Eyeball Network Camera Quick Start Guide Version 1.0.1...
Page 2
Foreword General This manual introduces the functions, installation and operations of the camera. Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a medium or low potential hazard which, if not avoided, could result in slight or moderate injury.
Page 3
All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the manual. Please contact the customer service for the latest program and supplementary documentation. There still might be deviation in technical data, functions and operations description, or errors in print.
Page 4
Important Safeguards and Warnings Electrical Safety All installation and operation should conform to your local electrical safety codes. The power source shall conform to the Safety Extra Low Voltage (SELV) standard, and supply power with rated voltage which conforms to Limited power Source requirement according to IEC60950-1.
Page 5
Do not touch the image sensor (CMOS) directly. Dust and dirt could be removed with air blower, or you can wipe the lens gently with soft cloth that moistened with alcohol. Device body can be cleaned with soft dry cloth, which can also be used to remove stubborn stains when moistened with mild detergent.
Page 6
residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. For class B device, these limits are designed to provide reasonable protection against harmful interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation.
Page 7
Table of Contents Foreword ............................... II Instructions ..............................II Revision History ............................II Protect Privacy Notice..........................II About the Manual ............................II Important Safeguards and Warnings ......................IV Electrical Safety ............................IV Environment ............................IV Operation and Daily Maintenance ......................IV Regulatory Information..........................
Page 8
1. Cable Cable type might vary with different devices, and the actual product shall prevail. Waterproof all the cable joints with insulating tape and waterproof tape to avoid short circuit and water damage. For the detailed operation, see the FAQ Manual. Figure 1-1 Cable list For more information about cable ports, see Table 1-1.
Page 9
2. Network Configuration The IP address of all the cameras is the same when leaving factory (default IP 192.168.1.250), in order to make the camera get access to the network smoothly, please plan the useable IP segment reasonably according to the actual network environment. 2.1 Initializing Devices Figure 2-1 Device Search...
Page 10
Select one or several uninitialized devices. Click Figure 2-2 Set Device Password. Set the initialization parameters for the device. The Device Initialization screen is displayed. Initialization screen is displayed after initializing is completed. Click success icon ( ) or click the failure icon ( ) for the details. Figure 2-3 Device Initialized Click Finish to finish initialization.
Page 11
2.2 Modifying IP Figure 2-4 Device Search Find the device you want to modify IP, and then click the IP Modification button The Modify IP Address dialog box is displayed. Figure 2-5 IP Modification Select the mode for setting the IP address according to the actual situation. Click OK to complete modification.
Page 12
2.3 Logging in Web Interface Step 1 Open IE browser, then enter the IP address of the device in the address bar, and then press Enter. If the setup wizard is displayed, finish the settings as instructed. Step 2 Enter the user name and password in the login box, and then click Login. Step 3 For first time login, click Here to Download Plugin, and then install the plugin as instructed.
Page 13
Figure 3-1 Packing List 3.2. Dimension Following figures are for reference only, and the actual product shall prevail. (Unit: mm [inch]) Figure 3-2 Dimension...
Page 15
3.3.2. Installation Method Option 1: - Cable going through the side cable tray. Figure 3-4 Installation Method (option 1)
Page 16
Option 2: - Cable going through the mounting surface. Figure 3-5 Installation Method (option 2)
Page 17
3.3.4. Installing Waterproof Connector (Optional) This part is needed only when there is waterproof connector come with the device and the device is used outdoor.
