Summary of Contents for Midea MDDM-20DEN7
- Page 1 DEHUMIDIFIER Owner’s Manual & Installation Manual IMPORTANT NOTE: Read this manual carefully before installing or operating your new machine. Make sure to save this manual for future reference.
- Page 3 Table of Contents Safety Precautions Safety Precautions ................................01 Preparation Identification of parts................................09 Installation instructions..............................09 Strorage instructions................................09 Caster installation and disassembly instruction........................09 Design Notice..................................10 Positioning the unit................................10 When using the unit................................10 Operating Instructions Control Panel Features..............................11 Other features..................................13 Removing the collected water............................15 Care and Maintenance Clean the grille and case..............................17 Clean the bucket ................................17...
- Page 4 Safety Precautions Read Safety Precautions Before Operation and Installation To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. WARNING CAUTION This symbol indicates the possibility of...
- Page 5 CAUTION This appliance can be used by children aged from 8 years and above and person with reduced • physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 6 Note about Fluorinated Gasses(Not applicable to the unit using R290 Refrigerant) 1. Fluorinated greenhouse gases are contained in hermetically sealed equipment. For specific information on the type, the amount and the CO equivalent in tonnes of the fluorinated greenhouse gas(on some models), please refer to the relevant label on the unit itself. 2.
- Page 7 WARNING for Using R32/R290 Refrigerant Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). Do not pierce or burn.
- Page 8 1.Transport of equipment containing flammable refrigerants See transport regulations 2.Marking of equipment using signs See local regulations 3.Disposal of equipment using flammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
- Page 9 8)Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: The charge size is in accordance with the room size within which the refrigerant containing parts are installed;...
- Page 10 9.Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 10.Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 11 14.Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
- Page 12 Preparation Identification of parts NOTE:All the illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The actual shape shall prevail. The unit can be controlled by the unit control panel . air outlet grille control panel handle air intake grille...
- Page 13 bottom of unit caster block Disassembly: 1.To remove the caster , use a screwdriver to prop up the block, then take it down. 2.Then remove the caster. Design Notice In order to ensure the optimal performance of our products, the design specifications of the unit are subject to change without prior notice.
- Page 14 Operating Instructions Control Panel Features NOTE: The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly different according to the models. Your machine may not contain some indicators or buttons. The actual shape shall prevail. Indicator Function Indicator...
- Page 15 UP( )/DOWN( ) buttons PUMP feature(On some models) · Press and hold on the Up/Down buttons 2 second · Humidity Set Control buttons to initiate PUMP feature.Press and hold on the Up/ In Setting dehumidifying mode, The humidity level can be Down buttons 2 seconds again to stop PUMP feature.
- Page 16 Protection Code: Setting dehumidifying mode P2-Bucket is full -- Empty the bucket and replace it in At setting dehumidifying mode, the unit can be adjusted in a the right position. range 35%~85%, and the humidity setting can be adjusted Eb-Bucket malfunction--Replace the bucket in the right (increase/decreasing) in 5%.
- Page 17 Bucketless mode(on some models) √ The dehumidifier can be used without bucket when the unit is under Bucketless mode. The unit will not reminds the water to be full after entering the bucketless mode, therefore, it is suggested that: 10cm or more 1.
- Page 18 Removing the collected water Note: There are two ways to remove collected water. · When you remove the bucket, do not touch 1. Use the bucket any parts inside of the unit. Doing so may · When the unit is off,if the bucket is full, the unit will damage the product.
- Page 19 3. Pump draining (on some models) · Water can be automatically emptied into a floor drain · select the desired humidity setting and fan speed on or a suitable drainage facility by attaching the pump the unit for pump draining to start. Note: The pump operation on light blinks at 1Hz when drain outlet with a pump drain hose(Φod=1 ′′,...
- Page 20 Care and Maintenance Care and cleaning of the dehumidifier Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. Clean the Grille and Case · Use water and a mild detergent. Do not use bleach or abrasives. ·...
- Page 21 When not using the unit for long time periods · After turning off the unit, wait one day for water collecting before emptying the bucket. · Clean the main unit, water bucket and air filter. · Cover the unit with a plastic bag. ·...
- Page 24 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. Any updates to the manual will be uploaded to the service website, please check for the latest version. CD001UI-DM 16120100000776 20210628...
- Page 25 备注： 1. 基准说明书只适合DM平台所有常规机型。 2. 基准说明书为单英文版本，不含型号及商标，也无制造商信息，请业务根据所 销售国家或者区域的法规要求，使用对应的官方语言版本，增加型号及其它 法规要求信息，重新申请订单编码说明书。 3. 基准说明书的显示标贴为DM全功能，包含了目前已有的所有图标和功能按键及其 操作说明。 4. 后面的选配页面标明了对应的不同机型(可燃冷媒与非可燃冷媒）下要修改的内容。 此面及后面的页面无需印刷 技术 要求： 1.80g双胶纸 2.尺寸：A4(210*290) 3.颜色：黑白 4.注意：排版时注意页码数字都是靠外面的，以便翻阅 5.装订。...
- Page 26 当机型为非可燃冷媒机型时，请进行以下变更： 删除Pg4-Pg8(WARNING for Using R32/R290 Refrigerant)内容。...
