6. Connectors and Indicators
6.1 LED Indicators
The Front Panel LEDs display the status of the switch and the associated port connections as
indicated in the table below:
LED Name
PWR Power
L/A Link Activity
SYS System
SPD Data Speed
6.2 RJ45 Ports
The Front Panel has 24 RJ45 Ports and all are Ports 1-16 are PoE+ compatible, with each port
capable of supplying 30W each; the remaining ports are non-PoE capable.
Front Panel
Colour State
OFF
Green
ON
OFF
Green
ON
OFF
Green
ON
ON
Green
Flash
Status
Unit Power Off
Unit Power On
No Connection
Connection
OS Not Running
OS Running
1000/100Mbps
10Mbps
