1.5. Basic Large parts list
No. of
Name
items
Wall elements
1 Lower rear wall element
1 Upper rear wall elements
1 Lower left side wall element
1 Lower right side wall element
1 Lower left rear wall element
1 Upper left side wall element
2 Upper right side wall element
2 Upper front side wall element
1 Log board with ventilation gap
1 Upper log board
1 Door frame
Roof elements
2 Roof element
Support slats
2 Roof support slat
2 Roof support slat
4 Outer corner cover slats
4 Cover slats door horizontally
4 Cover slats door vertically
1 Inner roof cover slat
1 Cable cover slat
2 Bench support slats
2 Bench support slat
p. 6/14
Dimensions
185 x 82,6 x 4 cm
185 x 96,2 x 4 cm
185 x 82,6 x 4 cm
185 x 96,2 x 4 cm
185 x 82,6 x 4 cm
185 x 96,2 x 4 cm
55,6 x 82,6 x 4 cm
55,6 x 96,2 x 4 cm
185 x 14,6 x 4 cm
185 x 14,6 x 4 cm
178,3 x 73,5 x 4 cm
176 x 92 x 5,7 cm
185 x 4 x 4 cm
180 x 4 x 4 cm
204 x 8 x 1,5 cm
68 x 8 x 1,5 cm
188,9 x 8 x 1,5 cm
176 x 8 x 1,5 cm
150 x 4 x 3 cm
50 x 4 x 4 cm
100 x 4 x 4 cm
