User Manual

SST4 Micro, SST4 Mini,

SST4 Pump & SST5

Multi Gas Detectors

SST4-SST4Pump-SST5-MAN-ENG-v1.0

01.11.2024

Need help?

Do you have a question about the SST4 Micro and is the answer not in the manual?

Questions and answers

Summary of Contents for WatchGas SST4 Micro

Page 1 User Manual SST4 Micro, SST4 Mini, SST4 Pump & SST5 Multi Gas Detectors SST4-SST4Pump-SST5-MAN-ENG-v1.0 01.11.2024...
Page 2 4.3. 1 4. Safe Mode 4.3. 1 5 Inert 2. 1 . How to Tap a Unit 4.3. 1 6. Language Menu 2.2. Overview of the SST4 Micro and Mini 4.4. Sensor Setting 2.3. Overview of the SST4 Pump 4.4. 1 .
Page 3 8.7. Sensor Signal 8.8. SST 4 Pump Replacement 9. Troubleshooting 9. 1 . Failure Codes 10. Spare Part List 10. 1 . SST4 Micro and Mini Spare Parts and Accessories List 10.2. SST4 Pump Spare Parts and Accessories List 11. Contact Details...
Page 4 • WatchGas recommends to “bump test” the sensors on a regular basis depending on the usage model to confirm their ability to respond to gas by exposing the detector to a gas concentration that exceeds the alarm setpoints. Manually verify that the audible and visual alarms are activated.
Page 5 Do not attempt to disassemble, adjust, or service the detector unless instructions for that procedure are provided in the technical reference guide, and/or that part is listed as a replacement part. Use only WatchGas replacement parts. Refer to Spare Parts List.
Page 6 SST Mini Very similar to its slightly smaller SST Micro counterpart, the SST Mini offers an optional NDIR or traditional high-powered catalytic bead as the detection method for LEL. This is done through our WatchGas Device Link Application. SST Pump Pumped four gas device with our on in-house designed pump allows a draw of up to 30 meters (100 Feet).
Page 7 Lithium polymer cells exposed to heat at 266°F (130°C) for 10 minutes can cause a fire and/or explosion. NOTE: To replace the battery, contact WatchGas or authorized distributor. The battery can only be replaced by the original manufacturer part, which is SST4-MIC-MIN-BAT for the SST4 Micro and Mini, and SST4- PUMP-BAT for the SST4 Pump.
Page 8 In addition to the Induction Disk Charger included with each detector, the SST Range of products can be charged in the WatchGas SST Induction Cradle Charger (sold separately). To charge the detector, refer to Figure 1., Table 2., and the steps below.
Page 9 1.6 Charge Battery and Replace Sensors To replace the battery, contact WatchGas or an authorized distributor. The battery can only be replaced with the original manufacturer part number. To charge the battery and replace the sensors and/or the sensor filter, refer to the following: •...
Page 10 Several cleaners, solvents, and lubricants can contaminate and cause permanent damage to the sensors. Before using cleaners, solvents, and lubricants in close proximity to the detector sensors, read the following cautions and refer to the lists below. Caution Use only the following WatchGas Technologies recommended products and procedures: • Use water-based cleaners. •...
Page 11 2. Overview of Detector Configuration of the SST Range is done with the WatchGas Device Link Application. The app can be downloaded from Google Play and the Store, or by scanning the appropriate QR code in Section 1.3. You can read more about the app on our website.
Page 12 2.3 Overview of the SST4 Pump Symbols Description Wireless charger and NFC Visual alarm indicators (LEDs) Alligator clip Pushbutton Audible alarm Liquid crystal display (LCD) Pump plate Table 4. Overview of the SST4 Pump Figure 5. Overview of the SST4 Pump 2.4 Overview of the SST5 Symbols Description Wireless charger and NFC...
Page 13 2.5 Display Elements of the SST4 Symbols Description Alarm Notification Low Alarm High Alarm Short Term Exposure Alarm Time Weighted Average Alarm Indicate LOW LOW or HIGH HIGH alarm. 3rd alarm level Hydrogen sulfide Sensor Sulfur dioxide Sensor Figure 7. SST4 display Carbon monoxide Sensor Oxygen Sensor NDIR LEL...
Page 14 2.6 Display Elements of the SST5 Symbols Description Alarm Notification Low Alarm High Alarm Short Term Exposure Alarm Time Weighted Average Alarm Indicate LOW LOW or HIGH HIGH alarm. 3rd alarm level Hydrogen cyanide Sensor Figure 8. SST5 display Hydrogen sulfide Sensor Sulfur dioxide Sensor Carbon monoxide Sensor Oxygen Sensor...
Page 15 2.7 Pushbutton To activate the detector, press and hold the pushbutton and a 3 second countdown will start. Keep pressing the pushbutton until the countdown ends, after which the detector will then turn on. To deactivate the detector, press and hold the pushbutton until the OFF countdown is complete and the LCD deactivates.
Page 16 If an error message displays, refer to Startup Troubleshooting. NOTE: The sensors are tested continuously while the detector is activated. If the Calibration Interval option is set to OFF in the WatchGas Device Link Application, the calibration due date is bypassed during operation.
