Summary of Contents for djpower DSK-1600VM
- Page 2 The information and specifications contained in this User Manual are subject to change without notice. DJPOWER assumes no responsibility or liability for any errors or omissions and reserves the right to revise or to create this manual at any time.
- Page 3 1.5.1 Personal Safety • Always connect the product to a grounded circuit to avoid the risk of electrocution. • During heating up and operation, the housing will be scalding hot. Do not touch. • The product is very hot during operation and it remains hot for a long time after operation has stopped.
- Page 4 With newest “Anti-Squirting Plus” technology, it is safer no matter hung or place on the floor. The height of jet is about 7-8 meters. DJPOWER's patented technology (Patent No.: ZL201320700998.7) is used to provide better effects. It is suitable for bars, concerts, product launch and other places.
- Page 5 Product Overview Product Dimensions 3 TECHNICAL SPECIFICATIONS Input Voltage & Rate AC 100-120V, 50/60Hz AC 220-240V, 50/60Hz AC Power Current Limiter Specifications 15 A, 250 V 8 A, 250 V Total Power Consumption 1,600 W 1,600 W Heating Heat Up Time Appr.
- Page 6 0 to 100% switch. AC Plug The DSK-1600VM comes with a power input cord terminated with a Lockable Powercon connector on one end and an EU plug on the other end (EU & China market). If the power input cord that came with...
- Page 7 Green/Yellow DMX Linking You can link the DSK-1600VM to a DMX controller using a 3- or 5-pin DMX connection. If using other DMX-compatible products with this product, you can control each individually with a single DMX controller. Instructions for connecting and configuring this product for DMX operation are in the User Manual.
- Page 8 • Return the tank back to its compartment in the DSK-1600VM. • Make sure the plastic hose entering the DSK-1600VM from the fluid tank cap is not bent or kinked. • Always connect the product to a grounded circuit. Before power on, make sure it is connected with the rated voltage.
- Page 9 Button Function <MENU> Switch menu pages to select a function ▲ Increase the relevant value of each page ▼ Increase the relevant value of each page < ENTER > Enter or exit each page When turn on the machine, the screen first displays the chip version "U001", and then displays "HEAT", which means the machine is heating.
- Page 10 4 (rand) Machine function description DSK-1600VM has the functions of wireless remote control, DMX control, immediate stop, and LED lights (8 pieces * 10 w). DMX control takes precedence over wireless remote control. The fog output duration time is 7s.
- Page 11 A. When the setting is off, the LED light is off. B. The 21 setting color states are as follows: Co 1 Co 2 Green Co 3 Blue Co 4 amber Co 5 UV color Co 6 pink Co 7 purple Co 8 Yellow...
- Page 12 5.3.3 Wireless remote control and operation W-2 Upgraded Remote Operation Instructions: • Insert the wireless receiver into the 5-pin socket marked with "Wireless Controller" on the control panel of the machine to connect to the wireless remote control function. • When the machine is heating, the indicator light on the wireless control receiver lights up red.
- Page 13 5.3.6 DMX Channel Assignments and Values DMX DMX control has a total of 16 channels , which are as follows • Channel Function Value Description 000 - 009 No function 010 - 255 Fog on 000 - 011 No function Inner red 012 - 255 Dim to bright...
- Page 14 Run the product in a well-ventilated area until the tank is empty. Do not allow the pump to run dry. Refill with fog fluid to continue using the DSK-1600VM. Run the machine briefly to clear any cleaning solution from the pump and heater.
