• Standby Screen
HDMI pass-through mode is activated while the ShareLink Pro output displays the standby screen.
NOTE:
The standby screen images are displayed only when HDMI and decoder sources are not active.
– Lights green when the HDMI source is active on the output in pass-through mode.
•
HD Pass
USB ports — Use these ports to connect USB peripherals when using ConferenceShare (see the ConferenceShare User
F
Guide at www.extron.com), and to connect the Extron WFA 100 Wi-Fi Miracast adapter. The WFA 100 adapter enables
anyone to share content from a device running Windows 10 without installing any software (see the ShareLink Pro 2500 User
Guide).
Once the ShareLink Pro 2500 is connected and powered on, the standby screen appears on the display:
1 1 2 2
Figure 4. ShareLink Pro 2500 Standby Screen
Hostname — Use this hostname to identify and access the ShareLink Pro 2500 during connection.
1
LAN — Use this IP address to identify and access the ShareLink Pro 2500 during connection and to download the ShareLink
2
Pro client software.
Login code — Use this code to connect to the ShareLink Pro 2500 using the software. This code can be customized or
3
disabled (see the ShareLink Pro 2500 User Guide for instructions).
Operation Using a Computer
Connecting a Computer to the ShareLink Pro 2500
A computer can be connected to the ShareLink Pro 2500 wirelessly through an external wireless access point (WAP), or wired
through a network device. See the instructions below for your preferred connection method.
Connecting Through an External WAP
1. Ensure that the external WAP and the ShareLink Pro 2500 are wired to the same network.
2. Ensure that the ShareLink Pro 2500 is powered on and that wireless network capability is enabled
on your computer.
3. Open the wireless networks on your computer as shown at right, and connect to the external WAP.
Connecting Through a Network Hub, Switch, or Router
1. Ensure that your computer is connected to the network through a hub, switch, or router.
2. Connect the LAN port of the ShareLink Pro 2500 to the network device using an RJ-45 cable.
– Lights green when the standby screen (see figure 4) is active on the output. Lights amber if
3 3
