Instructions for installation and use
fig. 1.7
fig. 1.6
fig. 1.8
fig. 1.9
4. Put the back and the left side (part II) on the lower
sides and screw them together from the side. (screws
5x80) Take care that no screws can be seen on the
inside. Use the same procedure for the right and the
front side.(fig.1.7)
Now your sauna should look as shown here. (fig.1.6)
5. Now put the upper log board onto the front wall and
screw it to the sides. (fig.1.8)
6. Then fix the roof supporting battens to the sides at
a distance of 9.5 cm from the upper edge of the side
to the lower batten edge. (screws 4x70 - fig.1.9) The
rounded batten edges should be visible below.
