  Account: admin  Password: 9999 (Default) 5.1.3 Using RTSP Player to View the Images Free software can be used for RTSP connection, such as VLC, Quick Time and PotPlayer RTSP connection address formats are as follows: ...

  • Page 16: Web Page Menu Function Description

    Web Page Menu Function Description 5.2.1 Login Screen ○ ○ ○ ○ ○ Item Function Descriptions User Login Account Enter user login account (default: admin) Enter user password (default: 9999) User Password <Remark> For the first-time login, please refer to 5.2.10 System Settings - User to change the default password...
  • Page 17 Preset setting Select the number first and then select SAVE or LOAD Pan/Tilt setting Adjust the Pan/Tilt position of the camera screen Zoom Zoom In/Zoom Out ratio AF/MF Switch AF/MF Pan/ Tilt Speed Adjust the horizontal/vertical moving speed of the lens Zoom speed Adjust the zoom speed Camera Setting...
  • Page 18  AF Sensitivity: Set automatic focus sensitivity Focus  AF Frame: Set automatic focus range  PTZ Assist: In Manual, check whether auto focus is enabled if there is any changes of PTZ <Remark> When PTZ Assist is enabled and PTZ control is in operation, the focus will be triggered.
  • Page 19  2D noise reduction: 2D noise reduction settings  3D noise reduction: 3D noise reduction settings  Image Mode: The user may customize his/her desired image mode Photo  Hue: Hue adjustment of the image; Adjustable when the image mode is set to Custom ...
  • Page 20 5.2.4 Tracking ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 7 ○ ○ 7 ○ ○ ○ ○ ○ 7 Item Function Descriptions Camera ID/location Please refer to 5.2.7 System Settings - Output Setting to display camera ID/location Preview main Display the screen currently captured by the main camera lens...
  • Page 21 Advanced Setting of Tracking Mode 17.1 Settings - Everywhere tracking  Body Size: Set Full/Half Body  Head Position  Block Area 17.2 Settings - Stage Tracking  Body Size: Set Full/Half Body  Head Position  Block Area  Select Zone: Press the button to enter the edit mode.
  • Page 22 17.4 Settings - Framing  Partition Edit: "Partition-editing button - to trigger P.1 ~ P.4 to enter the edit mode. Framing is available when panoramic window is in the edit mode After framing, capture the images immediately to show them on P.1 ~ ...
  • Page 23 5.2.5 Audio ○ ○ ○ Item Function Descriptions Select to enable Audio function  Audio In: Set Line In / Mic In Audio Enable  Encode sample rate: Set the encode type and sample rate  Volume: Adjust Audio Volume Audio Delay After checking the box, set the audio delay time (10 ~ -500 ms) Apply/Cancel...
  • Page 24 5.2.6 Streaming ○ ○ ○ ○ ○ Item Function Descriptions Streaming 1/ Supporting 2-way streaming output Streaming 2 Streaming Please refer to 5.2.6.1 Streaming Parameter Setting for relevant settings parameter setting Select to enable RTSP  Enable/Disable Multicast It is suggested to enable Multicast when the number of users online watching the live image simultaneously is more than 4 ...
  • Page 25 5.2.6.1 Streaming parameter setting Function Streaming 1 Streaming 2 Encode Format H.264 Resolution 1080p / 720p 720p Range 2,000~20,000 2,000~20,000 Bit rate Factory 7,000 3,000 Default Rate Control CBR / VBR Frame Rate Setting according to the supported resolution Group of Pictures Setting according to the supported resolution System Settings –...
  • Page 26 Enable/Cancel Privacy Mode Privacy Mode After the function is enabled, when the camera is turned off via the (UVC) remote control or software, the lens will automatically turn to the bottom right to ensure the user’s privacy Apply/Cancel Apply/Cancel Setting System Settings –...
  • Page 27 5.2.9 System Settings - Date & Time Function Descriptions Display the current camera/PC date and time, and set the display format and synchronization way When Manually Set is selected for [Time Settings], Date & Time can be customized 5.2.10 System Settings – User Function Descriptions Add/Modify/Delete user account ...
  • Page 28 Settings Account management 5.2.11 System Settings – Control ○ ○ ○ ○ 4 Item Function Descriptions Protocol Supporting VISCA protocol Baud Rate Choose the transmission speed of the control signal as 9600/38400 VISCA address The camera ID address 1 ~ 7 can be assigned. Select 0 for automation Apply/Cancel Apply/Cancel Setting English...
  • Page 29 Configuration camera setup parameters If the machine operates abnormally, the event log can be exported for reference of Lumens technicians Event Log <Remark> When an error code appears, please try to clear it to make sure whether the issue has occurred repetitively 5.2.13 About...

  • Page 30: Chapter 6 Troubleshooting

    It is recommended to use one remote control only How to log in the portal when you forget your Please contact your Lumens distributor or service center account password English...

  • Page 31: Chapter 7 Safety Instructions

    Safety Instructions Chapter 7 Always follow these safety instructions when setting up and using VC-R30 PTZ Video Camera: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. 1.3 Please clean the dust on the power plug prior to usage.

  • Page 32: Supplier's Declaration Of Conformity 47 Cfr § 2.1077 Compliance Information

    Supplier's Declaration of Conformity 47 CFR § 2.1077 Compliance Information Manufacturer：Lumens Digital Optics Inc. Product Name：VC-TR40 Model Number：PTZ Video Camera Responsible Party – U.S. Contact Information Supplier：Lumens Integration, Inc. 4116 Clipper Court, Fremont, CA 94538, United States e-mail ：support@mylumens.com FCC Compliance Statement This device complies with Part 15 of the FCC Rules.

  • Page 33: Copyright Information

    Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
