Parallax PDT-NSM-7024-MP-I Operation Manual page 10

8.3 Power Up
The Unit will automatically power up as soon as DC power is applied to the device. The Power Light will be
illuminated and after approximately 1 second, all of the other LEDs will flash on and off to complete the
initialization sequence. Following this, the Port Status LEDs will display the current state of each of the
ports, and the SYS light will flash to indicate that the operating system is running.
8.5 PC Setup Connection
The default IP address for the switch is 192.168.1.6, so you should ensure that your PC is setup correctly to
communicate with the switch. From your Network Settings Menu, you can adjust the IPV4 configuration to
use a Manual IP address in the appropriate subnet 192.168.1.x where x can be of the value 1-254, but not
have a value of 6. The subnet mask should be set at 255.255.255.0. You can enter the switch IP address
into your browser and access the Web GUI host menu on the switch, from which you can make
configuration changes.
9. Physical Dimensions
