Audix ADX10FLP Quick Start Manual

ADX10FLP
OVERVIEW
The ADX10FLP is characterized with a uniformly controlled cardioid polar pattern,
helping to isolate the area or section being miked from other instruments or vocals
on stage. With a smooth and accurate frequency range of 50 Hz - 18 kHz, the
ADX10FLP is lightweight, low profile and will provide natural sound with exceptional
transient response.
The ADX10FLP, specifically for use with a standard flute, includes a clip that attaches
to the headstock of a flute, an 8' cable terminating to a mini XLR-f connector and a
phantom power adapter (APS911). Other model versions include the ADX10FL for use
with the Audix RAD360 wireless system.
Manufactured to high standards and tight tolerances, the ADX10FLP features a
modular threaded capsule, machined brass body with matte black finish, high quality
shielded microphone cable and a variety of optional accessories.
MODEL VARIATIONS
ADX10FL - Same as ADX10FLP without the APS911 phantom power adapter
SUPPLIED ACCESSORIES
MCFLUTE - Clip for ADX10FLP flute mic. Fits standard size flutes.
WS10 - External foam windscreen for reducing wind, sibilance, and pop noise
P1 - Carrying pouch
APS911 - Optional phantom power adapter for use with electret condenser
microphones. Runs on AA batteries when phantom power is not available. Features
on/off switch and bass roll-off filter.
OPTIONAL ACCESSORIES
MC10L - Optional alligator style lapel clip with spring tension wire loop.
APS910 - 48 V phantom power adapter for use with electret
condenser microphones.
MCFLUTE WS10
Condenser Instrument
Microphone
P1 APS911
ADX10FLP
FEATURES
. Miniature condenser flute microphone
. Natural, accurate sound reproduction
. May be used wired or with RAD360 Wireless System
. Designed, assembled & tested in the USA
. 3 year warranty
APPLICATIONS
. Flute (Standard size)
MC10L APS910
