Extron electronics ShareLink Pro 2500 Setup Manual page 5

ShareLink Pro 2500 • Setup Guide (Continued)
Operation Using a Mobile Device
The ShareLink Pro App can be downloaded from the Google Play
This app allows you to present photos, documents, web pages, device screenshots, and the device camera (see instructions
below). The ShareLink Pro 2500 also supports iOS screen mirroring.
Using the ShareLink Pro App
Connecting to a ShareLink Pro Receiver
Once the ShareLink Pro app is installed on the device, follow these steps to connect to the ShareLink Pro 2500 receiver:
1. Ensure that the ShareLink Pro 2500 is powered on and connected to the network.
2. Connect your mobile device to an external WAP that is on the same network as the ShareLink Pro 2500 receiver. Ensure that
the WAP and the ShareLink Pro 2500 are wired to the same network.
3. Open the ShareLink Pro app and select the desired receiver from the list. Verify the receiver hostname and IP address on the
standby screen (see
Figure 7. ShareLink Pro App - Receiver Selection
4.
When prompted, enter the login code shown on the standby screen (see
When connection is established, the app shows the Share screen (see figure 8 below).
Presenting Content
Use the Share screen to present content. Select the
1 1
2 2
3 3
4 4
Figure 8. ShareLink Pro App - Share Screen
4,
figure and , on page 3).
1 2
5 5
store (for Android devices) or the App Store
TM
NOTE:
figure
button to see the options below:
View — Select this button to view the ongoing
1
presentation on your screen.
Share with Camera — Click this button to share an
2
image taken by the device camera.
NOTE:
also available to share the device web browser.
Share Image or Video — Click this button to navigate to
3
a specific video or image file on your device. Select the
video or image file to present it on the display.
Mirror Screen — Click this button to automatically mirror
4
your device screen on the display device. Select Stop
Presenting to stop the presentation.
NOTE:
instructions for mirroring the device screen.
End — Select this button to disconnect from the
5
ShareLink Pro device.
To refresh the list, drag down and
release the list. If the unit is not listed, select
the New Connection button and enter the
hostname or IP address as instructed on the
app screen.
4,
).
3
For iOS devices, a Share Website option is
For iOS devices, follow the on-screen
(for iOS devices).
®
5
