f50
Dynamic Vocal
Microphone
OVERVIEW
The f50 is a dynamic vocal microphone designed for a wide variety of live and studio
applications. The f50 is known for its warm, natural sound reproduction, resistance to
feedback and ability to handle high sound pressure levels without distortion.
The f50 is characterized with a unidirectional and uniformly controlled cardioid
polar pattern which helps to isolate the vocals from the rest of the instruments on
stage. With a wide frequency range of 50 Hz – 16 kHz, the f50 is also available with a
noiseless, magnetic on-off switch (f50S).
The f50 is designed to sound clear and full bodied on small to mid-size PA systems.
The f50 is well balanced, comfortable to hold, durable and manufactured with very
high standards and tight tolerances. Roadworthy construction includes a precision
cast zinc alloy, black e-coat finish, steel mesh grill and gold plated XLR connector.
MODEL VARIATIONS
f50CBL - Same as f50 with high performance XLR-XLR low impedance
microphone cable
f50S - Same as f50 with On-Off switch
SUPPLIED ACCESSORIES
MC1 - Heavy-duty nylon molded clip with brass insert
P1 - Carrying pouch
OPTIONAL ACCESSORIES
CBLDR25 - 25' premium right angle XLR-XLR balanced mic cable. Quad conductor,
twisted pair with braided shield for maximum conductivity. 6 mm PVC jacketed.
CBL20 - 20' premium XLR-XLR balanced mic cable. Quad conductor, twisted pair with
braided shield for maximum conductivity. 6 mm PVC jacketed.
TRIPOD - Metal tripod desktop stand for use with any 5/8" threaded mic clip.
T50K - Professional impedance matching transformer that allows a low impedance
mic to be connected to a high impedance input.
WS357 - Optional high quality external foam windscreen for reducing wind, sibilance,
and pop noise.
MC1
P1
CBLDR25
FEATURES
· All purpose, affordable vocal mic for live sound and
home studios
· Warm, natural vocal sound optimized for small to
mid-size PA systems
· Cardioid pattern for feedback resistance
· Rugged all metal body, low impedance
· 3 year warranty
APPLICATIONS
· Stage, karaoke, corporate, AV, rehearsal studio,
education, Houses of Worship
· Home studio - vocal and instrument
· Acoustic instruments
· Drums, guitar cabs
CBL20
TRIPOD
T50K
WS357
f50
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Audix f50
Summary of Contents for Audix f50
- Page 1 The f50 is characterized with a unidirectional and uniformly controlled cardioid polar pattern which helps to isolate the vocals from the rest of the instruments on stage. With a wide frequency range of 50 Hz – 16 kHz, the f50 is also available with a noiseless, magnetic on-off switch (f50S).
- Page 2 SERVICE AND WARRANTY: This microphone is under warranty for a period of 3 years to be free of defects in material and workmanship. In the event of a product failure due to materials or workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions.