Page 17 If the following error message displays after entering normal operation, refer Startup Troubleshooting. The bump due warning screen can be set in the WatchGas Device Link Application to either lock the unit and force the user to bump, or to simply alert the user about the overdue bump.
Page 18 Or press the pushbutton again to skip to the next screen. Show the current calculated TWA value. If TWA is not enabled in the WatchGas Device Link Application, it will not be shown in the sequence. Calculated TWA values are cleared at switch off,...
Page 19 Days To’ is equal or less than the Calibration Warning setting in the app. Display days remaining until bump due - only if Bump Enable Expiry enabled via the WatchGas Device Link Application, and the ‘Bump Days To’ is equal or less than the Bump Warning setting in the app.
Page 20 Show the language selected via the WatchGas Device Link Application. Show the date. Show the time. Show the User ID as configured via the WatchGas Device Link Application. Show the Site ID as configured via the WatchGas Device Link Application.
Page 21 3.3. Gas Exposures 3.3.1 Calculated Gas Exposures Warning To avoid possible personal injury, do not deactivate the detector during a work shift. TWA, STEL, and MAX readings reset once the detector is deactivated. Gas Exposures Description Time-weighted average (TWA) based on accumulated exposure to toxic gases averaged over a workday according to US OSHA (H2S, CO, and SO2 only) method.
Page 22 1 ppm 0.5 ppm Table 10. Factory Alarm Setpoints NOTE: To disable an alarm, this is done in the WatchGas Device Link App. 3.4.2 Changing Alarm Setpoints To change alarm setpoints, use the WatchGas Device Link Application. Refer to Section •...
Page 23 NOTE: If the pushbutton is released before the countdown is complete, the detector will not deactivate. NOTE: If the detector is set up via the WatchGas Device Link Application to be always on, the function must be changed via the WatchGas Device Link App to allow the unit to be switched off.
Page 24 4.1 App Overwiew Device Configurations 4.1.1 Installing the WatchGas App All set up for the SST4 and SST5 devices is done using the WatchGas Device Link Application. Use the Service password to get access to the Setup options. Either use a Saved Configuration file, or extract the settings from the device with a single Device setup.
Page 25 4.3.3. Heartbeat When enabled, the Heartbeat indicates the device status with a green, blue or red LED as per EN’60079- 29. The Hearbeat Interval can be set in the WatchGas Device Link Application and is disabled by default. 4.3.4. Confidence Bleep When enabled, the Confidence Bleep indicates that the device is compliant.
Page 26 The Scan Protect function can be enabled to protect the device with a PIN code. When the Scan Protect is activated and you input the PIN code into the device, this will block any WatchGas Device Link Application from reading the detector unless it first enters the correct PIN code.
Page 27 4.3.12. Monitor Always On This function disables the power down function and will display LOCKED if power down is attempted. 4.3.13. Auto Zero on Startup When enabled, the sensors automatically zero during the startup self-tests. The Auto-Zero on Start-up option is applied to all sensors. Click the checkbox of each sensor that will be auto zeroed during startup.
Page 28 4.4. Sensor setting 4.4.1. Sensor Configuration Settings for the sensors are configured individually. Enter values, or enable / disable options. Refer to Factory Gas Alarm Setpoints for setpoint values. NOTE: Depending upon the sensor, the options may vary. 4.4.2. Combustible Sensor Sensor 1 –...
Page 29 4.5.2 Calibration Interval Caution WatchGas recommends that the sensors be calibrated on a regular basis, depending on the usage model. Define how often a sensor should be calibrated in the Calibration Interval field. A different calibration interval can be defined for each sensor.
Page 30 The number of days that displays is when the next sensor calibration should be performed. If the Calibration Interval option is defined as OFF in the WatchGas Device Link Application, the calibration due date is bypassed during operation.
Page 31 4.5.13. Bump Test The bump test is activated via the WatchGas Device Link Application and stored in the app automatically and as an event as well. The bump due warning screen reminds the User to perform a bump prior to the bump overdue warning.
Page 32 NOTE: Wind currents may cause false readings and poor calibrations. Figure 8. Connecting the Gas Cylinder to the Detector Item Description Calibration cap Calibration hose Gas cylinder with 0.5 ml/min regulator Mobile phone with the WatchGas Device Link Application Table 11. Connecting the Gas Cylinder to the Detector...
Page 33 1. Make sure the gas bottle is loaded in the gas bottle list in the WatchGas Device Link Application. 2. Activate the calibration from the WatchGas compliance application. 3. Allow the device to finish the zero process. 4. Connect the other end of the calibration hose to the regulator on the gas cylinder.
