Summary of Contents for CHIEF PG3A
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Projector Guard Security Cage PG3A...
- Page 2 Reinforce the structure as required before installing the Chief® is a registered trademark of Milestone AV Technologies. component. All rights reserved. IMPORTANT WARNINGS AND...
- Page 3 Installation Instructions PG3A DIMENSIONS 2X 5.00 644.53 25.38 50.80 2.00 1.5" NPSM COUPLER WILL 89.69 ALLOW FOR 3.75" OF FRONT 3.53 TO BACK ADJUSTABLE SHIFT 633.10 25.00 ID 24.93 288.50 362.85 11.36 14.29 FROM BOTTOM OF RPA TO SURFACE OF RIVETS 638.79...
- Page 4 PG3A Installation Instructions TOOLS REQUIRED FOR INSTALLATION 5/32" [security] 7/16" PARTS A (1) [PG3A] B (2) [RPA/RPM Interface] C (1) 5/32" [security] D (4) E (4) 10-24 x 3/8" F (4) H (4) G (4) J (4) 1/4-20 x 3/4"...
- Page 5 1/4-20 x 1-1/2" buttonhead cap screws (F) and four nylon spacers (H). (See Figure 3) NOTE: The PG3A should not be used in a flush ceiling mount. NOTE: The projector must be removed from the mount before installing this accessory.
- Page 6 PG3A Installation Instructions Configure Fillers on the Projector Guard NOTE: The open cutout in the projector guard is designated as the FRONT of the guard. Thumb nuts Remove and keep the two security screws from the top and bottom of the front (on side that will swing open). Leave the...
- Page 7 Installation Instructions PG3A Slide the projector guard (A) into position over the projector, while aligning the slots on the projector guard with the screws in the RPA/RPM mount. (See Figure 8) Align the projector to sit evenly in the projector guard (A).
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Office No. 1 on 12/F, Shatin Galleria...
