USB to Isolated RS-485 Converter
Warranty
All products manufactured by ICP DAS are warranted against
defective materials for a period of one year from the date of delivery
to the original purchaser.
Warning
ICP DAS assumes no liability for damages consequent to the
use of this product. ICP DAS reserves the right to change this
manual at any time without notice. The information furnished by ICP
DAS is believed to be accurate and reliable. However, no
responsibility is assumed by ICP DAS for its use, or for any
infringements of patents or other rights of third parties resulting from
its use.
Copyright
Copyright 2011 by ICP DAS Co., LTD. All rights reserved
worldwide.
Trademark
The names used for identification only may be registered
trademarks of their respective companies.
tM-7561

User Manual

1
tM-7561 Series User Manual
Publication Oct, 2012 Ver. 1.02

Advertisement

loading

Related Manuals for ICP DAS USA TM-7561

Summary of Contents for ICP DAS USA TM-7561

  • Page 1: User Manual

    Series User Manual USB to Isolated RS-485 Converter tM-7561 User Manual Warranty All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser. Warning ICP DAS assumes no liability for damages consequent to the use of this product.
  • Page 2 PC, you get one RS-485 port that allows you to access RS-485 devices through the USB interface. Like the I-7520, the tM-7561 contains "Self-Tuner" chip auto-tunes the baud rate and data format to the RS-485 network. The tM-7561 module derives its power from the USB port and doesn't need external power adapter.

  • Page 3: Hardware Specifications

    Series User Manual Hardware Specifications Specifications Model tM-7561 Interface Compatibility: USB 1.1 and 2.0 standards RS-485 Data+, Data- Transfer Distance Max. 1,200 m at 9.6 kbps; Max. 400 m at 115.2 kbps Maximum Supported 256 (Without repeater) RS-485 Devices...

  • Page 4: Usb Driver Installation

    Manually install usb driver Please execute “USB-2514_tM-7561_Driver.exe“ (the driver file name for Step1. v2.08.24 or newer) file first to install necessary driver files of tM-7561 to system. Step2. Locate the USB port of your computer and plug in the tM-7561.
  • Page 5 Series User Manual Step4. Select “Install the software automatically (Recommended)” → Select “Next” Step5. If it is pop-up a new windows that “Hardware Installation”, please select “Continue Anyway” Publication Oct, 2012 Ver. 1.02...
  • Page 6 Series User Manual Step6. Select “Finish” to finish. Step7. Select “No, not this time” → Select “Next” Publication Oct, 2012 Ver. 1.02...
  • Page 7 Series User Manual Step8. Select “Install the software automatically (Recommended)” → Select “Next” Step9. If it is pop-up a new windows that “Hardware Installation”, please select “Continue Anyway” Publication Oct, 2012 Ver. 1.02...
  • Page 8 Series User Manual Step10. Select “Finish” to finish. Step11. Please open “Device Manager” → check com Publication Oct, 2012 Ver. 1.02...