Page 34 Do not calibrate the detector during or immediately after charging is complete. • Allow the detector to stabilize for 1 minute after activation before performing a calibration or bump test. • If a certified calibration is required, print it from the WatchGas Device Link Application.
Page 35 5.4.2. Calibration Process Step 1. Press the Calibration Step 2. Select the gas start zero (wait for device to pass) option. and connect the span. NOTE: If no span gas is detected in 90 seconds, the monitor will go in fail. Step 3.
Page 36 Step 5. Tap the unit again to load the result. Step 6. Tap units. Step 7. Tick the box and sign in. 5.5. Bump Step 1. Activate the NFC. Step 2. Select the Bump Test option. Step 3. Select the bottle from the list. Step 4.
Page 37 6. Alarms and Notifications Display screen Explanation Low alarm High High alarm High High High high – highest alarm level Low low Second low level for Oxygen STEL 15 min average 8 hours average Sensor Err Sensor error Low battery Battery needs charge Bump due warning Days to bump...
Page 38 (the ninth hour). This continues for the duration of the work shift until the detector is deactivated. Refer to Factory Gas Alarm Setpoints for the factory alarm setpoints. Enter the setpoint in the TWA Alarm field. 6.6 STEL Alarm The short-term exposure limit (STEL) is the maximum permissible gas concentration a worker can safely be exposed to for short periods of time (15 min).
Page 39 • Peak exposure level (ppm or %). • Status of the sensors. 7.3 Downloading Datalogs and Event Logs The datalog and event log files can only be downloaded by means of an SST Dock or the WatchGas Device Link Application.
Page 40 • Do not immerse the detector in liquids. 8.1 Maintenance Screen Device Link In the WatchGas Device Link Application settings, navigate to the Maintenance section. Here you can see information regarding the device’s operations and readings. • 5 stars mean that the sensor performance is healthy .
Page 41 The maximum temperature that the device has registered. 8.1.12 Alarm Minutes The amount of time that the device has spent in alarm mode. 8.2 Update Firmware You can update the device’s firmware to the latest version through the WatchGas Device Link Application, or via the WatchGas SST-Dock.
Page 42 • Ensure that hands are clean or wear gloves before handling components. Figure 10. Replacing a Sensor or Sensor Filter for the SST4 Micro Figure 11. Replacing a Sensor or Sensor Filter for the SST4 Mini...
Page 43 8.4. Removing the Back Casing 1. Deactivate the detector. Place the detector face down on a clean, flat surface. 2. Remove the six machine screws on the rear casing. 3. Remove the back cover by lifting the top and the bottom simulataneously upwards. 8.5.
Page 44 8.6. Replacing the H2S, CO, Oxygen, and LEL Sensor 1. NOTE: when opening the detector, ensure that the PCB is correctly fitted in the housing during reassembly. 2. Ensure that you have changed the sensor SN in the WatchGas Device Link Application, and then calibrate the sensor. Caution Ensure that no damage occurs to the battery.
Page 45 8.7 Sensor Signal PPM/hours - shows the total PPM/hours the sensors have been exposed to. This value is used as a indicator of the sensor usage. Peak reading – the maximum value the sensor ever was exposed to. This indicates if a sensor should be replaced for safety reasons.
Page 46 9. Troubleshooting Troubleshooting of the SST4/SST5 is done through the WatchGas Device Link Application maintenance section. This section will indicate what is functioning properly and what is broken. • 5 stars mean that the sensor performance is healthy . •...
Page 47 9.1 Failure Codes In the table below, you can find all the failure codes and their most common causes: Library Possible fault-cause MOD_ID_HIBERNATE EM4 devices malfunction MOD_ID_TIMER Basic ms-timer could not be started MOD_ID_GPIO One or more gpio-drivers reported an error. See also MOD_ID_EXP_ID2 and MOD_ID_EXP_SST4 MOD_ID_I2C0 MOD_ID_LCD...
Page 48 WatchGas SST Range 5 Way Stackable Charging Cradle, max 4 can be coupled w/o CHR SST-5WSSC-CHR WatchGas Adapter for SST-STACK-CHR can power 4 units SST-STACK-COU SST Range Coupling Cable (link to couple charging stacks) Table 16. SST4 Micro and Mini Spare Parts and Accessories List...
Page 49 0-100% LEL SST-SPARE-X4 WatchGas SST sensor LPC for SST4 Pump 0-100% LEL SST-AG-10 WatchGas SST Replacement Alligator Clip pack of 10 for ALL with screws SST4-POUL-10 SST4 Lanyard Bar, with screws, Pack of 10 (For Micro, Mini and Stainless Pump)
Page 50 11. Contact details EMEA Klaverbaan 121 2908 KD Capelle a/d IJssel The Netherlands info@watchgas.com www.watchgas.com Americas 313 N. State Hwy 342 Red Oak, TX 75154, USA info@watchgasusa.com www.watchgasusa.com APAC Woods Square Tower 1, 12 Woodlands Square, #11-71, Singapore 737715 info@watchgas.com www.watchgas.com...
