Summary of Contents for Chamberlain Sentex INFINITY
- Page 1 The Chamberlain Group, Inc. ® 845 Larch Avenue Elmhurst, Illinois 60126-1196 www.chamberlain.com INFINITY Installation Instructions with Multi-Link Firmware Firmware Rev. 3.0 and up...
- Page 2 T A B L E O F C O N T E N T S INSTALLING THE AUXILIARY RELAY MODULE IMPORTANT NOTICES ...23 .......3 INSTALLATION TIPS TESTING AND ADJUSTING THE UNITS .
- Page 3 I M P O R T A N T N O T I C E S The Infinity systems are powerful and flexible access control systems. These systems can be damaged by incorrect installation. In particular, it is critical that Infinity systems be Incorrect installation invalidates the warranty.
- Page 4 PROVIDE POWER FROM A DEDICATED SOURCE The connection points are marked on the boards clearly. Before The outlet(s) into which you plug the Chamberlain provided making any connections, be sure to read the markings and check transformer or AC power supply should each be wired to their it against the corresponding figure(s) in these instructions.
- Page 5 A R R A N G I N G P H O N E L I N E I N S T A L L A T I O N Your customer should have the telephone company install a telephone line as close as possible to the Infinity system location. •...
- Page 6 Government Printing Office. Washington, D.C., 20402. Stock No. TYPE OF SERVICE 004-000-00345-4. Your Chamberlain Infinity system is designed to be used on DISCONNECTION standard-device telephone lines. They should not be used on coin service or party lines. If you have any questions about your...
- Page 7 D O C R E Q U I R E M E N T S NOTE: The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, Users should not attempt to make such connections operational, and safety requirements.
- Page 8 The unit is shown with optional CCTV. If your system is a “B”, “S”, or “DI” series, skip the sections that do not apply. Most Chamberlain cabinet locks are commonly keyed, but can be Circuit easily replaced with individually keyed locks by a locksmith.
- Page 9 W I R I N G TELEPHONE INTERFACE BOARD CONNECTIONS NOTE: Installation where fiber optic cables are present may To avoid potential damage to the board, remove power to the require additional modifications from your telephone provider. unit BEFORE connecting or DISCONNECTING the phone line. Contact your provider for more information.
- Page 10 PROCESSOR BOARD SIGNAL CONNECTIONS (1100023 Board) Figure 6 4 Amp Fuse Green Keypad Light Fan A Heater A Fan B MADE IN USA MONITOR 12V A/C CLEAR 4 AMP FUSE 13.5V D/C Monitor Power Clear FAN B KEYPAD LITE FAN A Connector for Ground Screw Large Display...
- Page 11 PROCESSOR BOARD SIGNAL CONNECTIONS (1100072 Board) Figure 7 Red LOW Green MADE IN USA MONITOR KEYPAD LITE 12V A/C CLEAR 13.5V D/C Monitor Power Clear Connector for Ground Screw Large Display Clear To Send RS232 Out Ground Connector for RS232 In Small Display Request to Send Clear To Send...
- Page 12 Magnetic locks and DC powered strikes produce potentially • Relay 3 ... .TB11 damaging voltage spikes. Chamberlain strongly recommends installing an IN4001 diode across the magnetic lock coil with • Relay 4 ... .TB12...
- Page 13 • To connect additional units, repeat steps 2 and 3. The same If The Units Are 30 Or More Feet Apart: connections are made between the second unit and the third Connect the units through the dual short-haul modems unit, the third unit and the fourth unit, etc. (Figure 10).
- Page 14 • Dedicated Power Supply: The transformer used by the Infinity INSTALLING A NEW UNIT IN AN EXISTING cannot provide power to the door strikes (if used) or the MULTI-LINK CHAIN optional CCTV. Once the unit is installed, re-sequence all the units in the chain. Enter the system’s configuration information into the new unit, DC POWER (i.e., program access codes, relay activation times, holiday...
