Summary of Contents for CP Plus CP-UNC-VC41L5C-VMDS-V2
- Page 1 Quick Start Guide Version 1.0.3...
- Page 2 Foreword General This Quick Start Guide (hereinafter referred to be "the Guide") introduces the functions, installation, and operations of the camera. Safety Instructions The following categorized signal words with defined meaning might appear in the guide. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
- Page 3 • Please visit our website, contact the supplier or customer service if there is any problem occurred when using the device. • If there is any uncertainty or controversy, please refer to our final explanation. Important Safeguards and Warnings This section introduces content covering the proper handling of the device, hazard prevention, and prevention of property damage.
- Page 4 ● The Bullet cover is an optical component. Do not directly touch or wipe the surface of the cover during installation. Operation Requirements ● The cover must not be opened while the device is powered on. ● Do not touch the heat dissipation component of the device to avoid the risk of getting burnt. ●...
- Page 5 Table of Contents Introduction ..........................6 Cable ..............................6 Connecting Alarm Input/Output ......................7 Network Configuration ......................8 2.1 Initializing Device ..........................8 Modifying Device IP Address ......................10 Installation ..........................11 Packing List ............................11 Dimensions ............................11 Installing the Camera .......................... 12 3.3.1 Installation Method Figure 3-3 Installation...
- Page 6 Introduction 1.1 Cable Cable type might vary with different devices, and the actual product shall prevail. Please waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual Figure 1-1 Cables For more information about cable ports, see Table 1-1.
- Page 7 Name Description Inputs 12V DC power. Please be sure to supply power as instructed in the Guide. 12V DC power Device abnormity or damage could occur if input power is not supplied correctly. For more information about I/O port, see Table 1-2. Table 1-2 Alarm information Port Port Name...
- Page 8 Step 3 Log in to web page, and then configure alarm input and alarm output in alarm settings. ● The alarm input on the web page is corresponding to the alarm input end of the I/O port. There will be high level and low-level alarm signal generated by the alarm input device when alarm occurs.
- Page 9 Step 3 Click Search setting. The setting interface is displayed. Step 4 Enter the start IP and end IP of the network segment in which you want to search devices, and then click OK. All the devices found in the network segment are listed. Step 5 Select one or several devices which Status are Uninitialized, and then click Initialize.
- Page 10 Modifying Device IP Address You can modify IP address of one or multiple devices in one time. This section is based on modifying IP addresses in batch. Modifying IP addresses in batch is available only when the corresponding devices have the same login password.
- Page 11 Installation 3.1 Packing List ● The tool required for the installation such as electric drill is not provided in the package. ● The operation manual and related tool information are contained in the disk or the QR code. Figure 3-1 Packing list 3.2 Dimensions Figure 3-2 Dimensions: Model A (mm [inch])
- Page 12 3.3 Installing the Camera 3.3.1 Installation Method Figure 3-3 Installation Method 3.3.2 Installing SD Card ● SD card slot is available on select models. ● Disconnect the power before installing or removing the SD card. figure 3-4 Install SD card...
- Page 13 3.3.3 Detaching camera Figure 3-5 Detaching camera 3.3.4 Attaching the Camera Make sure that the mounting surface is strong enough to hold at least three times the weight of the camera and bracket. Option 1: - Cable going through the side cable tray. Figure 3-6 Cable going through the side cable tray...
- Page 14 Option 2: - Cable going through the mounting surface. Figure 3-7 Cable going through the mounting surface 3.3.5 Installing Waterproof Connector This part is needed only when a waterproof connector comes with the camera and the camera is used outdoors. Figure 3-8 Install waterproof connector...
- Page 15 3.3.6 Adjusting Lens Angle • Vertical rotation ring is available on select models, which fails to support image rotation. Please refer to the real model for more details. • IR light layout is different according to different models; please refer to the real model for more details. •...
- Page 16 Thanks for Choosing CP Plus! Website: - www.cpplusworld.com Email id: - sales@cpplusworld.com; support@cpplusworld.com...
