Summary of Contents for Quality Heating ISP 350
- Page 1 Installati on instructi ons for infrared panels ISP Models • ISP 350 ti ll ISP 1200 • ISP 351 ti ll ISP 851 Please note and keep in a safe place! Subject to change without noti ce! Id_Nr. MAG-000352 • ISP Moti v...
- Page 2 Installati on instructi ons ISP infrared heater Summary: 1. important safety instructi ons 2. general informati on 3. assembly Drill holes 4. Electrical connecti on 5. Operati ng the RF receiver 6. Customer service 7. guideline 8. Contact details Quality Heati ng...
- Page 3 Installati on instructi ons ISP infrared heater • 1. important safety instructi ons This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabili- ti es, or lack of experience and knowledge, unless they have been given supervision or instructi on concerning use of the appliance by a person responsible for their safety.
- Page 4 Installati on instructi ons ISP infrared heater • Do not use the appliance in rooms where petrol, paint or other fl ammable liquids are stored. • The appliance is not suitable for outdoor use. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabiliti es or lack of experience and knowledge if they have been given supervision or instructi on concerning use of the ap-...
- Page 5 Installati on instructi ons ISP infrared heater Cauti on: Some parts of the product can become very hot and cau- se burns. Special care must be taken when children and vulnerable persons are present. WARNING - THIS DEVICE MUST BE GROUNDED The heater may only be operated with an AC power supply and the operati ng voltage printed on the rati ng plate.
- Page 6 Installati on instructi ons ISP infrared heater 2. General informati on We hope you enjoy using your infrared radiant panel. The appliance off ers you a high level of operati ng convenience and energy-saving operati on. Before commissioning, please inform yourself about the correct installati on, commissioning, operati on and maintenance.
- Page 7 1224 1224 ISP 851 1524 A1/2=762 1524 B2/2=762 Drill spacing holes in [mm] all models of width 600 mm incl. RF ISP 350 ISP 450 ISP 750 ISP 950 1224 1224 ISP 1200 1524 A1/2 = 762 1524 B2/2=762 Mounti ng the devices Distances: The distance between the bott om edge of the heater and the fl...
- Page 8 Installati on instructi ons ISP infrared heater 4. Electrical connecti on The ISP heati ng panel is equipped with a plug. Removing the ISP heati ng panels Disconnect the appliance from the mains before dismantling. Lift the panel verti cally upwards and sideways to release it from the screws.
- Page 9 Installati on instructi ons ISP infrared heater 5. programming the receiver (only for the „RF“ models) nstallation Récepteur radio 16A Radio-controlled receiver 16A Funkempfänger 16A Receptor vía radio 16A Ricevitore via radio 16A Radiorreceptor de 16 A Draadloze ontvanger 16A 230V~ 50 Hz Réf.
- Page 10 Installati on instructi ons ISP infrared heater X3D -> X2D / X2D -> X3D >3s 230V~ ..50 Hz When the unit is switched on, the L2 LED flashes (twice (X2D), 3 times (X3D)). - Press the button briefly to toggle between them. - Confirm by pressing the button for 3 seconds until LED L1 flashes.
- Page 11 Installati on instructi ons ISP infrared heater 6. Customer service Your ISP heati ng panel has been carefully manufactured and checked several ti mes before de- livery. Should you nevertheless noti ce a problem or have any questi ons about handling, please contact our customer service.
- Page 12 With adapti ve start control With limitati on of heati ng ti me With a black lamp sensor Aizo Ltd, Quality Heating | 71-75 Shelton Street Contact: Covent Garden | London | WC2H |UK Aizo Ltd, Quality Heating | 71-75 Shelton Street Errors and technical modifi...