- Page 15 I N S T A L L I N G A D D I T I O N A L F E A T U R E S The Infinity system has many standard features which can be connected during installation. Only card readers, built-in modems and CCTV cameras must be ordered as options.
- Page 16 HOOKING UP AN EXTERNAL MODEM The Infinity can communicate with a remote terminal via RS-232 serial port 1 and modems. Figure 13 External Modem Infinity Processor Board Jumper Pins 4 to 5 DB25 Pin #3 DB25 Pin #2 DB25 Connection DB25 Pin #7 Jumper Pins 6 to 20...
- Page 17 NOTES: If The Terminal Or Computer Is Under 30 Feet Away: • Line-powered modems cannot be used with the Infinity. 1. Connect the terminal to the first unit in the chain. Plug the • If external modems are connected to the Infinity telephone terminal into RS-232 Port 1 (Figure 14).
- Page 18 DB-type connector. • Okidata 184 Turbo RS-232 serial printers are available from NOTES: Chamberlain, and come with a DB25 (25-pin data connector) and cabling. • Printers must be connected to the last Infinity unit in the chain.
- Page 19 Connect the Infinity and the printer as follows: DB25 Connections PIN NUMBER ON DB25 TERMINAL ON BOARD TB 2 3 (“receive data”) RS-232 out (OUT) 7 (“signal ground”) Ground 2 (“transmit data”) RS-232 in (IN) NOTE: Place one jumper between pins 4 and 5 and another between pins 6 and 20.
- Page 20 HOOKING UP REMOTE KEYPADS/KEYPAD LIGHTS KEYPADS LIGHTS Require a 7-conductor, 20-24 AWG, shielded cable. We suggest Require a 2-conductor, unshielded cable. Use 18 AWG wire for with both foil and braid shield or equivalent. distances up to 500 feet and 16 AWG for longer runs. Do not run lighting wires and keypad cable in the same conduit.
- Page 21 BARIUM FERRITE READERS PROXIMITY CARD READERS Use the same type of cable as the Wiegand installation if the 24 AWG cable with both a foil and braid shield is recommended readers are within 125 feet of the Infinity. If the cable run is because it allows the card readers to be mounted up to 500 feet longer, use 20 AWG wire for up to 350 feet and 18 AWG wire for from the system.
- Page 22 I N S T A L L I N G T H E A U X I L I A R Y R E L A Y M O D U L E You can purchase an Auxiliary Relay Module (ARM) with a 1.
- Page 23 I N S T A L L I N G T H E A U X I L I A R Y R E L A Y M O D U L E Figure 19 RS232 Baud Selections MADE IN USA 12VAC Power IN Green HI Red...
- Page 24 T E S T I N G A N D A D J U S T I N G T H E U N I T S INTERNAL FANS When connections have been completed, test the system’s functionality and adjust the unit, starting with the side tone Fans prevent display “blotching”...
- Page 25 T E S T I N G A N D A D J U S T I N G T H E U N I T S TELEPHONE ENTRY Test the telephone entry function as follows: Before making any adjustments, the model of the telephone interface board must be determined (model 1100329 or 1.
- Page 26 T E S T I N G A N D A D J U S T I N G T H E U N I T S TELEPHONE INTERFACE BOARD ADJUSTMENTS CARD ENTRY All adjustments must be made in the following order: 1.
- Page 27 T E S T I N G A N D A D J U S T I N G T H E U N I T S POSTAL LOCK, REQUEST FOR ACCESS, DOOR POSITION Figure 22 MONITORING Test these features by shorting across the appropriate terminal block pins, then check to make sure the associated relays activate and deactivate properly.
- Page 28 ® This document is protected by copyright and may not be copied or adapted without the prior written consent of Chamberlain. This documentation contains information which is proprietary to Chamberlain and such information may not be distributed without the prior written consent of Chamberlain.
