- Page 1 Eyeball Network Camera Quick Start Guide Version 1.0.1...
- Page 2 Foreword General Safety Instructions This manual introduces the functions, installation and operations of the camera. following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
- Page 3 The manual would be updated according to the latest laws and regulations of related regions. For detailed information, see the paper manual, CD-ROM, QR code or our official website. If there is inconsistency between paper manual and the electronic version, the electronic version shall prevail. All the designs and software are subject to change without prior written notice.
- Page 4 Important Safeguards and Warnings Electrical Safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1. Please note that the power supply requirement is subject to the device label.
- Page 5 Please strengthen the protection of network, device data and personal information by adopting measures which include but not limited to using strong password, modifying password regularly, upgrading firmware to the latest version, and isolating computer network. For some device with old firmware versions, the ONVIF password will not be modified automatically along with the modification of the system password, and you need to upgrade the firmware or manually update the ONVIF password.
- Page 6 Table of Contents Foreword ....................................II General .................................... II Revision History ................................II Protect Privacy Notice ..............................II About the Manual ................................II Important Safeguards and Warnings ..........................IV Electrical Safety ................................IV Environment .................................. IV Operation and Daily Maintenance ..........................IV Regulatory Information ..............................
- Page 7 1. Cable Cable type might vary with different devices, and the actual product shall prevail. Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1.
- Page 8 2. Network Configuration The IP address of all the cameras is the same when leaving factory (default IP 192.168.1.250), in order to make the camera get access to the network smoothly, please plan the useable IP segment reasonably according to the actual network environment. 2.1 Initializing Devices Figure 2-1 Device Search Select one or several uninitialized devices.
- Page 9 Select the devices that need to be initialized, and then click Initialize. The Device initialization screen is displayed. Figure 2-3 Set Password Set the initialization parameters for the device. The Device Initialization screen is displayed. The Initialization screen is displayed after initializing is completed. Click the success icon ( ) or click the failure icon ( ) for the details.
- Page 10 2.2 Modifying IP Figure 2-5 Device Password Find the device you want to modify IP, and then click the IP Modification button The Modify IP Address dialog box is displayed. Figure 2-6 Set Password Select the mode for setting the IP address according to the actual situation. Click OK to complete modification.
- Page 11 2.3 Logging in Web Interface Step 1 Open IE browser, then enter the IP address of the device in the address bar, and then press Enter. If the setup wizard is displayed, finish the settings as instructed. Step 2 Enter the username and password in the login box, and then click Login. Step 3 For first time login, click Here to Download Plugin, and then install the plugin as instructed.
- Page 12 3. Installation 3.1. Packing List The tool required for the installation such as electric drill is not provided in the packing. The operation manual and related tool are contained in the disk or the QR code, and the actual packing shall prevail. Figure 3-1 Packing List 3.2.
- Page 13 3.3. Installing Device 3.3.1. Installation Direction Figure 3-3 Installation Direction 3.3.2. Installation Method...
- Page 14 3.3.3. Attaching Device Make sure the mounting surface is strong enough to hold at least three times of the weight of the device and bracket. Option1:- Cable going through the side cable tray.
- Page 15 Option 2: - Cable going through the mounting surface.
- Page 16 3.3.4. Installing Waterproof Connector (Optional) This part is needed only when there is waterproof connector come with the device and the device is used outdoor. Figure 3-6 Install waterproof connector 3.3.5. Adjusting Lens Angle Figure 3-7 Adjust Lens Angles...
- Page 17 Thanks for Choosing CP Plus! Website: - www.cpplusworld.com Email id: - sales@cpplusworld.com; support@cppluswld.com...
