WATERPROOF SELF-TESTING NON-MAINTAINED EMERGENCY LUMINAIRE WITH WIRELESS COMMUNICATION
OPERATION VOLTAGE
MAXIMUM POWER CONSUMPTION
SUPPLY CURRENT
Prated/Irated
Iemergency
WIRE CROSS SECTION
U-OUT
TX/RX FREQUENCY RANGE
TX POWER
BATTERY (DJWS12-7.0)
MAX. CHARGING VOLTAGE IN NORMAL CYCLE
MAX. VOLTAGE IN STANDBY OPERATION
MIN. - MAX.CHARGE CURRENT / VOLTAGE RANGE
MIN. - MAX. DISCHARGE CURRENT / VOLTAGE RANGE
BATTERY PROTECTION
Rated CURRENT @12V
OPEN CIRCUIT VOLTAGE
CONTROL GEAR FUSE
CONTROL GEAR MAX. TEMPERATURE
CONTROLGEAR MIN/MAX VOLTAGE LOAD OUTPUT
INDICATIONS - CONTROLS
CHARGING TIME
MINIMUM AUTONOMOUS DURATION
LIGHT SOURCE
EMERGENCY ILLUMINATION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
EXTERNAL DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
CONTROL GEAR WITH AUTOMATIC TEST FUNCTION
The lamp controlgear relies upon the luminaire enclosure for protection against accidental contact with live part (7.2 BS EN 61347-2-7)
The controlgear is proof against supply voltage polarity reversal
The controlgear is suitable for LED module only
The controlgear can supply the LED modules only during emergency operation
The controlgear has mains-connected windings of transformer
Manufacturer
Model Number
Voltage Range
Nominal Power
Supply Current
Max Working Voltage for Proper Insulation
LV Supply - Control Conductors Insulation Type
Connections
Temperature (tc)
LED Module Type
Page 1 from 5
TECHNICAL CHARACTERISTICS
Deep discharge and overcharge protection / the control gear will recharge the battery normally after the test of 22.3
POWER-CHARGE indicator, LAMP FAULT–BATT. FAULT indicator, TEST button
EN 60598-1, EN 60598-2-22, ΕΝ 55015, ΕΝ 61547, ΕΝ 61000-3-2
ΕΝ 61000-3-3, ETSI EN 303 446-1 V1.1.0, ETSI EN 300 220-2 V3.1.1
LED MODULE CHARACTERISTICS
Cable connection between main pcb and led module
GRL-29/WP/WL
220-240V AC/50-60Hz
12.6W/13.1VA
57 mA
10W / 500mA
260mA per Lamp
Power Cables: 0.8-2.5mm
30V
868.150-868.450MHz
11dBm
Sealed Lead-Acid 12V/7Ah, 0 ~ 40°C
14.5V
13.8V
230 - 710 mA / 10.5 - 14.5V
755 - 1100 mA / 13.8 - 10.5
1A
23.5V DC
8A/250V FB, 5x20mm
78°C at R11
17 / 23V
24h
180 min
White LEDs
1760lm
IP65
o
5 to 40 C
Up to 95%
ABS/PC, PC
302 x 94 x 345 mm
3683gr.
3 years (1 year for the battery)
Olympia Electronics S.A.
2002163
19-23V
4.9W
260 mA on each lamp
700 V
Basic Insulation
60 °C max. across the board
Built-in
2
923029015_09_002
