2.2
Modifying Device IP Address
You can modify IP address of one or multiple devices in one time. This section is based on modifying IP
addresses in batch.
Modifying IP addresses in batch is available only when the corresponding devices have the same login
password.
Step 1 Double-click "IP Finder.exe" to open the tool.
Step 2 Click
. The Modify IP interface is displayed. See Figure 2-1.
Step 3 Select the devices which IP addresses need to be modified, and then click Modify IP. The Modify IP
Address interface is displayed. See Figure 2-3.
Step 4 Select Static mode and enter start IP, subnet mask and gateway.
IP addresses of multiple devices will be set to the same if you select Same IP.
If DHCP server is available in the network, devices will automatically obtain IP addresses from DHCP
server when you select DHCP.
Step 5 Click OK.
Figure 2-3 Modify IP Address interface
