Tronair 02-7960C0100 Operation & Service Manual

25 ton 22.7 metric ton axle jack
Hide thumbs Also See for 02-7960C0100:

Advertisement

Quick Links

Tronair, Inc.
1 Air Cargo Pkwy East
Swanton, OH 43558
OPERATION & SERVICE MANUAL
Model: 02-7960C0100
25 Ton (22.7 Metric Ton)
Axle Jack
01/2016  Rev. 01
Phone: (419) 866-6301 | 800-426-6301
Web: www.tronair.com
Email: sales@tronair.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 02-7960C0100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tronair 02-7960C0100

  • Page 1 OPERATION & SERVICE MANUAL Model: 02-7960C0100 25 Ton (22.7 Metric Ton) Axle Jack 01/2016  Rev. 01 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
  • Page 2 REVISION DATE TEXT AFFECTED 01/2016 Original Release...
  • Page 3 Model: 02-7960C0100 25 Ton Axle Jack TABLE OF CONTENTS PAGE PRODUCT INFORMATION ............................1 DESCRIPTION ..............................1 MODEL & SERIAL NUMBER .......................... 1 MANUFACTURER ............................1 USAGE ................................1 SPECIFICATIONS ............................1 SAFETY INFORMATION............................... 1 USAGE AND SAFETY INFORMATION ......................1 TRAINING..................................
  • Page 4 25 Ton Axle Jack This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., its suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
  • Page 5 Model: 02-7960C0100 25 Ton Axle Jack ASSEMBLY INSTRUCTIONS GENERAL INFORMATION This product should be assembled and/or repaired using good workmanship practices and proper tools. All replacement parts must be the same as or equal to the original parts supplied. PRE-USE CHECKS Refer to the Parts List and Illustrations section to identify and ensure that all parts are present.
  • Page 6 Model: 02-7960C0100 25 Ton Axle Jack MAINTENANCE GENERAL COMMENTS  All maintenance and/or repair work should be done using good workmanship practices and proper tools.  The work area should be clean and free of dirt.  When O-rings and backup rings are removed, every effort should be made to avoid the contact of tools with the critical surfaces of parts.
  • Page 7 GUARANTEES/LIMITATION OF LIABILITY Tronair products are warranted to be free of manufacturing or material defects for a period of one year after shipment to the original customer. This is solely limited to the repair or replacement of defective components. This warranty does not cover the...
  • Page 8 Model: 02-7960C0100 25 Ton Axle Jack Parts List When ordering replacement parts/kits, please specify model, serial number and color of your unit. Item Part Number Description N-2066-02-S-B Plug, Hex Head with O-ring TR-2427 Tube, Piston R-3028 Extension, Mechanical G-1300-25050 Pin, Roll...
  • Page 9 Model: 02-7960C0100 25 Ton Axle Jack Parts List Item Part Number Description K-4064 Kit, Pump Replacement; consists of: HC-2008-109 O-ring, Series 2 HC-2377 Assembly, Hydraulic Hand Pump Not Shown G-1151-107210 Screw, Hex Socket Head Cap, -16 x 1" long K-2499 Kit, Cylinder Seal Replacement;...
  • Page 11 APPENDIX I Hydraulic Schematic...
  • Page 13 Hydraulic Schematic...
  • Page 15 APPENDIX I HC-2377 Hand Pump Parts List...
  • Page 17 Model: HC-2377 7400 psi Hand Pump Parts List With Illustrations 01/2008 – Rev. 01 Tronair, Inc. Phone: (419) 866-6301 | 800-426-6301 1 Air Cargo Pkwy East Web: www.tronair.com Swanton, OH 43558 Email: sales@tronair.com...
  • Page 19 ODEL 7400 psi H This product can not be modified without the written approval of Tronair, Inc. Any modifications done without written approval voids all warranties and releases Tronair, Inc., its suppliers, distributors, employees, or financial institutions from any liability from consequences that may occur.
  • Page 20 : HC-2377 ODEL 7400 psi H Parts List Illustration This pump is compatible with MIL-PRF-5606/MIL-H-83282 Hydraulic Fluids only. WARNING Item 31 (H-3095) is a preset relief valve. Do Not disassemble this valve. Replacement parts are available as a preset relief valve assembly. 01/2008 | Rev.
  • Page 21 APPENDIX III Safety Data Sheet MIL-PRF-5606 Hydraulic Fluid...
  • Page 35 APPENDIX IV Declaration of Conformity...
  • Page 37 DECLARATION of CONFORMITY The design, development and manufacture is in accordance with European Community guidelines Axle Jack 02-7960C0100 Relevant provisions complied with by the machinery: 2006/42/EC Relevant standards complied with by the machinery: EN ISO 12100-1 Identification of person empowered to sign on behalf of the manufacturer: Quality Assurance Representative Tronair, Inc.
  • Page 39 APPENDIX IV Maintenance Schedule...
