Summary of Contents for Electrolux EOB6730X
- Page 1 Electric built-in oven INSTR INSTR UCTION BOOKLET UCTION BOOKLET INSTR INSTR INSTR UCTION BOOKLET UCTION BOOKLET UCTION BOOKLET Model EOB 6730 35690-4401...
- Page 2 Important Safety Information It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred, always ensure that the book is left with the appliance in order that the new owner can get to know the functions of the appliance and the relevant warnings. These warnings are provided in the interest of safety.
- Page 3 Contents For the User For the Installer Important Safety Information Installation Description of the Oven Technical data Controls Electrical Connection Before the First Use Building In Electronic programmer Using the Oven Hints and Tips Using the Conventional Oven Using the Fan Oven Cooking chart-Conventional and Fan Oven Grilling Defrosting...
- Page 4 Description of the Oven 1. Control panel 7. Air Vents for Cooling Fan 2. Oven Control Function Knob 8. Grill 3. Electronic Programmer 9. Oven Light 4. Thermostat Control Knob 10.Oven Fan 5. Mains on Light 11. Rating Plate 6. Thermostat Control Light Oven accessories Grill/roasting pan Anti-tip shelf (x 2)
- Page 5 Controls Oven Function Control Knob The oven is off. Oven light - The oven light will be on without any cooking function. Conventional cooking - The heat comes from both the top and bottom element, ensuring even heating inside the oven. Top heating element - The heat comes from the top element only (outer section).
- Page 6 The Safety Thermostat This oven is provided with a safety thermostat. In case of malfunctioning of the main thermostat, and consequent over-heating, the safety device will stop the power supply to the appliance. If this happens, call your local Service Force Centre.
- Page 7 Electronic programmer 1. Push button for selecting a function 2. Decreasing control button “ ” 3. Increasing control button “ ” 4. Display 5. “Cooking Duration” pilot lamp 6. “End of cooking” pilot lamp 7. “Minute minder” pilot lamp 8. “Time of day” pilot lamp The oven will work only if the time of day has been set.
- Page 8 “End of cooking” function With this function, you can set the oven to switch off automatically when a programmed end of cooking time is over. Place food in the oven, select a cooking function and adjust the cooking temperature. Press button repeatedly to select the “End of cooking”...
- Page 9 Using the Oven Always cook with the oven door closed. Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. The oven has four shelf levels, and is supplied with two shelves.
- Page 10 Using the Conventional Oven When using this setting, heat comes from both the top NOTE and bottom elements. This allows you to cook on a single The action of the cooling fan will depend on how long the level and is particularly suitable for dishes which require oven has been used and at what temperature.
- Page 11 Using the Fan Oven The air inside the oven is heated by the element around the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. The advantage of cooking with this function is energy saving through: Faster Preheating "...
- Page 12 Cooking Chart- Conventional and Fan Oven Cooking times in the tables do not include pre-heating. We recommend to pre-heat the oven for about 10 minutes before cooking. Traditional Cooking Cooking Fan Cooking time TYPE OF DISH NOTES Level Level temp. °C temp.
- Page 13 Grilling Grilling must be carried out with the oven door Hints and Tips closed. The grill pan handles must be removed from Most foods should be placed on the grid in the grill the pan during grilling. Always use oven gloves pan to allow maximum circulation of air to lift the food to remove and replace the grill pan handles.
- Page 14 ! ! ! ! ! How to Use the Thermal Grill Hints and Tips Thermal grilling offers an alternative method of cooking Prepare foods in the same way as for conventional grilling. food items normally associated with conventional grilling. Brush lean meats and fish lightly with a little oil or butter The grill element and the oven fan operate alternately, to keep them moist during cooking.
- Page 15 Cleaning the Oven Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply. This appliance cannot be cleaned with steam or with a steam cleaning machine. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan.
- Page 16 Cleaning The Oven Door The oven door is made up of three glasses. It is possible to remove them for easier cleaning. Warning - The oven door may bang shut if you try to extract the inner glasses when the oven door is still fitted to the oven.
- Page 17 Clean the oven door glass with warm water and a softh cloth only. Never use harsh abrasives as they could damage the special heat-resistant surface of the inner glasses. Once the cleaning is carried out, refit the oven door, following the procedure in reverse. The two glasses in the middle are special glasses that have been treated to resist heat.
- Page 18 The Hinged Grill Some models are fitted with a hinged grill element, to enable you to clean the roof of the oven easily. Before proceeding ensure the oven is cool and is isolated from the electricity supply. Undo the screws which hold the grill in place (see "...
- Page 19 Something not working If the appliance is not working correctly, please carry out the following checks before contacting your local Customer Care Department. SYMPTOM SOLUTION % Check that the current time of day has been set on the The oven does not come on. programmer (see chapter "Setting the time of day") % Check that both a cooking function and temperature have been selected.
- Page 20 Electrical Connection The instructions given below are designed specifically for a qualified installer and should aid him or her to perform all installation, adjustment, and maintenance operations with absolute precision and in compliance with all current legislation and regulations. We strongly recommend that all operations for the installation of your cooker be carryed out by qualified personnel in accordance with existing rules and...
- Page 21 Building In Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. Building In The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant "...
- Page 22 5. Parts and Appliances not supplied by Electrolux are not covered by this warranty. 6. Where you are within an Electrolux service area, this warranty covers the cost of transport of the Appliance to and from Authorised Service Centres of Electrolux and travelling costs for representatives of the Authorised Service Centre to and from your home or business.
- Page 23 Electrolux which cannot be excluded, restricted or modified. To the extent permitted by law, the liability of Electrolux (if any) arising out of or in relation to the Appliance or any services supplied by Electrolux shall be limited (where it is fair and reasonable to do so),:...
- Page 24 The Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
