Summary of Contents for djpower DSK-3000VST
-
Page 2: Before You Begin
The information and specifications contained in this User Manual are subject to change without notice. DJPOWER assumes no responsibility or liability for any errors or omissions and reserves the right to revise or to create this manual at any time. - Page 3 1.5.1 Personal Safety • Always connect the product to a grounded circuit to avoid the risk of electrocution. • During heating up and operation, the housing will be scalding hot. Do not touch. • The product is very hot during operation and it remains hot for a long time after operation has stopped.
- Page 4 Built-in LCD control, easy to operate, better experience Use only DJPOWER Professional fog fluid PRO-V, otherwise the machine will spray water or block! Pro-V can help create white thick smoke which completely dissipate in a few seconds. It is very suitable for fog jet effect, and this liquid is specially prepared, with very good light transmission, and the colored smoke column will be brighter.
-
Page 5: Product Overview
Product Overview - 4 -... -
Page 6: Product Dimensions
Product Dimensions 3 TECHNICAL SPECIFICATIONS Input Voltage & Rate AC 100-120 V, 50/60 Hz AC 220-240 V, 50/60 Hz Current Limiter Type Breaker Breaker AC Power Current Limiter Specifications 15 A, 250 V 16 A, 250 V Total Power Consumption 1,700 W 3,000 W Heating... - Page 7 0 to 100% switch. AC Plug The DSK-3000VST comes with a power input cord terminated with a Lockable Powercon connector on one end and an EU plug on the other end (EU & China market). If the power input cord that came with...
-
Page 8: Resetting The Breaker
Plug the product’s power cord into the power outlet and continue using as recommended. DMX Linking You can link the DSK-3000VST to a DMX controller using a 3- or 5-pin DMX connection. If using other DMX-compatible products with this product, you can control each individually with a single DMX controller. -
Page 9: Preparing For Operation
• Return the tank back to its compartment in the DSK-3000VST. • Make sure the plastic hose entering the DSK-3000VST from the fluid tank cap is not bent or kinked. • Always connect the product to a grounded circuit. Before power on, make sure it is connected with the rated voltage. - Page 10 Menu Map Parameter Display Description Range DJPOWER Software version Version 1 Welcome Pages Initializing… Initializing DSK-3000VST Heating Up Preparing The machine is heating up >>>>>> Pages Ready to Fog Standby Finished heating up, ready to work. DSK-3000VST Page - 9 -...
- Page 11 Lack of Fluid Lack of fluid, and the display will flicker Please refill DMX Mode & Operation DMX The Machine DSK-3000VST works with a DMX controller. • Connect the product to a suitable power outlet. • Turn the product on.
- Page 12 DJPOWER® DSK-3000VST DMX set the starting address in the 001 - 512 DMX range and uses 9 or 10 DMX channels, which defines the highest configurable address to 503 to have all channels controllable.
- Page 13 10 DMX Channel • Channel Function Value Description 000 - 009 No function 010 - 255 Fog on 000 - 009 No function 010 - 255 Dim to bright 000 - 009 No function green 010 - 255 Dim to bright 000 - 009 No function blue...
-
Page 14: Technical Information
Run the product in a well-ventilated area until the tank is empty. Do not allow the pump to run dry. Refill with fog fluid to continue using the DSK-3000VST. Run the machine briefly to clear any cleaning solution from the pump and heater. - Page 15 Storage 6.3.1 Machine Storage Before storing the machine, clean it as described in the cleaning procedure above; however, only follow steps 1 through 5. Do not refill the tank with fog fluid if storing the machine. Cleaning the system prior to storage will help prevent any particles from condensing inside the pump or heater while not in use.
