Structural Concepts Fusion GHS456R User Manual page 8

Installation: Start Up
Plug Case In/Turn On Main Power Switch:
• Do not use an extension cord with this case.
• Do not operate this equipment with a damaged cord,
plug, or outlet.
• Ensure that the main power switch is off.
• Route the power cord through the appropriate knockout
in the rear panel. Install the supplied cord bushing in the
knockout hole. Do not install cord without bushing.
• Plug the cord into a certified 120V electrical outlet with
ground.
• Turn the main power switch on.
• Coil fans should turn on.
• From inside of the case, check for discharge air from
front baffle, to confirm that the fans are functioning
properly.
• When the case is in a start-up mode or has been idle for
a long period of time, the case may require 75 minutes
running time to pull down the temperature.
• Turn lights on.
• Light switch is located on the ceiling of merchandising
area.
• The lights should come on at the same time.
• Always maintain front and rear airflow clearance of four
inches.
• Obstruction or restriction of air can void warranty.
• Note: Case temperature setting is determined by case
size. Temperature is controlled by a thermostat.
Fusion® User Manual Fusion® User Manual
Main Power Switch
Light Switch
