INFRARED HEATER
READ AND SAVE THESE INSTRUCTIONS
Read all instructions carefully before setting up and operating this unit.
This manual is designed to provide you with important information needed to setup,
operate, maintain for your radiant heaters.
Failure to follow these instructions may damage and/or impair its operation and void
the warranty.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QH16-18A and is the answer not in the manual?

Questions and answers

Summary of Contents for Quality Heating QH16-18A

  • Page 1 INFRARED HEATER READ AND SAVE THESE INSTRUCTIONS Read all instructions carefully before setting up and operating this unit. This manual is designed to provide you with important information needed to setup, operate, maintain for your radiant heaters. Failure to follow these instructions may damage and/or impair its operation and void the warranty.
  • Page 2: Safety Precautions

    Health and fresh! 1. SAFETY PRECAUTIONS This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 3: Performance Features

    Health and fresh! 11. Users cannot repair the radiant heater,if equipment failure and need maintenance, please contact authorized servicer. 12. Do not install and use radiant heaters on areas occur with flammable,explosive,easy to shock. 13. Please do not insert any metal or foreign objects to inside of radiant heater, to avoid accident or personal injury.
  • Page 4: Working Condition

    Health and fresh! Physical therapy: The heat radiant can change body microcirculation, cell organization under skin producing resonance, clearing the barrier of microcirculation, adjusting and balancing nervous system, promoting metabolism, increasing body physical power. It is very good for people's health. Far-infrared radiant heaters are produced by unique design and manufacturing technique.
  • Page 5: Spare Parts

    Health and fresh! 7. SPARE PARTS Expansion screw fixing plate Stainless steel expansion bolt 8. INSTALLATION INSTRUCTION(JH-NR16-18A) Specifications Installation decomposition...
  • Page 6 Health and fresh! Step 1:Select the position of the heater on the ceiling, and remove the two aluminum gussets in the installation position and the two aluminum gussets in the side. Step 2: Right above the installation position of the heater, make a 10mm diameter bolt hole with a percussion drill, insert the stainless steel expansion bolt, and fix the "expansion screw fixing plate".
  • Page 7 Health and fresh! Step 5: Connect the lead wires of the heater to the corresponding power cable. (Note: Make sure the product is completely grounded!) Step 6: Reinstall the removed aluminum gussets.
  • Page 8: Installation Instruction

    Health and fresh! 8. INSTALLATION INSTRUCTION Specifications Installation decomposition...
  • Page 9 Health and fresh! Step 1: Select the position for installing the heater on the ceiling, and remove the 3 aluminum gussets in the installation position and the 3 aluminum gussets in the side. Step 2: Right above the installation position of the heater, Make a 10mm diameter bolt hole with a percussion drill , insert the stainless steel expansion bolt, and fix the "expansion screw fixing plate",The hole spacing between the two "expansion screw fixing plates"...
  • Page 10 Health and fresh! Step 4: Ensure the surface of the heater is flush with the aluminum gusset by adjusting the length of the wire rope. Step 5: Connect the lead wires of the heater to the corresponding power cable. (Note: Make sure the product is completely grounded!) Step 6: Reinstall the removed aluminum gussets.
  • Page 11: Inspection Items After Installation

    Health and fresh! 9. INSPECTION ITEMS AFTER INSTALLATION Situation caused by improperly i Items Items to be checked to be checked installation Is installation stable? The equipment may fall off or shake. Is heat insulation adequate? Damage objects close to equipment. Does power voltage same as voltage Equipment failure.
  • Page 12: Packing List

    Health and fresh! 12. PACKING LIST Name Heater 1 pc Expansion screw fixing plate 2 pc Stainless steel expansion bolt M8 * 60 13. SPECIFICATIONS Dimension Package size Net weight Gross weight Model No. (mm) (mm) (kg) (kg) QH16-18A 600*300*90 650*355*150...
