USB to Isolated RS-485 Converter
Warranty
All products manufactured by ICP DAS are warranted against
defective materials for a period of one year from the date of delivery
to the original purchaser.
Warning
ICP DAS assumes no liability for damages consequent to the
use of this product. ICP DAS reserves the right to change this
manual at any time without notice. The information furnished by ICP
DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, or for any
infringements of patents or other rights of third parties resulting from
its use.
Copyright
Copyright 2011 by ICP DAS Co., LTD. All rights reserved
worldwide.
Trademark
The names used for identification only may be registered
trademarks of their respective companies.
tM-7561
User Manual
1
tM-7561 Series User Manual
Publication Aug, 2024 Ver. 1.03
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA tM-7561 Series
Summary of Contents for ICP DAS USA tM-7561 Series
- Page 1 Series User Manual USB to Isolated RS-485 Converter tM-7561 User Manual Warranty All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for damages consequent to the use of this product.
- Page 2 Series User Manual Introduction The tM-7561 is a cost-effective USB to RS-485 converter. Connecting the tM-7561 to a PC, you get one RS-485 port that allows you to access RS-485 devices through the USB interface. Like the I-7520, the tM-7561 contains "Self-Tuner" chip auto-tunes the baud rate and data format to the RS-485 network.
- Page 3 Series User Manual Hardware Specifications Specifications Model tM-7561 Interface Fully Compliant with the USB 1.1/2.0/3.0 RS-485 Data+, Data- Transfer Distance Max. 1,200 m at 9.6 kbps; Max. 400 m at 115.2 kbps Self-Tuner Asic Inside Speed 300 ~ 115200 bps...
- Page 4 Series User Manual Installing the tM-7561 Drivers (Win10/Win11) To install the tM-7561 series drivers, follow the procedure described below: Step 1: Double click the “USB-2514_tM-7561_I-756xU_Driver_xxxxx.exe” to execute the driver installer application. Step 2: Click the “Next>” button to start installation.
- Page 5 Series User Manual Step 3: Select the destination folder. The default path is C:\ICPDAS\USB_2514_tM_7561_I_756xU. Verify that the destination path is correct and click the “Next>” button. Step 4: Click the “Next>” button. Publication Aug, 2024 Ver. 1.03...
- Page 6 Series User Manual Step 5: A warning dialog box will be displayed asking you to confirm whether you want to install the device software. The type of warning that is displayed will depend on which operating system is being used. Refer to the following figures for details.
