10 - SETTING AUTO LOCK/UNLOCK SCHEDULES
Setting these schedules allows the system to automatically unlock
and re-lock a door, open and close a gate, or control almost any
other function at specific times. Each schedule can contain up to
three time periods. For example, doors can automatically unlock
at 8 a.m. and re-lock at 5 p.m. on weekdays, but unlock only
from 8 a.m. to 12 noon on Saturdays. Holidays can be excluded
from these schedules so that the doors/gates will not be open if a
holiday falls on a day that would normally be a business day. For
the auto lock/unlock schedule to work with relays 2, 3, and 4,
relays 2, 3, and 4 must be set as control relays
(see Initial System Set-up, programming number 03
Setting Relay Configuration, page 13).
To set up a schedule that extends past midnight and into the next
day, create a segment that runs until midnight (for example,
Monday through Friday from 8 p.m. until 12 midnight) and a
second segment that starts at midnight on the following days
(for example 12 midnight until 4 a.m. on Tuesday
through Saturday).
1. Select the relay for which the automatic unlock and re-lock is
to be set. Each relay may be controlled independently if they
are set as control relays in programming number 03.
2. Three different time periods may be included in each segment.
If only one unit is being addressed, the current entries for all
segments in that unit will be displayed on the screen. If no
entries have been made, the next prompt will not be shown.
3. Enter the segment time and valid days. If "0" is entered, a
prompt to enter more time segments will be shown.
4. Set the segment begin time in a 2-digit hour, 2-digit minute
format (e.g., 0800). Do not enter colon after the hours.
5. Set AM/PM orientation to the begin time.
6. Set the segment end time (e.g., 0530). Segments must end
after the time that they begin and may not extend past 12 p.m.
on the same day.
7. Set AM/PM orientation to the end time.
8. Enter the days on which the time zone is valid,
1 = Sunday, 2 = Monday, 3 = Tuesday, 4 = Wednesday,
5 = Thursday, 6 = Friday, 7 = Saturday, 8 = Holiday.
STEP 1
SET AUTO LOCK/UNLOCK FOR WHICH
RELAY (1-4) _
STEP 2
ENTER TIME SEGMENT NUMBER
(1-3) _
STEP 3
ENTER 0 TO ERASE THIS SEGMENT
OR 1 TO ENTER TIME AND VALID
DAYS _
STEP 4
TIME TO O P E N DOORS IS
(HR:MN) __:__
STEP 5
0=AM 1=PM _
STEP 6
TIME CLOSE DOORS IS
(HR:MN) __:__
STEP 7
0=AM 1=PM _
STEP 8
DAYS ON WHICH TIME ZONE IS
VALID (1=SUN 8=HOL) _
