- Page 1 Cordoba Charcoal Bench Installation Guide...
- Page 3 Cordoba Charcoal Bench POWDER COATED ALUMINIUM FRAME Light Weight Design ITEM NO. : 0583714...
- Page 5 Please carefully read the below warnings and instructions. Save the instructions for future reference. • Please carefully read all instructions before assembly and use. • Please separate and identify all parts, ensuring that you have all parts listed. • Assembly to be carried out by a competent adult. •...
- Page 6 Parts List: Part No. Pictures Description Seat frame Hardware Kit: Part No. Pictures Description Bolt M8 x 50 mm Washer Spring washer Spanner...
- Page 7 Step 1: Put 4pcs legs (B) on the corner of the seat frame (A), inserting bolts (C) with washers (D) and spring wahsers (E) to the holes, then tighten all bolts with spanner (G) one by one. Cover the caps (F) on the bolts (C) at last.
- Page 8 Step 2: Bench is now ready for use.
