1.
Introduction
1.1 Cable
Cable type might vary with different devices, and the actual product shall prevail.
Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water
damage. For the detailed operation, see the FAQ Manual
No
1
2
3
4
For more information about cable ports, see Table 1-1.
Name
Description
Connects to sound-pick-up device to receive audio signal.
Audio input
Connects to speaker to output audio signal.
Audio output
Ethernet port
Includes alarm signal input and output ports, the number of
I/O ports might vary on different devices. For detailed
Alarm I/O
information, see "Error! Reference source not found. Error!
Reference source no t found.."
Figure 1-1 Cables
Table 1-1 Cable information
Audio input port is available on
select model.
Audio output port is available on
select model.
Connects to network with network cable.
Provides power to the device with PoE.
PoE is available on
select model.
